Bed and Breakfast Instructions
A
F
J
D
A) Top of pole with many larger holes
B) Middle section of pole with a tapped hole at
each end
C) Bottom of pole t
D) PVC Ground Socket (Has one machine screw
inserted into the sleeve. A piece of plastic tape
holds the screw in place and the tape should be
removed before installation)
E) Top Perch Rods
F) Hub with brackets and rope attached bolt with
hardware
G) Trays
H) Tray Arms
I) Splice pieces
J) Rope with Crimp
Troyer's Birds' Paradise
I
L
N
M
R
O
HARDWARE BAG
20785 Morris Rd
Conneautville, PA 16406
C
P
H
Q
K
(K) Rope winder with assembled hardware
(L) Top Cap
(M) (4) 1/4 - 20 x 1/4" stainless steel set screws
with a 1/8" allen wrench
(N) (2) 10 - 24 x 1/2" stainless steel set screws
with 3/32" allen wrench
(O) Eye bolt with assembled hardware
(P) (12) ⅜ plastic clips
(Q) (12) #8 x ⅜" machine screw
R) (12) # 8 nut
814-587-2756
B
E
G
Page 1
Advertisement
Table of Contents
Summary of Contents for Troyer's Birds' Paradise Bed and Breakfast
- Page 1 Bed and Breakfast Instructions HARDWARE BAG (K) Rope winder with assembled hardware A) Top of pole with many larger holes (L) Top Cap B) Middle section of pole with a tapped hole at each end (M) (4) 1/4 - 20 x 1/4” stainless steel set screws with a 1/8”...
- Page 2 Bed and Breakfast Instructions Location of a bed and breakfast should be within 10 feet of martin housing. Step 1) Install ground stake (D). Dig a hole 24 inches deep by 6 inches in diameter. Measure and mark 2” from the top of the...
- Page 3 Bed and Breakfast Instructions the 2 tapped holes. Thread into the holes tapped hole. Align the set screw and tighten. your ½-20 x ½” set screws using your 3/32 Next add the bottom section. Its the same allen wrench. Measure and mark the center way.
- Page 4 Bed and Breakfast Instructions nuts. Slip the back piece of the rope winder insert the rope thru the back of the pulley around the pole. Replace the bolt into the and pull the rope over and thru the pulley so...
- Page 5 Bed and Breakfast Instructions It can get a bit tricky holding all the parts, but take your time and you will see its not A Bed & Breakfast too bad. Take the ⅜” plastic clips (P) and slip them onto the ⅜” tray arm (H) exactly as seen ready and waiting in the photo.
- Page 6 flinging crickets your half way there. Now comes the easy part. Do you have a bed and breakfast or did you build your own feeding platform? Lets face it, humans are generally lazy, why fling crickets if we can teach the Mar- tins to eat at one place, and we don’t need to get wet? Well, how can we accom-...
- Page 7 Bed and Breakfast Instructions Troyer’s Birds’ Paradise 20785 Morris Rd Conneautville, PA 16406 814-587-2756 Page 7...
