Summary of Contents for Future Electronics OSSO
- Page 1 OSSO- Pet tracker CONFIDENTIAL AND PROPRIETARY – FUTURE ELECTRONICS...
- Page 2 Introduction...
- Page 3 Reference design evaluation board in the shape of a dog bone to demonstrate pet tracking application • The OSSO board utilizes ST Microelectronics wireless and sensor solutions • Created and designed in-house by the System Design Center, Future Connectivity Solutions and ST Microelectronics •...
- Page 4 Power management components from ST Microelectronics: LDO Voltage regulator: LDS3985 Step up converter: L6920DB • Other components from ST Microelectronics: Balun for Bluetooth SoC: BALF-NRG-02D3 To get more information on the above parts, please click on the OSSO landing page: https://www.futureelectronics.com/resources/promotions/future-osso-board...
- Page 5 GNSS Antenna: APAKN1804-C2G-T Bluetooth Low Energy Antenna: ACAG0801-2450-T • Passive components Inductors: ASPI-5040S-100M-T AIML-0805HC-100 AIMC-0402-2N2S-T AISC-0402-16NG-T AISC-0402-27NG-T • Timing Crystals & synchronization 1. ABM8W-32.0000MHZ-6-D1X-T3 2. ABS06-32.768KHZ-1-T To get more information on the above parts, please click on the OSSO landing page: https://www.futureelectronics.com/resources/promotions/future-osso-board...
- Page 6 Introduction A closer look at OSSO NFC Tag IC Accelerometer and Gyroscope GNSS Antenna IR temperature sensor MEMS Microphone Humidity/Temperature sensor UVA Sensor Bluetooth System-on-Chip GNSS Module...
- Page 7 Introduction A closer look at OSSO GNSS Antenna Bluetooth System-on-Chip Antenna Timing Crystal Inductor...
- Page 8 Introduction A closer look at OSSO cont’d Included in the box: • OSSO Board • 2 x AAA batteries • Scan QR code on label for quick start guide iOS/Android App Functionalities: Sensor Demo 1. Environmental demo 2. IR temperature demo 3.
- Page 9 Quick Start Guide...
- Page 10 Quick Start SW1 LED1 LED2 Turning on the OSSO 1. Flip the switch SW1 to the ON position 2. LED1 will turn on solid. 3. Start the App. 4. LED1 and LED2 will start blinking slowly once you have successfully paired with your smart device 5.
- Page 11 Quick Start *iOS users can skip the Android section...
- Page 12 OSSO- Android – NFC Demo* Click on the bottom of the screen Ensure your device’s NFC is Download an “NFC Tool” to visit the OSSO landing page turned on. Open App and tap**. from the Play Store *OSSO App not required...
- Page 13 Quick Start OSSO Android App Quick Start Ensure your device’s Bluetooth and Download the app Search for “ future electronics GPS are turned on. Select the “+” osso” in Play Store...
- Page 14 Barks: displays number of barks Steps: displays number of steps, need to take a minimum amount of 10 before it is displayed. *It is known that some Android devices have not been compatible. App unable to find OSSO. Please try another device.
- Page 15 OSSO Android-cont’d Select Location icon to view GPS Note: you can delete an information. Note: Please note that OSSO board through the the GPS will NOT receive a fix settings page, and by indoors. The first time to receive a...
- Page 16 Quick Start *Android user can skip the iOS section...
- Page 17 Quick Start OSSO iOS App Quick Start Ensure your device’s Bluetooth is Download the app Search for “ osso future” in App ON and GPS are turned OFF. Store...
- Page 18 Quick Start OSSO-iOS Turn Location Services Disable GPS on your iPhone. Click on Location Services From Setting, go to Privacy...
- Page 19 Quick Start OSSO-iOS In the event that this screen below Ensure your OSSO board and your pops up – hit “Don’t Allow” Bluetooth on your iPhone is turned Start the OSSO App on. Click in the little dog icon...
- Page 20 Quick Start OSSO-iOS-cont’d Select dashboard tab view sensor information Temperature/Humidity: gives reading for Temperature outside IR Temperature: gives reading for Temperature of a surface. E.g. put your hand over the sensor UV index: gives reading for UV Exposure Time: time spent out in the sun...
- Page 21 See GPS Optimization Slide for If you did not turn off your iPhone more details on fixing. GPS, you will get positioning irrespective of the OSSO GPS status since the app will use the GPS Location of your iPhone.
- Page 22 Quick Start...
- Page 23 Quick Start Once you finished doing the demo, please REMOVE the batteries from the unit. This will prevent any shorting potentially caused by the key chain...
- Page 24 Quick Start GPS Optimization How to maximize GPS performances? Use outside where an unobstructed view of the sky is achieved o The antenna has about 120Degree spread on its radiation pattern, it is best if all 120degrees are unobstructed (60degrees on each side) When a fix is obtained, the GPS module is likely still renewing its ephemeris data, the longer it runs with satellites in view/used, the more...
- Page 25 You of these Terms and Conditions of Use or any representations or warranties made by You herein. You will cooperate as fully as reasonably required in Future Electronics’ defense of any claim. Future Electronics reserves the right, at its own expense, to assume the exclusive defense and control of any matter otherwise subject to indemnification by You and You shall not in any event settle any matter without the written consent of Future Electronics.
- Page 26 THANK YOU!
