Winstar M Series User Manual

Tft-lcd module

Advertisement

Quick Links

M-series TFT User Guide
(V1.6.8)
Date :2015/08/31

Advertisement

loading
Need help?

Need help?

Do you have a question about the M Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Winstar M Series

  • Page 1 M-series TFT User Guide (V1.6.8) Date :2015/08/31...
  • Page 2 1. How to connect Winstar M-series TFT to your PC 2. Winstar M-Series clever system kit 3. Hardware control function 4. Touch Panel Control function 5. Firmware Update...
  • Page 3 1. How to connect Winstar M-series TFT to your PC 2. Winstar M-Series clever system kit 3. Hardware control function 4. Touch Panel Control function 5. Firmware Update...
  • Page 4 PN : WF35M w/ RTP M series TFT PN : WWTFT-10# USB Transfer Board USB cable Clever system kit Hardware 1. M series TFT 1. Winstar .exe 2. WWTFT-10# 2. FTD2XX_NET.XML 3. USB cable 3. FTD2XX_NET.dll 4. USB driver 5. HIDBootLoader_V1_6.exe...
  • Page 5: Hardware Connection

    First, the Pin1 to Pin4 of JP3 connection on WWTFT-10#(USB transfer board) should connect to the Pin1 to Pin4 of CON2 connection on M series module. Once starting, the PC USB port should also connect with the USB transfer board. Then, the module will display “Error No image”.
  • Page 6: Connection Check

    Connection Check For the first time installation, the USB driver will install automatically when getting USB transfer board connected with computer. Please make sure the PC can access with the Internet. Otherwise, the USB driver need to set up manually. Please select “Start menu”“Computer”...
  • Page 7 M-Series Clever system kit Please copy FTD2XX_NET.XML, FTD2XX_NET.dll and Winstar.exe to your own folder. When executing “Winstar.exe” application, it will generate “IMG_SAVE.h” file which records the images download history.
  • Page 8 1. How to connect Winstar M-series TFT to your PC 2. Winstar M-Series clever system kit 3. Hardware control function 4. Touch Panel Control function 5. Firmware Update...
  • Page 9 Main Page  Main Instruction page...
  • Page 10 Main Page  Main Instruction page 1. Select COM port 2. Messages that show system status : (a)Ready to Link : Wait for connecting (b)System Ready : Connection is successful (c)Connection Timeout: Status like failed connection, or timeout…...
  • Page 11 Main Page 1. Text function 2. Clean screen 3. Draw Image 4. Draw pixel 5. Draw line and square 6. Command area 7. Memory space...
  • Page 12: Load Image

    Load Image  Load Image page P.S. First image will be the starting picture...
  • Page 13 Load Image 1. Download single image Select ”Select File”  choose image  select “Open”  select “Loading File” press “OK”.
  • Page 14 Load Image 2. Download images file Choose ”Select All” to select all images at same folder, which is available for download.
  • Page 15 Load Image 3. Remove the image’s background (1) Mouse over and click the to-be removed color in the preview picture (2) “Ignored Color” will show the color code value (3) Then select “Loading File”. After download, the image without background will show on the screen.
  • Page 16 Load Image  Image Name: A list of loaded images are available to use.
  • Page 17 Load Image  Select the image you prefer, then choose “Display Layer” and press “Paint Image”. Frame buffer(SRAM) Display Layer Icon Layer Background Layer...
  • Page 18 Load Font Library  Load Font page 1. Choose your preference Windows font from “Select Font Type” 2. Select Font style 3. Loading font by selecting ”Load Font Library” 4. In “Loaded Font List”, a new font library file is built.
  • Page 19 Load Font Library  Font: A list of loaded fonts are available to use.
  • Page 20 Display Memory Layer Structure Frame buffer(SRAM) Images and Texts will display on Display Layer the TFT screen. Edit image and texts in this layer only Icon Layer Default background image Background Layer...
  • Page 21 Display Memory Layer Structure  Key-in words in Text Data area, then select “Display Layer” and press “Paint text” Frame buffer(SRAM) Display Layer Icon Layer Background Layer...
  • Page 22 Display Memory Layer Structure  Icon layer purpose: Show all icon or words in assigned locations at once. 3. After send command ” write to Display layer” Frame buffer(SRAM) Display Layer Key-in words in Text Data area, then select Icon Layer “Icon Layer”...
  • Page 23 1. How to connect Winstar M-series TFT to your PC 2. Winstar M-Series clever system kit 3. Hardware control function 4. Touch Panel Control function 5. Firmware Update...
  • Page 24 Hardware Control Page  Peripheral Hardware Control page Sleep mode: On=sleep mode Off =normal mode PWM signal: Frequency from100~300KHz Brightness Adjustment: adjust range 0~100 TP Calibration: touch panel calibration Command area...
  • Page 25 Hardware Control Page  Peripheral Hardware Control page  Select “Erase Flash” to Erase All flash memory.
  • Page 26 1. How to connect Winstar M-series TFT to your PC 2. Winstar M-Series clever system kit 3. Hardware control function 4. Touch Panel Control function 5. Firmware Update...
  • Page 27: Touch Panel Calibration

    Touch Panel Calibration  Select “TP Calibration”, three black blocks will show on the screen.
  • Page 28 Touch Panel Calibration  Select “TP Calibration”, three black blocks will show on the screen.  Touch the left upper first, then touch the middle, and touch the right below position. Then you will finish the TP calibration. p.s. If you touch one of three black blocks, it will turn to green block.
  • Page 29 Touch Panel Control Function  TP page The Picture Preview will show the blocks of touch position when you touch the panel.  For example: drawing the circle on the module then the picture preview will show the circle.
  • Page 30 1. How to connect Winstar M-series TFT to your PC 2. Winstar M-Series clever system kit 3. Hardware control function 4. Touch Panel Control function 5. Firmware Update...
  • Page 31 (1) Short JP2 pin1 & Pin2, short Pin5 & Pin6. (2) Short JP4 2. JP3 (Pin1~Pin7) of WWTFT-10# connects with CON2 (Pin1~Pin7) of M series module. 3. Connect to PC USB port and then power on USB transfer board and M-series.
  • Page 32 Step 4: Select Update program 4. Open Winstar clever system kit, Select “Update Program” can open HIDBootLoader_V1_6.exe directly.
  • Page 33 Step 5: download.wof file 5. Select “Open Wof File”, select the wof file you want to update and open it.
  • Page 34 Step 6 Program/Verify and Restart 6:Select ”Program/Verify”, start to update firmware. 7:Change back JP2 & JP4 to the original position then able to restart the module and clever system kit.
  • Page 35: Contact Information
