KEYWALKER IFD 68 Manual

KEYWALKER IDF 68 wireless mechanical
keyboard Manual
Using manual and warranty card
Thanks very much for buying KEYWALKER mechanical keyboards.
Please read the manual before using it

Attention

After using keyboards for a long time. You hands,arms,neck,shoulders and waist will be uncomfortable
When you feel uncomfortable,tired,please stop using keyboard immediately and have a rest.
When you are not well, please don't use keyboard for a long time .

Feature

All "KEYWALKER" mechanical keyboards use original MX switch.
They have hard internal structure and good touch.
The common colors for MX switch are black,blue,brown,red.
Each keyboard use switches of only one color,Switches of different color have different function and
touch. Please check before purchase.

Device parameters and using

Key quantity:68keys
Switch: MX Switch
Keycaps: Cherry keycaps
Keyboard specifications :wired control:Aint-ghosting NKRO/wireless control : Aint-ghosting 6KRO)
Keyboard dimension: 316mm*109mm*28mm
Keyboard weight: 722g
Cord length :1.5mm
Wireless device system and hardware requirement :
Hardware: Bluetooth V4.0 or above (built-in bluetooth v4.0 or bluetooth adapter v 4.0 or
above),Support Device driver/Custom Operation
System requirement : Wired control
Microsoft windows XP above .
IOS MAC OS.
Linux system.

Wireless control:

Microsoft windows 8/windows 10.
IOS IOS7.0 or above/MAC OS10 system above.
Android: Android 4.4 or above.
This device is with lithium polymer battery 1200mAh. Has USB interface for recharging 5.0V
recharge Voltage , plug in and charge.
The wireless transmission distance is 15m if no obstacles ,when first connection with wireless
device,it need input dynamic pairing code
Wireless Control
1. After switch in the keyboard.FN+Q/W/E(flash once every 3-5 seconds).the keyboard now is on
pairing mode.then please turn on the Bluetooth function on you mobile phones/computer,or other
Bluetooth devices.searching
KEYWALKER,your device will pop up one window to input.identifying code,please input the
identifying code on KEYWALKER keyboard,and press "Enter"key, then the light of "Q/W/E" key
keeps on on, which is means your bluetooth device and the keyboard are connected.
2. Press and hold ''FN''+Q/W/E key is to disconnect the present bluetooth device,it will enter into new
pairing mode.
3. change between multiple devices
At the same time open the phone and tablet PC Bluetooth, by pressing the FN+Q/W/E key.

4.Other function instruction

FN key function Fn+ESC
FN+(1)
4.
FN+(2)
5.
FN+(3)
6.
new bluetooth device.you
ALL for light
F1
F2
F3
will find KEYWALKER,clink
