SW102 Display technical specifications

Product Name：Intelligent OLED display

Part Number：SW102

Write

Checked by

Approved by

文件编号 TOP-SW102-U-01-1.0

版本号

Signature

WWW.TOPOLOGY-TECH.COM

Date

1.0

Table of Contents

Need help?

Do you have a question about the SW102 and is the answer not in the manual?

Questions and answers

Summary of Contents for EKOROWER SW102

Page 1 文件编号 TOP-SW102-U-01-1.0 浙江图谱智能科技有限公司 WWW.TOPOLOGY-TECH.COM 版本号 SW102 Display technical specifications Product Name：Intelligent OLED display Part Number：SW102 Signature Date Write Checked by Approved by Zhejiang Topology Intelligent Technology Co., Ltd WWW.TOPOLOGY-TECH.COM Room 702,Building A, DIC, No.1190 Bin’an Rd. Hangzhou, Zhejiang TEL： 0571-87633029...
Page 2: Table Of Contents
Content Product introduce ..................................4 1 Product name and model 1 Product name and model ..........................4 2 Product Introduction ..................................4 3 Range of application ..................................4 4 Appearance and size ..........................
Page 3 6.4 Walk assist mode 6.4 Walk assist mode ..........................12 6.5 Headlight on/off 6.5 Headlight on/off ..........................12 6.6Power indicator ..................................13 7 User settings ....................................13 7.1 enter setting status 7.1 enter setting status..........................
Page 4: Product Introduce
A. Product introduce 1Product name and model Product name and model Intelligent OLED display, model：：SW102 2Product Introduction  Minimalist design, process without without screw assembly  Super contrast 1.3 -inch monochromatic OLED screen inch monochromatic OLED screen  Excellent outdoor design with with IP65 waterproof ...
Page 5: Display Coding Rules
Display coding rules As shown as above picture, C1 is the manufacture factory code cture, C1 is the manufacture factory code 1701 is the manufacture year and week number is the manufacture year and week number; A means the hardware version means the hardware version;...
Page 6: Product Manual
B. Product manual 1 Specifications ①Power supply：DC 24V/36V/48V /48V ②Rated current：12mA ③Shutdown leakage current：<1uA <1uA ④Screen specification：1.3”OLED OLED（64*128 dots） ⑤communication method：UART UART（default） ⑥Operating temperature：-20°C ~ 60 C ~ 60°C ⑦Storage temperature：-30°C ~ 80 C ~ 80°C ⑧Waterproof level：IP65 2Functional overview ①Four buttons, easy to operate ②...
Page 7: Installation
3Installation ① Open the display lock clip, set the display in the left handlebar (standard handlebar Open the display lock clip, set the display in the left handlebar (standard handlebar Open the display lock clip, set the display in the left handlebar (standard handlebar size:Φ22.2).Adjust to a position easy to operate tighten and fix ).Adjust to a position easy to operate tighten and fix the screw by M3 hexagon by M3 hexagon.
Page 8: Basic Interface
4.2 Basic interface speed levers PAS LEVERS PAS levers Rear speed ① power assist level and walk mode: 0 power assist level and walk mode: 0-4 files assist level, power from low to high are: OFF 4 files assist level, power from low to high are: OFF、ECO、 TOUR、SPORT、TURBO，and WALK mode.
Page 9: Function Interface
① riding time show ride duration. The rest information is the same as basic interface. ride duration. The rest information is the same as basic interface. ride duration. The rest information is the same as basic interface. 4.3 Function interface（II） ①...
Page 10: Mapping The Mobile Phone (Connect To The Mobile Phone App) 4.5 *Mapping The Mobile Phone (Connect To The Mobile Phone App)
basic interface; [ ] select menu；； ③Unit Settings: unit settings of speed speed and mileage ④ wheel diameter information: wheel diameter wheel diameter information: wheel diameter information adapt for the display adapt for the display ⑤This password Settings: users users can change the password or shut down ( can change the password or shut down (turn offthe defaulted password function)
Page 11: Operation
6 Operation 6.1Turn on/off Maintain the normal connection Maintain the normal connection of the display and the controller. Long press (2 seconds) . Long press (2 seconds) button when is display is off. Display button when is display is off. Display shows the boot interface and enters the basic interface s the basic interface to start work.
Page 12: Walk Assist Mode
6.4 Walk assist mode Long press button for 2 seconds, bike entered walk assist mode. When button for 2 seconds, bike entered walk assist mode. When button for 2 seconds, bike entered walk assist mode. When is shown, loose button to exit walk assist mode button to exit walk assist mode .Walk assist mode switch as below pictures (only in the walk pictures (only in the walk assist status)：...
Page 13: Power Indicator
6.6Power indicator When the battery works normal, normal, the battery power shows 5 levels according to the shows 5 levels according to the battery capacity.When the battery power reaches the under voltage warning value, only frame When the battery power reaches the under voltage warning value, only frame When the battery power reaches the under voltage warning value, only frame of the battery icon is displayed and flash to remind the user to charge immediately.
Page 14: User Settings
 Long press (3 seconds） to exit and save the setting status. Select to exit and save the setting status. Select [Exit] on the setting interface, short press to exit and save the setting status. to exit and save the setting status. ...
Page 15: Wheel Diameter Information
left to right, short press to adjust the code value. Choose Exit (after save) to retu hoose Exit (after save) to return to previous level after setting. Interface show as below： Boot again, you need to use a new password to boot, or Boot again, you need to use a new password to boot, or display will automatically shut down automatically shut down after 25s.
Page 16: Speed Limitation Information
7.5Speed limitation information Speed limitation information indicate Speed limitation information indicates the maximum speed allowed in the current system the maximum speed allowed in the current system (only show the changes through the serial port changes through the serial port) Default allowed maximum speed: efault allowed maximum speed: 25KM/H Interface shown as below：...
Page 17: Automatic Shutdown Time
7.7Automatic shutdown time Press to choose automatic shutdown time to choose automatic shutdown time（default 5 minutes），in auto off interface. Press in auto off interface. Press to save and return the setting interface. setting interface. Interface shown as below: 7.8 System information Press to return to setting interface in system information interface.
Page 18: Reset
7.9 Reset Reset, press to choose setting, switch to to choose setting, switch to YES item，short press to restart the display. The parameter reset to the factory state. Press Exit to exit the page and return to previous level. The parameter reset to the factory state. Press Exit to exit the page and return to previous level. The parameter reset to the factory state.
Page 19: Error Information
Normal shutdown and power ower-down will not make the above data clear clear. 9Error information The display can alert the bike failure, failure, if failure detected, the display interface interface will show the error code. Interface shown as below: Error code definition Error code table: Error code Fault description...
Page 20: Wire Definition
"13" shown at speed failure of the temperature of the battery failure of the temperature of the battery check the battery "14" shown at speed failure of the temperature of the motor failure of the temperature of the motor check the motor "21"...
