PARTS LIST
LEG TUBE X 4
EXTENSION TUBE X 4
Insert the 4 leg tubes (rubber feet on bottom)
into the corners of a shelf.
Note: Shelves can be mounted either way, as tray or at shelf
Note: Holes face inwards
Insert extension tubes with joiners
Keep holes facing inwards.
IMPORTANT: READ ENTIRE INSTRUCTION BEFORE ASSEMBLY
"CLICK"
Delta Cycle Corporation
125 Washinton Street
Foxborough, MA 02035 USA
SHELF X 3
Slide on next shelf to rest on the bottom
1
Place top shelf onto plastic collars on extension tubes.
3
3 SHELF UNIT WS1003
ASSEMBLY DIAGRAM
TOP TUBE X 2
COLLAR X 4
JOINER X 2
Copyright 2010
2
4
SEE OVER
Advertisement
Table of Contents
Summary of Contents for Delta Design WS1003
- Page 1 Note: Holes face inwards Insert extension tubes with joiners Place top shelf onto plastic collars on extension tubes. Keep holes facing inwards. “CLICK” SEE OVER Delta Cycle Corporation 3 SHELF UNIT WS1003 125 Washinton Street Copyright 2010 ASSEMBLY DIAGRAM Foxborough, MA 02035 USA...
- Page 2 Maximum load per shelf (spread evenly): 160lbs (75kgs) SAFTEY WARNING: Do not use as a step ladder. Never allow children to climb on rack SEE OVER Delta Cycle Corporation 3 SHELF UNIT WS1003 © 125 Washington Street Copyright 2010 ASSEMBLY DIAGRAM...
