Eco Garden House 5000 Assembly Manual

88” x 72” x 48” (1.8m x 1.2m x 2.2m)

Hide thumbs

page of 60

/ 60
Bookmarks

Quick Links

Download this manual

88"

(2.2m)

Thank you for purchasing the Eco Garden House indoor greenhouse. Please read these

instructions thoroughly before assembling or using the Unit. The terms and conditions

contained in this Assembly Instruction Guide are the only terms which govern the sale of

the unit by The Plastics Group, Inc (TPG). and the direct or indirect use of the unit by you,

your representative, or any third party. By assembling or otherwise using the unit, you

accept and agree to be bound and abide by the terms and conditions contained herein.

The Plastics Group, Inc.

7409 S. Quincy St. Willowbrook IL 60527

1.888.449.3326

Eco Garden House Assembly Guide

88" x 72" x 48" (1.8m x 1.2m x 2.2m)

72"

(1.8m)

48"

(1.2m)

Check Out Our Site for:

• Video Assembly Guide

• Customer Support

• Join the Indoor Greenhouse

Community

www.EcoGardenHouse.com

Need help?

Do you have a question about the 5000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eco Garden House 5000

Page 1 72” 48” (1.8m) (1.2m) Thank you for purchasing the Eco Garden House indoor greenhouse. Please read these Check Out Our Site for: instructions thoroughly before assembling or using the Unit. The terms and conditions • Video Assembly Guide contained in this Assembly Instruction Guide are the only terms which govern the sale of •...
Page 2 AND PROPERTY DAMAGE! Determining Your Location • Make sure that you have measured the final location for your Eco Garden House (length, width, & height). • A level floor is required for the placement of the tanks due to liquid water contents.
Page 3 Eco Garden House Assembly Guide Page 3 In Case of Missing Parts: Please Do Not Return to Store! STOP For faster resolution call: 1.888.449.3326 Or visit our website: www.EcoGardenHouse.com...
Page 4 Eco Garden House Assembly Guide Page 4 Included Components Part Qty. Part # Reference Description Three layer Fabric, adhesive, Tent Shroud SHR601011 Mylar Tent covering with various fittings Shroud Top Left Side Shroud Right Side Shroud (Components comes attached to...
Page 5 Eco Garden House Assembly Guide Page 5 Included Components (Cont.) Part Qty. Part # Reference Description Fan/Digital Display Kit DIS601014 Thermal Control Unit USB Power Supply 24” Power Cord Cord Thermal Control L-Bracket Shim Spacer Screw High Speed 120mm USB Fans...
Page 6 Eco Garden House Assembly Guide Page 6 Included Components Part Qty. Part # Reference Description All parts come pre-installed in Drainage Tank Kit the gray water tank Eco-Tank F Gray water Tank 110 Volt low head (approx. 4 feet) Water Sump Pump...
Page 7 Eco Garden House Assembly Guide Page 7 Included Components (Cont.) Part Qty. Part # Reference Description Light raise/lower adjust system of two (2) steel bars, IM handle with integral return Light Height spring, pulleys/bobbins, pin, screws, Adjustment Assembly LIG601015 cordage, and “J” hooks assembled and...
Page 8 Eco Garden House Assembly Guide Page 8 WARNINGS 1. A level floor is required for placement of the tanks due to the liquid water contents. The floor must be able to support loads up to 125 lbs per square foot and 1,000 lbs total load for the entire unit (this includes approximately 500 lbs.
Page 9 Eco Garden House Assembly Guide Page 9 WARNINGS: “Third Party Products” included with the Unit: Products manufactured by a third party (“Third Party Product”) may constitute, contain, be contained in, incorporated into, attached to or packaged together with, the Unit. Third Party Products are not covered by the TPG limited warranty.
Page 10 Eco Garden House Assembly Guide Page 10 Unwrap and Unzip Eco Garden House Shroud Loosen and remove the straps from the shroud. Unroll/unfold shroud and unzip into separate pieces. LEFT Contents: Roof/ Top Shroud, two Side Shrouds, and a Shroud Tray. Set aside everything but the Shroud Tray.
Page 11 · Water Supply and Drain Footprint of unit. ·Control Panel Access ·Back Access 72” Leave adequate space between the 48” walls and Eco Garden House for easy access. Place Shroud Tray Place “water tight” Shroud Tray in desired final position.
Page 12 Eco Garden House Assembly Guide Eco Garden House Assembly Guide Page 12 Page 12 8-Way Manifold Install Freshwater Tank Blue Cap on Freshwater Tank Place the Freshwater Tank in the Shroud Tray on desired control panel side. VERY IMPORTANT: The Freshwater Tank will need power supplied to it. Position it on the same side that you plan to install the Control Panel, Fans, &...
Page 13 Eco Garden House Assembly Guide Page 13 Install Gray Water Tank Gray Cap on Gray Water Tank Place the Gray water Tank in the Shroud Tray next to the Freshwater Tank. Tilt and Tip Two People are needed to install the Gray Water Tank.
Page 14 Eco Garden House Assembly Guide Page 14 Install Fan / Thermal Control Unit Locate the Fan Kit Box with the Control Panel “L” Bracket, Thermal Control Unit, and the two (2) Screws. Locate the 4” x 4” Black Shroud Swatch (in Drip Kit package).
Page 15 Eco Garden House Assembly Guide Page 15 Unpack Single Light Bulb Units Unpack the four (4) pack of the Single Bulb Light Units. Remove the bulb from each of the light units by twisting. Keep the foam on the bulbs for protection, and safely set them aside.
Page 16 Eco Garden House Assembly Guide Page 16 Attach Center Support Beams to Wall Sections Gather a Male and Female Support Beam Section and two (2) Wall Sections. Do not use the Wall Section with the Thermal Control Unit. Attach both the Male and Female...
Page 17 Eco Garden House Assembly Guide Page 17 Assemble Side Wall Panels Place all four (4) Wall Section pieces with the Metal Stampings face up on a flat surface. Attach the Control Panel Wall Section to the Wall Section with the Female Support Beam Section.
Page 18 Eco Garden House Assembly Guide Page 18 Attach Support Brackets to Middle Support Beams and Wall Panels Gather the two (2) Triangular Support Brackets. Position one (1) Bracket with the shortest side of the triangle on the Middle Support Beam and the three holes on the Wall Panel.
Page 19 Eco Garden House Assembly Guide Page 19 Install Single Bulb Light Units Locate the one (1) Single Bulb Top Side Light Unit that has open female and male plugs, and snap female plug side up, into the metal Female Plug...
Page 20 Eco Garden House Assembly Guide Page 20 Attach Side Wall Panels Slide both of the Side Wall Panels with their top sides up and the Support Beam Sections at the back of the unit (Refer to diagrams in Step 14) onto the tanks. Ensure the Single Bulb Light Units are facing inside the unit.
Page 21 Eco Garden House Assembly Guide Page 21 Attach Rear Support Beam DO NOT stand on the tank during assembly. While supporting the Side Wall Panels, connect the Rear Support Beam (assembled in Step 7) to the top of Side Wall Panels. Locate slots and pull down from top to secure.
Page 22 Eco Garden House Assembly Guide Page 22 Attach Triangular Tank Brackets to Side Walls Gather eight (8) 3/4” Self Tapping Screws. Locate the four (4) Triangular Brackets attached to the outside four corners of the tank assembly. Use a level to ensure the...
Page 23 Eco Garden House Assembly Guide Page 23 Assemble Roof Truss Sections Notches on ends denote top side of the Roof Truss Sections. Gather the four (4) Roof Truss Pieces, two (2) Plastic Plates, four (4) 5” Bolts, four (4) Male truss Spacers, and four (4) Cap Nuts.
Page 24 Eco Garden House Assembly Guide Page 24 Connect Roof Truss Connect the Roof Truss Unit to the top of the Side Wall panels. Locate inside slots and pull down to secure. Ensure correct Truss placement Rubber mallet may be needed to fully secure Roof Assembly onto Side Walls.
Page 25 Eco Garden House Assembly Guide Page 25 Install Pulley System Bar & Left Female Support Beam Section Locate the two (2) remaining Support Beam Sections. Connect the Female Support Beam Section to the left side outer slot and pull down to connect.
Page 26 Eco Garden House Assembly Guide Page 26 Install Right Pulley System Bar & Right Male Support Beam Section Locate the last remaining Male Support Beam Section. Place the right Pulley System Bar (with the four spools and cordage) into the upper rear...
Page 27 Eco Garden House Assembly Guide Page 27 Install Structural Support Hardware Gather two (2) 1.75” Bolts, four (4) Washers, and two (2) Cap Nuts. Twist a Bolt with Washer into the top Female Support Beam Foot Section connecting both Support Beams. Attach...
Page 28 Eco Garden House Assembly Guide Page 28 Install Fans Locate one (1) of the two (2) Fans supplied and two (2) of If holes are not pre-drilled into the the four (4) supplied Fan Grills. mounting tabs, drill 1/8” holes into plastic tabs.
Page 29 Eco Garden House Assembly Guide Page 29 Plug Fan Units into Thermal Controller Plug both of the Fan Unit USB plugs into the Thermal Controller.
Page 30 Eco Garden House Assembly Guide Page 30 Install Power Control Panel Remove clear plastic battery pull tab Locate the Control Panel. Remove the clear plastic battery pull tab. Locate the two (2) Corner Brackets, and two (2) Self Corner Brackets Tapping Screws.
Page 31 Eco Garden House Assembly Guide Page 31 Install Single Bulb Light Unit Wiring Daisy Chain Cord If installed correctly, all four (4) Single Bulb Light Units should have an open plug on the top side. Find the Daisy Chain cord.
Page 32 Eco Garden House Assembly Guide Page 32 Install Single Light Unit Power Supply Cord Find the power supply cord. Power Supply Cord Locate the Single Bulb Light Unit with the male end exposed on the Bottom Side (on the control panel side),...
Page 33 Eco Garden House Assembly Guide Page 33 Install Top Shroud With the Top Shroud piece in hand, locate the 4” round access sleeve, this will be positioned over the Light Adjustment Handle on the front side. With two people, slide the Top Shroud over the Roof Truss.
Page 34 Eco Garden House Assembly Guide Page 34 Install Right and Left Shroud Start with the Right Shroud (section without logo), start zipper at the top middle of Right Shroud the right side of the unit. Zip all the way around the top as shown.
Page 35 Eco Garden House Assembly Guide Page 35 Fold Shroud Open Unzip the front, central zipper. Unzip the front side, top and bottom, of both the right and left shroud. Fold back the right and left shroud as shown and clip to secure.
Page 36 Eco Garden House Assembly Guide Page 36 Attach the Shroud Straps Locate the straps on the inside of the Left and Right Shroud at each of the corners. Pull the straps around each of the four Single Bulb Light Units,...
Page 37 Eco Garden House Assembly Guide Page 37 Install the Vertical Light Reflectors Locate one (1) Light Reflector and two (2) Steel Reflector Clips. Remove the protective film from both sides of the Reflector. With the Reflector in proper orientation on light assembly (see...
Page 38 Eco Garden House Assembly Guide Page 38 Install Pulley System for 8-Bulb Overhead Light Unit Left Pulley System Bar Cut the rubber bands off of the Left Pulley System Bar to allow for free movement of the two spools. Right Pulley System Bar...
Page 39 Eco Garden House Assembly Guide Page 39 Install Pulley System for 8-Bulb Overhead Light Unit Take the loose ends of each of the four (4) cords and attach the J-hooks into the holes located on the Roof Truss. J-Hooks should hook in to 1/8” hole on the roof truss near Light Adjustment Bar (approximate location shown).
Page 40 Eco Garden House Assembly Guide Page 40 Install 8-Bulb Overhead Light Unit With two (2) people, take the 8-Bulb Overhead Light Unit and attach the four (4) “J” hooks into each of the four (4) corners. Make sure power cord is on the Control Panel side.
Page 41 Eco Garden House Assembly Guide Page 41 Attach the Overhead Lighting and Freshwater Pump Cords For the Overhead Light, locate the upper Side Wall Beam on the Control Panel Side and loosely attach a zip tie around the center. Run the cord from the...
Page 42 Eco Garden House Assembly Guide Page 42 Install Light Bulbs Remove the protective foam from each of the four (4) Single Light Bulbs. Carefully install the four (4) Bulbs into Single Light Bulb Units by inserting and twisting them to lock in place.
Page 43 Eco Garden House Assembly Guide Page 43 Electronics Schematic Plug the Thermal Control Unit, Freshwater Pump, Single Bulb 8-Bulb Overhead Light Unit Cord, and the 8-Bulb Light Unit Overhead Light Unit Cord into the Power Control Panel. Timer 2 Timer 1...
Page 44 Eco Garden House Assembly Guide Page 44 Fill the Freshwater Supply Tank Locate the blue cap on the Supply Tank. Remove the cap and insert the water source hose (no larger than 3/4”) into the Supply Tank (holds approximately 33 gallons (125L)).
Page 45 Attach an extension cord (not included), and plug into a 110v wall outlet. Congratulations! You have completed the Eco Garden House Assembly. Additional Information: When Gray Water Tank is Full, Attach Garden Hose Attach Garden Hose to the male pipe thread fitting when ready to activate Gray Water Pump.
Page 46 Page 46 Lighting Information The Eco Garden House lighting system is designed to simulate the natural light cycles of year-round growing (winter, spring, summer, fall). Therefore, the amount of light and light cycle you choose will depend upon the type of plant you are growing, (long day plants vs. short day plants) the current stage of the plant’s growth cycle, (seedling, starts, small plant, etc) and whether or not you’re...
Page 47 Always use a water soluble nutrient/ fertilizer in the Eco Garden House in order to maintain a healthy watering system for your plants. Based on your use, you may desire to use the chart below for the Eco Garden House Drip Irrigation Watering System output:...
Page 48 Eco Garden House Assembly Guide Page 48 8-Way Manifold & Drip Supply Kit Instructions Installing Tubing 1. Starting at the 8-Way manifold, roll out the 1/4” black vinyl tubing to the first area to be watered and cut the tubing to the desired length.
Page 49 Eco Garden House Assembly Guide Page 49 8-Way Manifold & Drip Supply Kit Instructions Removing Screen Filter for Cleaning The 8-Way manifold has an internal screen to help prevent the 1/4” emitter tubing from clogging. The filter can be easily removed using a at blade screwdriver. For general debris, the screen can be cleaned with canned air or clean compressed air (no oil).
Page 50 Eco Garden House Assembly Guide Page 50 8-Way Manifold & Drip Supply Kit Instructions Shutoff/ Flow Adjustment Screws Each outlet on the 8-Way 1/4” manifold has a shutoff screw that can be used to adjust the ow from full (20 GPH) to o (0 GPH) with a at blade screwdriver. Clockwise will reduce the ow and counterclockwise will increase the ow.
Page 51 Eco Garden House Assembly Guide Page 51 Control Panel Programming Instructions...
Page 52 Eco Garden House Assembly Guide Page 52...
Page 53 Eco Garden House Assembly Guide Page 53...
Page 54 Eco Garden House Assembly Guide Page 54 CHECKING AND CHANGING SWITCHING COMMANDS VARIOUS PROGRAMMING FEATURES...
Page 55 Eco Garden House Assembly Guide Page 55 USER HINTS WARNINGS 1. DO NOT connect to an ungrounded outlet. 2. DO NOT use with extension cords or adapters that eliminate the connection to ground. 3. The power strip is designed for indoor use only.
Page 56 Eco Garden House Assembly Guide Page 56 USB Powered Programmable Thermal Controller With LED Display Set Stop Temp:* Press “stop button” once to put unit in Stop programming mode and the turn off temperature will blink, use the right Up/Down buttons to set the temperature press the “stop button”...
Page 57 Eco Garden House Assembly Guide Page 57 Light Units 8-Bulb Horizontal Light Warnings: - Orientation for Mounting: Horizontal - Electrical Rating: 120V; 60Hz; 3.75A - Bulb Replacement Marking: T5 HO 54W - Caution: Risk of Fire. - Use Only T5 fluorescent 54 watt lamps.
Page 58 Eco Garden House Assembly Guide Page 58 Water Pump Instruction Guide INTRODUCTION This instruction sheet provides you with the information required to safely own and operate your pump. Retain these instructions for future reference. Please examine your pump carefully to ensure that no damage occurred during shipment.
Page 59 Eco Garden House Assembly Guide Page 59 OPERATION 1. Operate the pump in clean, fresh water completely submerged. Do not let the pump run dry. 2. The pump can be placed in any position. There are suction cup feet provided with the pump.
Page 60 Eco Garden House Assembly Guide Page 60 END-USER RESTRICTIONS The Unit is offered and available to users who are 18 years of age or older and reside in the United States or any of its territories or possessions, for use strictly in compliance with all applicable laws, regulations, and ordinances You represent and warrant that you meet all of the foregoing eligibility requirements.
