- Page 1 Hypervac Technologies Revolution Hybrid 220V user Manual...
- Page 2 This Manual is supplied to you for your protection and to provide you with many years of trouble free and safe operation of your Hypervac Technologies Product. This Manual will guide you through the safe operation and maintenance of your Revolution Hybrid 220 Volt.
- Page 3 User agrees to hold Hypervac Technologies or any of its employees or agents harmless in the event that this machine is not operated in a safe and proper manner.
-
Page 4: Table Of Contents
Table of Contents Important Notice Resale of goods Understanding the components of the Hybrid 220V Understanding the 220 Volt System Single Phase Motors Three Phase Motors Cleaning the Filtration System Understanding the Quick 220 Splitter Box Reasons for the Quick 220 not to operate... -
Page 5: Resale Of Goods
Resale of goods: In the event of the resale of any goods, in whatever form, Resellers/Buyers will include the following language in a conspicuous place and in a conspicuous manner in a written agreement covering such sale: The manufacturer makes no warranty or representation, express or implied, by operation of law or otherwise, as the merchantability or fitness for a particular purpose for the goods sold hereunder. -
Page 6: Understanding The Components Of The Hybrid 220V
Understanding the Components of the Hybrid 220V The Hybrid Vacuum consists of Three main components: 1. The Lid 2. The Filter Canister 3. The Drive Housing... - Page 7 1. The Lid: The lid is simply that – a lid for the top of vacuum to seal the Filter Canister. With a 10” hole cut out of the top to attach your hose. The most efficient method of connecting you hose to the vacuum is to attach a collar to the end of your hose and then pushing that collar into the opening on the lid.
-
Page 8: Understanding The 220 Volt System
Understanding the 220 Volt Vacuum System This section covers both the Single Phase 220 Volt system and the Three Phase 220 Volt System. To determine whether your Vacuum is either a Single Phase unit or a Three Phase unit is easy. The Single Phase units have a simple On/Off Toggle switch on the front of the Vacuum to operate. -
Page 9: Single Phase Motors
course is inevitable in any vacuum system. In our efforts to build the most powerful vacuum possible we have designed this system to reduce the suction lost due to dust loading in the filters. Single Phase Motors: To power on the Vacuum simply move the toggle switch to the On position. To power down the Vacuum simply move the toggle switch to the Off position. - Page 10 Generally if the Vacuum is running off a dryer plug with hose attached to the Vacuum and the duct work you are cleaning, the amperage will be dropped enough you will never have a problem. It is only times when you may have the Vacuum hooked up to large ductwork, with brand new filters, and it has no real restriction against the impellor will it ever be a problem.
- Page 11 1. You must run the vacuum with hose attached. You may actually have to run with a longer hose until the filters get some dust in them. 2. Using an 8” hose also works well to create restriction 3. Place a filter pad in the top of the vacuum to create restriction. 4.
-
Page 12: Three Phase Motors
Three Phase Motors: Our Three Phase motors are powered by our custom built Hyperdrive. The Hyperdrive is a Variable Frequency Drive. Essentially this drive converts single phase power to three phase power and controls the amount of power being supplied to the motor. The Hyperdrive provides infinite control on the power being supplied to the motor enabling you to operate in the most adverse conditions. - Page 13 The Hyperdrive is programmed to run the motor at a constant 12.5 amps. The Hyperdrive also enables the motor to begin operation with a soft start eliminating the initial power surge of a Single Phase motor. If there is a need to run the Vacuum at lower amps because of adverse power conditions simply press the down arrow on the keypad to reduce the amperage sent to the motor.
-
Page 14: Cleaning The Filtration System
Cleaning the Filtration System The Filter Bag: The Bag should be cleaned after every duct cleaning job. To clean the filter bag simply remove it from the vacuum, empty the large debris into a garbage bag or can then blow the bag out with your air pressure. -
Page 15: Understanding The Quick 220 Splitter Box
Understanding the Quick 220 Splitter Box The Quick 220 should only be used in situations where 220Volt power is not available. The Quick 220 Splitter Box converts two 110Volt circuits into one 220Volt circuit. The Quick 220 is a failsafe method of providing 220Volt power as long as you understand the parameters of its operation. - Page 16 supplied with the Quick 220. If the outlet is wired incorrectly the Quick 220 will not operate. Once you have found two outlets on separate phase of power the Quick 220 will automatically recognise this and the orange indicator light will turn on to show you that it has the correct parameters in which to operate.
-
Page 17: Reasons For The Quick 220 Not To Operate
Reasons for the Quick 220 not to operate: 1. No 220 Volt power. Houses built before the 1930’s may only have one Phase of power. 2. Wall outlet is wired incorrectly. Use the circuit tester provided to test the wall outlet. 3. - Page 18 Most times problems can be easily solved over the phone with a little education. Please don’t hesitate to call us with any questions. There isn’t a question you could ask us that we haven’t heard before and found a solution for. Like they say –...
