Figure 1
Contact
Contact All Safety Products, P.O. Box 3822, Lakewood, CA 90711-3811
Tel. 877-209-3108 (USA) Toll-Free or Direct Line to Customer Service, 562-630-3700
Website: www.allsafetyproducts.com
For assistance with any questions, please contact us above or
E-mail us: customerservice@allsafetyproducts.com
NOTE: All Safety Products reserves the right to make changes without prior notice
www.allsafetyproducts.com
Exterior Height
Interior Height
Exterior Width
Interior Width
Exterior Length
Interior Length
Door Frame Width
Door Frame Height
Weight
April 1999
Page 1 of 17
91.0 in
231.0 cm
83.0 in
211.0 cm
47.0 in
119.0 cm
43.0 in
109.0 cm
47.0 in
119.0 cm
45.5 in
116.0 cm
26.0 in
66.0 cm
75.0 in
191.0 cm
171 lbs.
77.0 kg
Advertisement
Summary of Contents for All Safety Products Fleet Shower SH1 Series
- Page 1 Contact All Safety Products, P.O. Box 3822, Lakewood, CA 90711-3811 Tel. 877-209-3108 (USA) Toll-Free or Direct Line to Customer Service, 562-630-3700 Website: www.allsafetyproducts.com For assistance with any questions, please contact us above or E-mail us: customerservice@allsafetyproducts.com NOTE: All Safety Products reserves the right to make changes without prior notice...
-
Page 2: General Product Overview
April 1999 Page 2 of 17 Fleet Shower Model GENERAL PRODUCT OVERVIEW Fleet Shower Room provides a private, personal hygienic bathing facility for a variety of rental applications. These include: RECREATION: campgrounds, parks, residential & municipal swimming pools, marinas, sporting events and ocean or lake front hotels CONSTRUCTION: work crew clean up from dusty environments such as building demolition, ground grading and land... -
Page 3: General Notes
April 1999 Page 3 of 17 Fleet Shower Room Assembly Instructions PLEASE READ THESE INSTRUCTIONS GENERAL NOTES The Fleet Shower Model is supplied either assembled or unassembled. Please retain these assembly instructions for future use in the event replacement parts are required. All references to left, right, front and rear throughout the entire assembly instructions are shown in figure 2 exploded parts drawing and as viewed when looking at the front of the shower room from the outside. - Page 4 April 1999 Page 4 of 17 Fleet Shower Room Exploded Parts Drawing Figure 2 NOTE: ITEM NUMBERS LISTED IN THE BILL-OF-MATERIALS WITH AN ALPHABETICAL SUFFIX ARE NOT SHOWN, HOWEVER, THEY ARE USED WITH THE NUMBER BEFORE IT.
- Page 5 April 1999 (Revised January 2001RM) Page 5 of 17 Fleet Shower Model - BILL OF MATERIALS ITEM PART # DESCRIPTION REQ. ITEM PART # DESCRIPTION REQ. FS1-0007 Roof SG1-0086 Runner, sacrificial PC-000101 Rivet, large flange, long PC-000123 Washer, flat 1/4 x 5/8 PC-000121 Washer, fender 1/4 x 1 1/4 SS PC-000174...
- Page 6 FULL SIZE SCALE OF FASTENERS USED FOR THE FLEET SHOWER ASSEMBLY April 1999 Page 6 of 17 PC-000101 PC-000102 PC-000104 Large Flange PC-000106 Small Flange Small Flange Long Rivet 3/16” Back-Up Short Rivet Long Rivet Washer PC-000158 #10 x 1-1/2” PC-000160 PC-000121 Oval Head...
- Page 7 April 1999 Page 7 of 17 Fleet Shower Room Assembly Instructions The base, sacrificial runners, drain pan, floor-grating and related parts are shipped from the factory as a sub-assembly. The following instructions are to be used for reference purposes should any of these components need to be replaced.
- Page 8 April 1999 Page 8 of 17 Fleet Shower Model Assembly Instructions STEP 3. 2" PVC PLUMBING DRAINAGE SYSTEM TO UNDERSIDE OF DRAIN PAN. Refer to figure 5. The plumbing system consists of: two - 2" flexible rubber couplings with clamps; a solvent cemented assembly consisting of two 90°...
- Page 9 April 1999 Page 9 of 17 Fleet Shower Model Assembly Instructions STEP 4. DOORJAMB TO BASE (cont.): Place an aluminium backing plate on the underside of the base inserting the screws through the holes of the plate. Install a 1/4”-20 nylon lock nut on each of the screws and tighten.
- Page 10 April 1999 Page 10 of 17 Fleet Shower Model Assembly Instructions BUILDING THE CABANA STEP 6. SIDEWALL PANELS TO REAR EXTRUSIONS AND REAR WALL PANEL: The rear left and right extrusions have a mitre cut on one end. The top extrusion has mitre cuts on both ends.
- Page 11 April 1999 Page 11 of 17 Fleet Shower Model Assembly Instructions STEP 9. WALL PANELS TO BASE SUB- ASSEMBLY: See figure 9. Using PC-000192, SEMS 1/4 x 1 1/4 self- threading, screws with washers assemble the walls to the base in the sequence shown in figure 9.
- Page 12 April 1999 Page 12 of 17 Fleet Shower Model Assembly Instructions STEP 12. SHOWER TOWER ASSEMBLY TO DRAIN PAN: Refer to figure 11. Remove the cap on the shower head end of the long shower tower tube and slip the end of the tube through the opening in the roof.
- Page 13 April 1999 Page 13 of 17 Fleet Shower Model Assembly Instructions STEP 13. FRESH WATER INLET PLUMBING (cont.). Drill a 1 1/8" diameter hole. Using the fresh water hose connector as a drill guide, position it in the hole on the outside of the rear panel and drill two 13/64"...
- Page 14 April 1999 Page 14 of 17 Fleet Shower Model Assembly Instructions STEP 15. SHELF FOR TOILETRIES: Refer to figure 14. The shelf is positioned around the shower tower and on the second rib from the top of the side panel. Slip the shelf over and around the shower tower so that it rests on the rib of the side panel.
- Page 15 April 1999 Page 15 of 17 Fleet Shower Model Assembly Instructions STEP 17. DOOR TRIM PANEL, SPRING CLOSURE AND SLIDE LATCH ASSEMBLY: See figure 16. Reinstall the door on the doorjamb by reversing step 4. On the outside of the door push the cable end of the spring tube assembly through the hole in the door below the middle hinge.
- Page 16 April 1999 Page 16 of 17 Fleet Shower Model Assembly Instructions STEP 17. DOOR TRIM PANEL, SPRING CLOSURE AND SLIDE LATCH ASSEMBLY (cont.): Apply the "In-use/Open" decal to the slide latch. There is a punched 1/4" diameter hole in the decal. Align this to the corresponding hole in the slide latch.
- Page 17 April 1999 Page 17 of 17 Fleet Shower Model USE, SERVICE AND MAINTENANCE SUGGESTIONS WE STRONGLY SUGGEST MEMBERSHIP IN THE PORTABLE SANITATION ASSOCIATION INTERNATIONAL (PSAI) WHICH IS THE RECOGNIZED WORLDWIDE AUTHORITY ON PORTABLE SANITATION SERVICES: PORTABLE SANITATION ASSOCIATION INTERNATIONAL 7800 METRO PARKWAY, SUITE 104 BLOOMINGTON, MINNESOTA 55425 USA 800-822-3020 / 612-854-8300 (FACSIMILE 612-854-7560) THE PSAI, "PORTABLE SANTATION INDUSTRY CERTIFICATION...
