RADIOHAUS SPIDERDXMAN RH-DX1020 Assembly Instructions Manual

Portable antenna 10, 12 15, 17, 20m

Advertisement

Quick Links

RH-DX1020
Portable Antenna 10, 12 15, 17, 20m
ASSEMBLY INSTRUCTIONS

Advertisement

loading

Summary of Contents for RADIOHAUS SPIDERDXMAN RH-DX1020

  • Page 1 RH-DX1020 Portable Antenna 10, 12 15, 17, 20m ASSEMBLY INSTRUCTIONS...
  • Page 2 Thank you for choosing the SPIDERDXMAN RH-DX1020 Antenna, a Cobweb antenna for portable use in the 10, 12, 15, 17 and 20 meter bands. This antenna was developed considering its efficiency and durability of the materials. It is ideal for hamradio operators that have problems with space and it’s great for using in portable operations.
  • Page 3 1) IDENTIFICATION OF THE PARTS OF YOUR ANTENNA A) Mast / Distribution Box Part B) 4 Pieces Fiberglass tubes with a nylon cable clamp C) 4 Pieces Fiberglass tubes with three nylon cable clamps D) 2 Pieces Small Fiberglass Tubes E) 1 Aluminum plate with central axis clamps F) 1 Aluminum plate with clamps for...
  • Page 5 2) ASSEMBLY 2.1) Take the aluminum plate E and the two tubes D. (Photo 01) 2.2) Position each of the tubes D on one side of the plate E, so that the red marks match the clamps. Note that the tubes should form a cross and two clamps will be free for later use.
  • Page 6 Note that the nylon tab should be positioned toward the outside of the assembly. 2.5) In the same way as with tubes B, mount a tube C on each end so that the plastic cap is positioned on the outside. That way you will have an X-shaped set that will be the structure of your antenna.
  • Page 7 2.9) At each end of each wire, insert one of the 10 nylon cable glands. (Photos 07, 08 and 09) Twist the cable press to give pressure and prevent the cable from escaping. Note that the tips of each antenna element are folded and glued with electrical tape.
  • Page 8 3) ADJUSTMENT Your RH-DX1020 antenna is already set and centered for the lowest SWR at the following approximate frequencies: 20m - 14,150kHz 17m - 18,100kHz 15m - 21,200kHz 12m - 24,950kHz 10m - 28,400kHz In all bands, at the center frequency a very low SWR is obtained, with an increase of SWR for the ends of each band.
  • Page 9: Specifications

    21,050kHz (CW subband), remove the tape and INCREASE the length of the antenna. This adjustment is critical, so you will have to increase only about 5mm (1/4”) on each side, reassemble the antenna and give the SWR. If you want the SWR to be lower at a higher frequency, SHORTEN the antenna’s length.
  • Page 10: Warranty Term

    WARRANTY TERM This product is guaranteed by RADIOHAUS COMÉRCIO E TECNOLOGIA DE PRODUTOS ELETRÔNICOS LTDA. for the period of 01 (one) year from the date of acquisition. This warranty covers defects and materials used in manufacturing. The warranty does not cover defects caused by misuse or misuse of the product.
  • Page 11 Rua Candelária, 672 | Centro Indaiatuba, SP | 13.330-180 | Brazil www.radiohaus.com.br...
