ORSTEEL Light SILURE RGBW Technical Manual

TECHNICAL SCHEMATICS
69 69
INSTALLATION SCHEMATICS
Cable ref CAB0010
NEVER TURN ON THE PROJECTEUR
IF IS NOT UNDER WATER.
Concrete
Water level
Serial Wiring RGBW
All data are given for information purposes only. They do not constitute a contractual commitment on our part and are subject
to change at any time.
49 49
65 65
TECHNICAL MANUAL
SILURE
RGBW/DYNAMIC WHITE 700mA
0,44
ACS
IP69 IK10
A A+ A++
T° max 55°C
The Silure submersible spotlight with its directable head will enhance your ponds,
waterfalls, swimming pools and lagoons whether fresh or salt water. This spotlight is
also a shipyard favourite and provides yachts and luxury boats new RGBW effects to
play with light. It is made from 316L stainless steel which, together with its IP69 cable,
makes it perfectly watertight in wet zones.
Electrical Features
POWER 1x10W
SUPPLY 700mA
POWER SUPPLY Not included
WIRING Serial
Features
lighting technology
60 000 heures
AVERAGE LIFE OF THE
LED Certifiée L90 B10
COLOR EMISSION RGBW :
Red - Green - Blue -
4000°K
Dynamic White :
2700°K - 3000°K
4000°K - 6000°K
ANGLE BEAM 10°-25°-40-115°
INITIAL OUTFLOW 634lm at 4000k
Mechanical Features
DIMENSIONS Ø49mm x 69mm
WEIGHT 0.44kg
MATERIAL INOX316L
electropolished
General features
OPERATING - 20°c ~+ 60°
TEMPERATURE
INGRESS PROTECTION IP69
IMPACT RESISTANCE IK10
A / A+ / A++
ENERGY CLASS
APPLICANCE CLASS CLASS III
WALKOVER FIXTURE NO
DRIVE-OVER FIXTURE NO
WIRES 8x0.22mm2 in IP68
PHOTOBIOLOGICAL Risk group I
SAFETY
