Page 2
1、 主控方案 Bluetooth chipset controller :NY010 2、产品关键参数 Headset Specifications 规格列项 Items 规格参数说明 Description 备 注 Remark 蓝牙版本 Bluetooth version V4.2 蓝牙协议 Bluetooth profile HFP A2DP HSP AVRCP 蓝牙耳机类型 Product type 立体声蓝牙耳机 Stereo Bluetooth Headphone 工作频率 Working Frequency 2.402GHz-2.480GHz 产品尺寸...
Page 3
功能特点 描述 蓝牙立体 声(Stereo 入耳式立体声蓝牙耳机 Bluetooth Headphone 蓝牙通话(Talking) 支持使用蓝牙耳机通话 Support talking function 电量指示(Battery indication) 支持蓝牙耳机的电量在 IOS 手机上显示 Support battery capacity indication 中/英文切换 无 NC 蓝牙配对名称 配对名:17LY71 4、产品提示音、LED 指示灯状态 备注 提示音 LED 状态 序号 功能 status Remark Function tone 蓝灯快闪...
Page 4
末码重拨 待机状态 双击“Power”键一下 Last number Standby mode Double click on“Power”button once redial 接听电话 来电中 短按“Power”键一下 Answer call Incoming call Click“Power”button once 挂断电话 通话中 短按“Power”键一下 End call On calling Click“Power”button once 拒接电话 来电中 长按“Power”键约 2 秒 Reject call Incoming call Long Press“Power”button for 2 second 当电池电压低到...
Page 5
1.耳机电量差不多耗尽 手机与耳机成功连接后断开 Earphone will be 2.耳机与手机超出有效连接距离(10 米) disconnected from time to 1. The battery drain. 2. The headphone is beyond the communication range(10M) time 1.确认通话时连接的音频设备为蓝牙耳机,而不是手机或扬声器; 2.增大耳机或手机音量 3.手机模式不是蓝牙模式 接通电话无声 4.手机音频未打开 No sound on talk mode 1.Confirmed the headphone connected and with earpiece mode on talking. 2.
Page 6
FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
