Summary of Contents for SmaK Stallion 10.0
- Page 1 SmaK Stallion 10.0 120V INFORMATION & OPERATING INSTRUCTIONS READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE OPERATING THE MACHINE...
-
Page 2: Table Of Contents
Warranty System Features Troubleshooting Chemicals Parts List Tools & Accessories Exploded View Machine Specifications: Stallion 10.0 100H 120V Pump 120 psi diaphragm, with internal pressure switch Vacuum Dual 3 Stage, 185” lift, 107 cfm Heater 1000 watt Solution Tank Capacity... - Page 3 CRITICAL SAFETY INFORMATION & CAUTIONS • To avoid electric shock, do not expose to rain or The acceptable use of this machine is for commercial/professional cleaning, for example, in snow and keep from extremes in temperature. hotels, schools, hospitals, and offices, rather than Store in a heated location.
-
Page 4: Your New Machine
SYSTEM FEATURES: TOOLS & ACCESSORIES: HEAT: The Stallion 10.0 100H has a built-in Use only manufacturer’s recommended tools and heater for the solution. An ON/Off switch accessories. If the spray valve on your cleaning activates the heater. -
Page 5: Views Of Machine
VIEWS OF THE MACHINE: FRONT VIEW REAR VIEW Recovery Tank Access Cord wrap Recovery Hose connects Power Recovery here Cord Tank Drain Pigtail TOP VIEW SWITCH PLATE Heat Pump Vacuum Switch Switch Switch Switches Solution Tank Fill Hole... -
Page 6: Set Up & Operating Instructions
SET-UP AND OPERATION: 1. Before each use, inspect the machine, hoses, 9. Turn on the vacuum. and cleaning tool for cleanliness and completeness, Ensure the spray nozzles on 10. Begin cleaning, following industry accepted the cleaning tool are tight and that the ball practices. -
Page 7: Warranty
If the product fails because of defect or poor workmanship, SmaK Products will pay for the cost of shipping the products to SmaK Products and back to you. If, through our inspection, we determine that there is not defect in the product, or that the problem resulted from causes not within the scope of this warranty, the product will be repaired or replaced only at owner’s request and expense. -
Page 8: Troubleshooting
No power to heating element – thermal fuse is blown; the bimetallic switch is not closing or heat on/off switch is bad; Always use original equipment replacement parts. Contact your distributor for additional information or to arrange for service. SmaK Products 9116 NE 130 Ave STE 106 Vancouver WA 98682... - Page 9 SmaK Stallion 10.0...
-
Page 10: Parts List
Stallion 10.0 Part List Item Item Part No. Description Part No. Description 01-10694-001 Cord Wrap 41-00065 Elbow Solution Tank Cover, ABS 41-00069 Filter, Inlet 41-00530 Exhaust, Connection 40-00400 Switches 01-10693-001 Base 41-09545 Switch Plate 35-00186 Foam Coated Exhaust 01-10696-001 Solution Tank...
