Download
Share
Print this page
  1. Manuals
  2. Brands
  3. AIR-O-LATOR Manuals
  4. Industrial Equipment
  5. ICE-AWAY IA-5
  6. Installation, operation and maintenance instructions

AIR-O-LATOR ICE-AWAY IA-5 Installation, Operation And Maintenance Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
8100-04 Paseo, Kansas City, Missouri 64131
This manual is designed for your use in the installation, operation and maintenance of the Ice-
Away® de-icer. Store this document in an easily accessible location.
The following information is provided to alert persons to potential personal injury hazards
inherent with products.
!
DANGER:
Indicates an eminently hazardous situation which, if not avoided, will result in
death or serious injury.
!
WARNING:
Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury.
! CAUTION:
Indicates a potentially hazardous situation, which may result in minor or
moderate injury.
January 1, 2005
800-821-3177
INSTALLATION
OPERATION
AND
MAINTENANCE
OF THE
ICE-AWAY
DO NOT DESTROY!
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ICE-AWAY IA-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for AIR-O-LATOR ICE-AWAY IA-5

  • Page 1 8100-04 Paseo, Kansas City, Missouri 64131 800-821-3177 INSTALLATION OPERATION MAINTENANCE OF THE ICE-AWAY DO NOT DESTROY! This manual is designed for your use in the installation, operation and maintenance of the Ice- Away® de-icer. Store this document in an easily accessible location. The following information is provided to alert persons to potential personal injury hazards inherent with products.
  • Page 2 SAFETY DATA INFORMATION SHEET DANGER: RISK OF ELECTRIC SHOCK. DO NOT INSTALL THIS EQUIPMENT IN SWIMMING AREAS. THIS EQUIPMENT HAS NOT BEEN INVESTIGATED FOR USE IN SWIMMING AREAS. WARNING: DISCONNECT AND LOCK OUT ELECTRICAL POWER BEFORE ANY SERVICE IS PERFORMED ON THIS DEVICE. WARNING: THE CONTROL PANEL AND UNIT MUST BE GROUNDED.

  • Page 3: Installation

    ASSEMBLY AND OPERATING INSTRUCTIONS For MODEL #IA-5 ICE-AWAY Remove unit from carton - shipped completely assembled. INSTALLATION STEP 1 Remove the Ice-Away from the carton, place on a flat surface. Note that the Ice- Away has two (2) 10-foot suspension ropes already attached to the diffuser.
  • Page 4 MOORING OPTIONS ILLUSTRATION A ILLUSTRATION B A PIECE OF ROPE WILL DO IT! Mounting is simple using the “SLING APPROACH”. Just sling the unit under the boat, between pilings OR anywhere that the most effective results are achieved. ILLUSTRATION C...

  • Page 5: Electrical Connections

    ELECTRICAL CONNECTIONS DANGER: ELECTRIC SHOCK HAZARD. DISCONNECT ELECTRICAL POWER BEFORE SERVICING MACHINE. WARNING: ROTATING PROPELLER COULD RESULT IN SERIOUS IN- JURY, TURN OFF POWER BEFORE SERVICING MACHINE. ! CAUTION: UNIT MUST BE GROUNDED, FAILURE TO CONNECT TO PROPER GROUND COULD RESULT IN PERSONAL INJURY. DETERMINE VOLTAGE OF UNIT (110/120 OR 230/240).
  • Page 6 Franklin Electric Submersible Motor Specifications (60 Hz) Motor Maximum Line to Line S.F. Circuit Breaker Fuse Amp Size Amp Size Model Number H.P. Volts S. F. S.F.Amps Watts Resistance PowerFactor % Standard Time Delay 244301 12.0 1000 1.0-1.3 73.00% 224302 1000 4.2-4.5 73.00%...

  • Page 7: Certificate Of Limited Warranty

    2. What’s Covered Basic Warranty Air-O-Lator warrants to the original purchaser that the equipment delivered by it will be of the kind and quality described in the order and will be free of defects in workmanship, material or factory preparation when operated under normal use and services.
  • Page 8 Franklin Electric motor, stainless steel fasteners, or fountain nozzles). But this warranty does not cover any part that Air-O-Lator did not supply. Nor does this warranty cover the cost of any repairs or adjustments that might be caused or needed because of the installation or use of non- Air-O-Lator parts, components, equipment, or materials.
  • Page 9 Incidental and Consequential Damages Not Covered This warranty does not cover any incidental or consequential damages connected with Air-O-Lator products’ failure, either while under warranty or afterward. Examples of such damages include: • Lost time, Inconvenience; The loss of the use of equipment; The loss of personal or commercial property; The loss of revenue;...
  • Page 11 8100-04 Paseo, Kansas City, Missouri 64131 800-821-3177 MAIL IN FORM WARRANTY REGISTRATION Font’ N-Aire Aquarian Ice-Away Ready ______ Residential _______ ________ Platinum ______ Commercial _______ Gulf Stream ______ Aquaculture _______ Quantum _______ Purchase Date Mo.______ Day______ Year_______ Model No._________________________ Serial No.__________________________ Owner Name Dealer Name________________________ Owner Address...
  • Page 13 NO REPAIRS WILL BE MADE UNLESS AUTHORIZED BY THE OWNER OR AGENT. If Air-O-Lator is unable to contact the owner/agent within 30 days after receipt of the equipment for repair, a “signature required” notice will be forwarded to the owner or agent stating that disposal of the equipment will be made 30 days from the date of the notice.
