DIRECT POU WATER DISPENSER

USER'S MANUAL

OHC-7000D

Please read the instruction manual before using the product.

This product operates at 220-240V, 50/60Hz

This product is intended to be used in household and similar applications.

This manual contains a warranty for the product, so please keep it well.

www.ovio.com

Table of Contents

Need help?

Do you have a question about the OHC-7000D and is the answer not in the manual?

Questions and answers

Summary of Contents for OVIO OHC-7000D

Page 1 DIRECT POU WATER DISPENSER USER'S MANUAL OHC-7000D Please read the instruction manual before using the product. This product operates at 220-240V, 50/60Hz This product is intended to be used in household and similar applications. This manual contains a warranty for the product, so please keep it well.
Page 2: Table Of Contents
Contents Before use Product Features 3 page Safety Precautions 4 ~ 7 page Name of Each Part 8 page Using Installation Precautions 9 page Installation Method 10 page 11 ~ 12 page Control Panel and Display How to dispense the water 13 page Function Setting and release 14 page...
Page 3: Product Features
Product Features KC Mark is the only certified mark of the Korea government that has passed the standards and standards of the water purifier. Please use the water purifier with KC mark in peace. Direct Hot & Cold POUwater dispenser(purifier) It is convenient and hygienic because it can heat or cool immediately without storing water, making it hot or cold.
Page 4: Safety Precautions
Safety Precautions Please ensure that the following instructions are intended to prevent unexpected hazards or damages by using the product safely and accurately. Precautions related to safety are the expected risks and the amount of damages and depending on the urgency of the member's occurrence, the following categories. WARNING CAUTION Failure to observe the instructions may...
Page 5 Safety Precautions WARNING Power-related Do not connect the power cord to P l e a s e u n p l u g t h e p o w e r If water is inside the purifier, Connect the power plug muti-adaptor.
Page 6 Safety Precautions WARNING Installation-related After 30min 45° Do not ground the gas pipe or Be sure to use an extended Insert the power plug into the Do not tilt more than 45 degrees outlet 30 minutes after installation. faucet if the ground is not in the outlet with a ground connection when transporting the product.
Page 7 Safety Precautions CAUTION Related to use If you have not use it for a long time, If the water flows from the inside If the product has severe noise and Replace the filter according activate the electrolytic sterilization of the product or if there is water burning odors or fumes, immediately to the exchange cycle.
Page 8: Name Of Each Part
Name of each part Touch control unit Moving nozzle Sterilization lamp Operating lamp Faucet Mood lamp Filter cover Drip tray grill Drip tray Chilling tank water out valve Dust filter Inlet tubing(White) Drain tubing(Blue) Power cord...
Page 9: Installation Precautions
Installation Precautions When installing the product, do not install it in the following places. · Near fire · Near flammable material · Humidity · In front of air condition/heater · Where snow or rain can fall · Outdoor or direct sunlight ·...
Page 10: Installation Method
Installation Method CAUTION Please consult with our installer for the detailed installation method to guarantee the optimum performance of the product. ※ When producing the product, some residual water may remain inside the filter due to the inspection process. - This product is not used, please use with confidence. Voltage This product is only for 220-240V 50/60Hz, please check the voltage before connecting the power cord.
Page 11: Control Panel And Display
Control Panel & Display Control Panel & Display The Volume of water selection button Each time the button is pressed, it is set in order of 120ml → 250ml → 550ml → continuous. Select the desired amount of water and press the button for more than 6 seconds to fix the volume of water.
Page 12 Control Panel & Display Warm(Approximately 40℃) water selection button Use when you want to dispence warm water. When the hot water lock LED turned on, the warm water select button LED turn off. You can not drink water at this time, please use it after unlocking. Hot water selection button Use when you want to dispense hot water.
Page 13: How To Dispense The Water
How to dispense the water Power on When the power is plugged in, sound effect occurs, the control panel and the display blinks and the product initial startup for about 10 minutes. When the preparation is complete, the display unit and operation are lit and the preparation of the water intake is complete.
Page 14 Function setting and reset Auto-flushing When installing the product for the first time, connect the power cord and the dispense button will blink and drain about 3L of water. After replacing the filter, press and hold the dispense button for about 6 seconds. During flushing, press the dispense button for more than 3 seconds to stop.
Page 15: Precautions When Using
Precaution when using This product is 220-240V 50/60Hz only. CAUTION The power plug must be plugged into a 220-240V 50/60Hz dedicated outlet. The water purifier must be plugged in to operate normally. Do not use multiple electrical appliances at one outlet. Must be used alone for outlets over 16A. ※...
Page 16: How To Clean
How to Clean How to clean the drip tray Removing drip tray Hold the drip tray and separate by pulling into the product front. ※Hold the drip tray and pull it with both hands and pull slowly. The water can be poured out when pull it strongly. Removing drip tray Grill Remove the drip tray and pull the top grill out of the water tray to separate the drip tray Cleaning drip tray...
Page 17: Hygienic Management Of Product
Hygienic management of product Item Contents Please install the product in the region where the tap water Installation conditions is tap water condition and water pressure is conditions 0.1Mpa to 0.7Mpa. Please connect the raw water within the temperature range of 5-35℃. <Installation Restricted Area>...
Page 18: Filter Function And Replacement Time
Filter function and replacement time Function of filter Step 1-2 : Sedi-carbon filter It removes suspended solids such as dust, rust and sand, which are relatively large particles contained in water, and adsorbs various organic compounds such as residual chlorine and disinfectant. Step 3-4 : UF composite filter Minimal micro pores of microns remove various impurities and contaminants harmful to human...
Page 19: How To Replace The Filter
How to Replace the Filter 1. Close the tap water supply valve. 2. Unplug the power plug. (Caution: Danger of electric 3. Open the filter cover on the side of the product by shock when the plug is touched with wet hands) pulling it.
Page 20: Product Specification And Flow Chart
※ The conents of this instruction manual (Exterior design and specifications) are subject to change without notice to improve the quality of the product. ※ Manufacturer : OVIO Corporation : 76, Cheongwonsandan 2-Gil, Mado-myeon, Hwaseong-si, Gyeonggi-do 18543, Rep. of Korea. (+82-31-357-7075)
Page 21: Troubleshooting Guide
Troubleshooting Guide Please check the following before requesting repairs. If there is any problem, please contact the service center. Phenomenon Possible cause Solution ·Check if the power supply is 220V. If the power supply is Low power supply low, the power must be set to 220V. High amount of ·If you take a lot of water continuously, the cold water water to be extracted...
Page 22 Troubleshooting Guide Phenomenon Possible cause Solution Simultaneous use ·When used with other products at the same time, the amount of of faucet or other water to be extracted may be reduced. (Reduced flow) faucets ·Stop using the faucet and take it. ·Check the filter replacement cycle and replace the filter.
Page 23 Note...
Page 24 Manufacturer : OVIO CORPORATION 76, CHEONGWONSANDAN 2-GIL, MADO-MYEON, HWASEONG-SI, GYEONGGI-DO 18543, REP. OF KOREA...
