julu Laundry Ladder Instructions

.

In the box

1 x Laundry Ladder
2 x Julu Wall Brackets
4 x Screws + Caps
4 x Raw Plugs
1 x Length of Cord
1 x Spindle + Screw (which is attached
to the inside of the Laundry Ladder
Frame for delivery only)
1 x Rope Hook
1 x Instruction Leaflet
Fixings are ONLY included for solid
walls. All other types i.e. Cavity,
Thermolite Block etc. will require
additional fixings which can be bought
from good hardware stores.
Fixing to a Solid Wall (fixings
included)
Decide on the height.
recommends positioning the Laundry
Ladder base, at waist height to aid
functionality.
Use Ø 7 mm drill
Brackets to be positioned:
52cm apart Bunty (600)
72cm apart Doris (800)
Warning: To minimize the risk of injury or damage, read both sides of these instructions before
assembling, installing and using. Always keep instructions for future reference by other users.
Laundry
Ladder
For safe use:
To attach to the wall:
Don't leave Laundry Ladder outside when not in use as the unit will naturally deteriorate in
outdoor weather conditions.
No two pieces of wood are exactly the same and some movement should be allowed.
Colour, grain and texture can vary considerably even in the same piece. The random
occurrence of characteristics is an inherent part of the beauty of any natural wooden
product; as are variations in colour and texture.
Whilst Julu make every effort to give high customer satisfaction, if there is an issue with the
product or service, please contact us so that we can try and rectify any problems
Julu

Safety Instructions

Read before Assembling, Installing and Using.
•
Laundry Ladder rope must ALWAYS be secured to the ladder using the rope hook.
•
Keep fingers away from pinch points when opening or closing Laundry Ladder.
•
Do not let children play on Laundry Ladder.
•
Do not place objects that exceed 44 Lbs (20Kg) on Laundry Ladder
•
Regularly check that all screws are securely tightened and spindle is securely
attached and replace if any signs of wear and tear.
•
Check cord is securely attached and replace cord if any signs of wear and tear.
•
Do not place it in a location that will get in people's way when it is open.
•
The Julu Laundry Ladder brackets must be securely fixed to a solid clean wall using
the enclosed screws.
•
For all other types of walls, Julu recommends you seek professional advice from
your local builder or decorator. Some walls use different materials and you may
need to use other attachment methods.
•
Wall coverings such as wall paper may be adversely affected through product use.
• This is not a toy.
Not suitable for
children.
• Be careful not to
pinch fingers.
• Do not exceed
weights of
20kg/44lb

Spindle Attachment

Spindle
• Always secure with
rope hook.
• Always read the
instructions.
The spindle is attached to the inside of
Laundry Ladder for delivery only.
Unscrew and re-position on the
outside of unit, at the bottom of the
back frame either right or left
depending on the preferred side you
are going to operate it from.
The back frame is lower than the front
frame.
See reverse side for stringing and other
instructions and keep all instructions
for future use/reference.
A video for stringing:
'How to string your Laundry Ladder'
can be found on the website at:
www.juluhome.co.uk
