Summary of Contents for Redsense Medical Alarm Unit
- Page 1 Instructions for use / Alarm unit, Fiber optic cable & Sensor patch ENGLISH...
-
Page 2: Table Of Contents
Instructions Warnings and precautions Mounting Redsense During dialysis After completing dialysis Maintenance Cleaning Charging the battery Replacing the battery Symbols and terms Technical Information EMC Information IFU | Alarm unit, Fiber optic cable & Sensor patch | ENGLISH | ©... -
Page 3: Warnings And Precautions
• The alarm unit shall only be used with the proper AC adapter. • The alarm unit may only be used by persons who have received proper training from Redsense Medical or who have been approved by Redsense Medical. Use by untrained or improperly trained personnel may pose a danger to the patient. -
Page 4: Mounting Redsense
1. Attach the alarm unit to the dialysis machine’ s IV pole / drip stand (see figure 1). If this isn’t possible please contact Redsense Medical for consultation. Connect the AC adapter to a wall outlet and to the black-colored connector on the alarm unit. - Page 5 Warnings and precautions figure 2 figure 1 figure 4 figure 3 figure 6 figure 5 IFU | Alarm unit, Fiber optic cable & Sensor patch | ENGLISH | ©...
-
Page 6: During Dialysis
Charging the battery The alarm unit contains a battery in order to issue an alarm in the event of a power failure from the AC adapter. When the alarm unit is connected to the AC adapter, the charging status for the built-in battery is displayed as: •... -
Page 7: Replacing The Battery
Replacing the battery In order to replace the battery, the alarm unit must be opened and this can only be done during servicing. Servicing the equipment and changing the battery should only be done using Redsense Medical or by personnel authorized by them. - Page 8 Consult warnings and almstad precautions RA-1-RA201 On/0ff-button Class II – double insolation Do not use if package The sensor has been sterilized using is damaged Ethylene Oxide (Sensorpatch) IFU | Alarm unit, Fiber optic cable & Sensor patch | ENGLISH | ©...
-
Page 9: Technical Information
Harmonic emission IEC 61000-3-2 Class A power supply network that supplies buildings used for domestic purposes. Voltage fluctuations/ flicker emissions IEC 61000-3-3 Complies IFU | Alarm unit, Fiber optic cable & Sensor patch | ENGLISH | ©... - Page 10 Interference may occur in the vicinity of equipment marked with the following symbol. IFU | Alarm unit, Fiber optic cable & Sensor patch | ENGLISH | ©...
- Page 11 Note 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies. Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. IFU | Alarm unit, Fiber optic cable & Sensor patch | ENGLISH | ©...
- Page 12 Connector for ymbol AC adapter Yellow indicator with warning symbol ellow indicator with attery symbol Service connector (Redsense use only) or with Redsense Medical AB | Gyllenhammars väg 26 302 92 HALMSTAD | SWEDEN | www.redsensemedical.com...
