BTA007 BLUETOOTH ADAPTER
1.1 （PRODUCT OVERVIEWAL）
BTA007 is a Bluetooth adapter (Bluetooth receiver &transmitter
two-in-one device), which supports receivingmode and transmitting
mode. In receiving mode, you canchange the Bluetooth adapter into
a Bluetooth speaker or a Bluetooth earphone by connecting it with a
speaker or a wired earphone via AUX port. In transmitting mode, you
can send the audio program of your cellphone, computer and TV to other
Bluetooth player by wireless connecting. It supports the devices with 3.5mm
earphone plug
(AUX) and audio fiber optic interface (SPDIF).
1.2（PREPARATION BEFORE USE）
When you are ready to use BTA007, you need to prepare fully charged
BTA007, Walkman，cellphone, TV or computer which supports 3.5mm audio
output interface or audio fiber optic port(SPDIF)
1.3（RODUCT PICTURE AND FUNCTION DEFINITION）
A
B C
D E F G
A:Audio interface choice is 3.5mm earphone port.
B:Audio interface choice is fiber optic port.
C:power supply button (multi-functional button)
D: Mode choice transmitting mode
E: Mode choice is receiving mode
F: Reset button
G: 3.5mm audio input port
H: Audio fiber optic input port
I: Audio fiber optic output port
J:3.5mm audio output port
K: Charging port
L:Volume - (short press)/ last song (long press) K: Volume + (short press)/ next
song (long press)
J K
H I
L
M
Advertisement
Table of Contents
Summary of Contents for Dongguan Binshi BTA007
- Page 1 (AUX) and audio fiber optic interface (SPDIF). 1.2（PREPARATION BEFORE USE） When you are ready to use BTA007, you need to prepare fully charged BTA007, Walkman，cellphone, TV or computer which supports 3.5mm audio output interface or audio fiber optic port(SPDIF) 1.3（RODUCT PICTURE AND FUNCTION DEFINITION）...
- Page 2 1.4（RODUCT PICTURE AND FUNCTION DEFINITION） Bluetooth version V4.1，C lass II The Bluetooth CSR 8670 chip Frequency range 2.402G H z-2.480G H z Working time About 12 hours (RX mode) Working time About 13 hours (TX mode) Charging time About 2 hours Bluetooth A2DP, AVRCP protocol...
- Page 3 LED light of adapter blinks quickly, get the second Bluetooth device, say BTA007, to enter into the pairing mode (Long press the MFB button of BTA007 until see the alternative flash of red and blue light) wait several seconds, it will connect the second device automatically.
- Page 4 Make sure the adapter is in RX mode, delete the paired BTA007 in your cellphone, and double click the MFB button to assure the adapter enter into the pair mode and search and connect the phone again.
- Page 5 If you put BTA007 in freezing cold or burning hot places, for example, if you put it in the closed car both in winter or summer, you will shorten the life and capacity of the battery.
- Page 6 2.5 Other matters of attention changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
