Summary of Contents for HUBBLEFLY HEAVEN
- Page 1 HUBBLEFLY HEAVEN USER MANUAL Oct. 10th, 2019 www.hubblefly.com...
-
Page 2: Table Of Contents
3.0 Specifications 4.0 Attention before flight 5.0 Charging 6.0 Downloading and Installing App 7.0 App Operating Main Interface Instructions 8.0 Hubblefly GO Main Interface Instruction 9.0 Prepare for Aircraft 10.0 Prepare for Remote Controller 11.0 Ready for Flight 11.1 Aircraft Starting/Code-matching 11.2 APP Connection... -
Page 3: Get To Know Your Aircraft
User Manual 1.0 Get to know your aircraft Foldable design is employed to greatly improve compactness without compromising quality and function. Equipped with advanced Optical Flow Positioning System & Infrared Obstacle Avoidance System, it is capable of achieving accurate positioning and auto obstacle avoidance. More accurate and safer flight is achieved using GPS/GLONASS dual-satellite positioning &... -
Page 4: Get To Know Your Remote Controller
DEVO F8S is in-built with a ground receiving terminal of 5.8G WiFi digital video transmission system, which can achieve a real-time display of high-definition images on a mobile device by using Hubblefly Drone APP, with a foldable holder capable of holding mobile devices. 1. Antenna 10. Power Button 2. -
Page 5: Specifications
User Manual 3.0 Specifications Aircraft 177mm Main Rotor Dia.: Dimensions (L x W x H ) : 229 x 279 x 113mm Weight: 890g(batteries included) Remote DEVO F8S Controller: Main VITUS 320 board: Brushless WK-WS-28-017A Motor: Brushless VITUS 320 ESC: Battery: 11.4V 5200mAh LiPo 3S Flight Time: 22minutes for positioning flight (with10% battery level residual) / 25minutes for ultimate flight... - Page 6 User Manual DEVO F8S remote controller Dimensions (L x W x H ) : 173 x 101 x 71mm 2.4G Working frequency: About 1.5KM (open without shelter, no electromagnetic interference) Signal range: 7.4V 2200mAh Li-po 2S Built-in battery: Applicable to tablet and phone Mobile device holder:...
-
Page 7: Attention Before Flight
Android system Go to Google play to search for Hubblefly Drone or scan the QR code to download and install; iOS system please go to the APP Store to search for Hubblefly Aircraft or scan the QR code to download and install. iOS download... -
Page 8: App Operating Main Interface Instructions
User Manual 7.0 APP Operating Main Interface Instructions On the interface, HD video and photographs can be previewed in realtime and you can set the dynamic parameters, such as aircraft, remote controller, gimbal and battery. GestureShot ActiveTrack Aerial Mode eady 16. -
Page 9: Hubblefly Go Main Interface Instruction
8.0 Hubblefly GO Main Interface Instruction The Hubblefly GO can be activated when the aircraft is in Auto Mode with a strong GPS signal. 1. FPV simulation mode: Just connecting remote controller with your cellphone, you can enjoy a flight experience simulating a real scene. -
Page 11: Prepare For Remote Controller
Open the Mobile Wi-Fi device and wait for 30 seconds, when at the same time “Vitus-Ground-***” and “Vitus-Air-***” appears, click “Vitus-Ground-***” , input password “1234567890” t o connect and exit settings after a successful connection. 11.2 APP Connection Connect the operation app Hubblefly Aircraft / Hubblefly Drone. Connected AUTO Mode eady 1. -
Page 12: Gps Indicator Lights
User Manual 11.3 GPS Indicator Lights When the left red LED light slowly flashes, the GPS function works. Left red LED light slowly flashes 11.4 Motor Unlock/Lock Motor Unlock After successful code-matching, move the left & right sticks down and toggle them outward, and hold for 1.5 seconds. the right red LED light slowly flashes You will see indicating that motors are unlocked. -
Page 13: Flight Control
1) Make sure that the GPS signal is received (left red LED light slowly flashes). 2) Only when “Connected” displays on the upper bar of the main interface of the Hubblefly Drone APP, you can perform APP operation. 3) Please unlock motors before takeoff. (refer to Page 10 for the detailed method) - Page 14 User Manual Return to Home (Remote controller or APP operation) Auto Sports Manual Click this icon on the APP Long press interface, the aircraft will return the aircraft will return automatically. automatically. Horizontal distance between aircraft & Home point＞30m a. When the flight altitude is over RTH Height, the aircraft will keep the current altitude and automatically fly back above the Home Point, then descend vertically.
- Page 15 User Manual Active Track Mode (APP operation) There are two modes: Lock Mode & Follow Mode Follow Lock ActiveTrack in the Auto Mode Click this icon Click the icon Choose what you need Attention: 1) Only Lock Mode is usable at optical flow positioning 2) In the Follow mode, the aircraft is kept at a constant altitude, so please keep an eye on the aircraft's surrounding to assure the personal and property security of you and other people.
- Page 16 User Manual Aerial Mode (APP operation) Aerial Mode Click this icon Click the icon Attention: The Braking will slow down in Aerial Mode. Circle Flight (APP Operation) Aircraft in the Click this icon on Click this icon to the APP map interface enter Circle Flight mode.
- Page 17 User Manual 1. Click this icon to add waypoints 1. Click this icon to add waypoint Clear 2. Click this icon to clear waypoints Start 2. Click this icon to start waypoint f l i g ht Start 3. Click this icon to start waypoints fl i g ht Exit 3.
-
Page 18: End Flight
User Manual Photo & Video (Remote Controller or APP operation) Remote Controller Operation: APP Operation: 1) Select working mode: photo or video Take photo by short pressing the button of Remote Controller 2) Touch the Photo or video icon to take photo or video Camera Settings Photo or video icon... -
Page 19: Additional Instruction
User Manual 14.0 Additional Instruction 14.1 Optical Flow Positioning System Utilizing camera to get aircraft location information, it achieves accurate positioning of aircraft. It is suitable for environments with altitude of less than 3 meters without GPS signal or with weak GPS signal. Please make Please make sure sufficient lighting of the environment sure... -
Page 20: Compass Calibration
User Manual 14.3 Compa 14.3 Compass Calibration Attention: Attention Calibrate compass when abnormal circle flight or skewing occurs during flight (motor locked, right red LED remains on). Please conduct calibration in an open outdoor area away from electromagnetic interference. The compass calibration steps are as follows: Place right/left sticks at lowest location, toggle t h e m inward and keep for 5 seconds until the aircraft’s Left red LED light extinguishes and right red LED... -
Page 21: Stick Mode Switch, Stick Calibration & Fixed Id
Rudder Aileron Rudder Aileron ※ Customization also supported in Hubblefly Drone APP. Stick Calibration Long press “ ” for 3~5 sec, you will hear a beep. Enter stick calibration, repeatedly move sticks f r o m minimum to maximum mechanical range for several times, and then back to the middle. -
Page 22: Instruction Of Intelligent Flight Battery Safety
2) Only batteries supplied by Hubblefly can be used. Hubblefly will not be responsible for any flight failure or other accidents, which are resulted from use of other batteries which are not supplied by Hubblefly. - Page 23 User Manual Manufacturer: Hubblefly Technologies Private Limited Add: 8/139A, Mehram Nagar West, New Delhi - 110037 www.hubblefly.com | support@hubblefly.com User manual is subject to change without prior notice. Please go to Hubblefly official website to get the latest version.
- Page 24 FCC WARNING This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
