minipcr P51 Setup Manual

Molecular glow lab

Download this manual

Setup Guide

Patent pending

Need help?

Do you have a question about the P51 and is the answer not in the manual?

Page 1 Setup Guide Patent pending...
Page 2 Box contents Viewer Insert Yellow filter Battery case LED strip You will also need: A 9V battery A Phillips screwdriver...
Page 3 Viewer 1. Unflatten box. 2. Fold flap down into the viewer. 3. Fold side flaps down and interlock them with 4. Fold back flap into the 5. This is how the viewer base viewer. should look now. Push hard! 6. Fold cover flaps. 7.
Page 4 Insert 1. Fold up at crease 2. Fold up at crease and Insert TAB A into SLOT A. View from the bottom. 3. Peel off the protective layer on back of LED to expose the adhesive strip.
Page 5 4. Stick the LED onto the light grey surface marked “LED”, making sure the cables exit as indicated. Make sure that the cables exit as indicated. 5. Fold the Insert across about 90 degrees each. 6. Fold the side flaps, engage them at point B, and interlock. Repeat on the opposite side with point C.
Page 6: Getting There
Getting there! Battery pack 1. Use screwdriver to open battery pack and insert 9V battery. 2. Peel backing off the Velcro to 3. Adhere battery pack to back expose the adhesive. corner of Insert. Make sure to align the corner of battery pack with corner of Insert.
Page 7 Putting P51 together 1. Connect battery wires to LED. 2. Peel yellow filter protective films from both sides. 3. Insert yellow filter against the front window. 4. Place Insert in the box with its window facing the filter. The fit is tight, so some pressure is needed.
