Setup and Operation

Service Manual

Revision GP-1.01-12.15-1

MotoGP™© Dorna Sports, S.L. 2015

This software is based in part on the work of the Independent JPEG Group.

This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http://www.openssl.org/)

This product includes cryptographic software written by Eric Young (eay@cryptsoft.com)

Table of Contents

Need help?

Do you have a question about the MotoGP and is the answer not in the manual?

Questions and answers

Summary of Contents for Dorna Sports MotoGP

Page 1 Revision GP-1.01-12.15-1 MotoGP™© Dorna Sports, S.L. 2015 MotoGP™ Game Software Copyright 2015 Play Mechanix™ Inc. This software is based in part on the work of the Independent JPEG Group. This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http://www.openssl.org/)
Page 2: Table Of Contents
Table of Contents Safety ................................3 Product Specifications........................... 5 Setup ................................6 MotoGP® Setup Wizard ..........................11 Game Networking ............................13 Online Features ............................15 Maintenance ............................... 16 Diagnostic Menu System..........................17 CoinUp® ............................... 35 Troubleshooting ............................38 Parts ................................41 Electrical Wiring ............................
Page 3 Ensure all connectors mate properly. If connectors do not slip in easily, do not force them. Connectors are often keyed and only connect one way. Check for correct orientation. Page 3 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 4: Safety
Safety OMPUTER The computer contains sensitive components, including a hard drive. Do not handle it roughly. Call your distributor before servicing its internal components. Ask about warranty information as it relates to the PC. Do not turn the PC power switch on or off. It should remain permanently in the ON position. Cycle AC power on or off with the cabinet power switch.
Page 5 Motorcycle Base Dimensions Height – 40.3” (102cm) Width – 35.4” (90cm) Depth – 68.3” (173.5cm) Main Cabinet Dimensions Height – 72.5” (185cm) Width – 43” (109cm) Depth – 30” (75.6cm) Page 5 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 6: Setup
Setup Unpack Carton 1. Place the shipping crate on a flat stable surface. 2. Cut the banding straps and remove the cardboard lid. 3. Lift off the large cardboard container surrounding the cabinet and any shipping cleats. 4. With at least two people and a dolly, remove the cabinet from the shipping pallet. 5.
Page 7 6. Secure the left vacform to the marquee grill, using three #10-32 torx screws, three #10 lock washers, and three #10 flat washers. 7. Repeat steps 4 & 5 for the right vacform. 8. Tighten all screws fully. Page 7 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 8 Setup Install Marquee Topper 1. Locate topper carton and upack. 2. In the carton with marquee topper, find the three ¼-20 x 1.25 torx mounting bolts, three flat washers, and three lock washers. 3. With an assistant, position the topper on top of the cabinet. 4.
Page 9 These prevent the bike seat from moving during shipment. For proper setup and game play, these must be removed in order to allow the bike seat to lean left and right. Page 9 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 10 Setup Verify Cabinet Functionality 1. Verify the voltage in the nearest AC outlet. 2. Verify the AC outlet ground connection is present and working. 3. Open the back door of the cabinet. 4. Near the AC power transformer, verify the voltage selector switch is set for the correct AC voltage.
Page 11 If connecting online, select or setup a location for the cabinet. This will provide tracking/management functionality through coinup.com. It will also allow players to locate the game through bigbuckhd.com. Page 11 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 12: Motogp® Setup Wizard
MotoGP® Setup Wizard Verify Input and Output Functionality 1. Enter the INPUT TESTS menu and verify all switches and inputs function. 2. Enter the VIDEO TESTS menu and verify that video is acceptable. 3. Enter the WEBCAM TEST menu and verify/configure the webcam functionality.
Page 13 Networking Considerations Each MotoGP game ships with a cross over cable for linking 2 games. Optionally, a hub and network cables can be installed to link more games together. Take care to protect exposed game wiring from general foot traffic around the game. Use a conduit or wire way to protect cables, if needed.
Page 14: Game Networking
Game Networking Online Network Setup 1. Set up DSL or cable modem service through an ISP for the location. 2. If connecting multiple games for online play, acquire a network hub with enough ports and the correct number of Ethernet cables to support the desired number of games. Cables and hub are not supplied with the games.
Page 15 Player Loyalty Reports Track earnings gained from online players at your locations. Game Adjustments Online games can have their adjustments modified remotely. Even better, MotoGP games will sync to the adjustments of the primary cabinet at the location. Location Registration Registering your game units to a location helps boost traffic, by allowing players to find them online, using the Coinup®...
Page 16: Maintenance
Maintenance Hard Drive Recovery Symptoms requiring hard drive recovery include:  File Test reports bad or missing files  Game fails to finish loading during startup  After resetting the AC power, an error is reported  You are prompted to insert a boot DVD ...
Page 17 Service exit current menu or cancel Volume Up moves up through menu or setting choices Volume Down moves down through menu or setting choices Page 17 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 18: Diagnostic Menu System
Diagnostic Menu System Menu Screens and Descriptions Main Menu MAIN MENU Setup Wizard Adjustments Audits Online Resets System Information Tests Utilities  Setup Wizard pg 11 - will only appear if setup wizard has not been completed  Adjustments pg 18 - modify various game settings ...
Page 19 Toggle the display of online national leaderboards. On/Off Leaderboards National leaderboards include all online units Operator Toggle the display of online operator leaderboards. On/Off Leaderboards Operator leaderboards include all your online units. Page 19 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 20 Diagnostic Menu System Main Menu Adjustments Online System Adjustments ONLINE SYSTEM ADJUSTMENTS Online Maintenance Hour 4:00 am-5:00 am Use Slow Network Wait Times DB Server Port Automatic File Server Port Automatic Setting Description Default Choices Online The 60-minute period during which online-enabled 4:00 am 24 hours in one Maintenance...
Page 21 Default Choices Brake Toggle the use of the brake On/Off Webcam Toggle the use of the webcam On/Off Air Blower Toggle the use of the air blower On/Off Page 21 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 22 Diagnostic Menu System Main Menu Adjustments Coin Adjustments COIN ADJUSTMENTS Currency Type Dollar Coin Base Unit $0.25 Coin 1 Value $0.25 Coin 2 Value $0.25 DBV Pulse Value $0.25 Service Credit Value $0.25 Setting Description Default Choices US dollar, AU dollar, Pound, Rand, NZ dollar, Euro, CA dollar, Franc, Guilder, Krona,...
Page 23 Service Switch Presses Service Credit Money $0.00 Main Menu Audits System Audits SYSTEM AUDITS Watchdogs Exceptions Bad Traps Maintenance Power Cycles 0 Maintenance Reboots Total Up Time: 0 days, 00:00:00 Page 23 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 24 Diagnostic Menu System Main Menu Audits Game Audits GAME AUDITS Player Starts Continues Continues Offered Multiplayer Games Started Average Game Time 00:00:00 Total Game Time 0 days, 00:00:00 Main Menu Online These menus cover all online interaction with CoinUp®. ONLINE Connection Details and Test Matchmaker Connection Test Online Synchronization...
Page 25 Main Menu Online Software Update This option contacts database and file servers to check for new software updates. Page 25 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 26 Diagnostic Menu System Main Menu Online Online Debug ONLINE DEBUG View Online Permissions Server Details Certificate Details Purge Query Cache Main Menu Online Online Debug View Online Permissions This page displays information regarding permitted online activity. VIEW ONLINE PERMISSIONS Online: ENABLED Registered: ENABLED...
Page 27 Reset High Scores Reset High Score Photos Reset Gameplay Audits Reset Hardware Monitoring Data Factory Reset Main Menu System Information SYSTEM INFORMATION System Details Hardware Monitoring View Game Log Page 27 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 28 Diagnostic Menu System Main Menu Information System Details SYSTEM DETAILS BIOS Vendor: Dell Inc. Version: A06 Date: 03/27/12 Kernel 2.6.39-jl2 Processor Intel® Celleron® CPU G530 @ 2.40GHz Memory 2051176 kb G5 Rev 27523 Library Rev 1079 Engine version 01.20.01 I/O lib 01.01.05 IR Track 03.02.35...
Page 29 The Switch Test menu has a unique exit procedure, because it checks the switches normally used for navigation. To exit the switch test menu, press the test button five times. Page 29 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 30 Diagnostic Menu System Main Menu Tests Input Tests Card Reader Test On swipe, card reader should read the card type and indicate success/failure for track 1 & 2. If results indicate failure, that card might be worn. If results indicate failure across several cards, card reader might be faulty.
Page 31 Lamp Test This page of tests checks for burned-out cabinet lights. Main Menu Tests Blower Test This test checks the functionality of the air blower at various strengths. Page 31 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 32 Diagnostic Menu System Main Menu Tests Sound Tests This checks sound volume and quality. Missing sounds indicated digital flaws. Distorted sounds suggest analog flaws. Lack of sound suggests disconnected or bad cables or speakers. SOUND TESTS 1000 Hz – Stereo (Both Left and Right Channels) 1000 Hz –...
Page 33 Operator and location splits can be adjusted through the CoinUp® webpage. Main Menu Utilities Collections View Credit Card Details VIEW CREDIT CARD DETAILS Attempted Credit Transactions Successful Credit Transaction Total Charged $0.00 Transaction Fees $0.00 Page 33 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 34 Diagnostic Menu System Main Menu Utilities Collections View Coinup Service Details VIEW COINUP FEE DETAILS Online Subscription Service (0.0 days) $0.00 Cell Modem Charge (0.0 days) $0.00 Operations Charge (0.0 days) $0.00 Credit Card Fees $0.00 Total Coinup Service $0.00 Copyright ©...
Page 35 1. Access the CoinUp® Web site at www.coinup.com. 2. Enter the account e-mail address and password to login. FCC Compliance You are solely responsible for FCC compliance on installations. Page 35 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 36: Coinup
CoinUp® Network Configuration Wired Connection – Ethernet Cable 1. Set up DSL or cable modem service through an ISP for online play or setup a local network. 2. Turn off AC power, unplug the power cord, and open the back door. 3.
Page 37 Collections screen and you will not be able to view your collections on www.coinup.com. 5. Split collection with location as usual. Page 37 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 38: Troubleshooting
Troubleshooting Warning: Review safety chapter before making any adjustments to game. General Troubleshooting Problem Possible Cause Solution Game will not power up Game not plugged in. Plug game into outlet. Game not turned on. Turn on main power switch. Game fuse is blown. Check and replace fuse.
Page 39 Check Connection Details and Test internet for an IP and successful pings NAT and Universal Plug n Play fail Router configuration doesn’t Contact IT administrator and/or support network play consult router documentation. Page 39 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 40 Troubleshooting Connection to CoinUp Troubleshooting ® General Connection Troubleshooting Problem Possible Cause Solution Connection Details and Test has IP Firewall is blocking communication Read firewall documentation. address but Test Connection reports with server. Ensure configuration allows ICMP Database Ping failure or File Server Echo.
Page 42: Parts
600-01134-01 CLIP-LED-TMOLD MG-P Blind_Connect_Female Moto GP Blindmate Connect Female Assembly 601-00580-01 PC Wood Cleat 01-1842 MotoGP Header Harness Plate with Grommet 603-00718-91 LED-Tmolding 91” 600-01650-01 Moto GP Rear Cabinet Access Plate Moto-GP Blower Mounting Assembly Moto-GP Blower Mounting Assembly Moto-GP 42 Back Door Assy Moto GP 42”...
Page 44 Parts Motorcycle Assembly Part Numbers Item Part No. Description 603-00665-01-WIDE Moto GP Bike Body Moto-GP-Handle Bar Assy Moto GP Handle Bar Assembly 603-00731-01 Moto GP Bike Right Frame 603-00732-01 Moto GP Bike Left Frame 603-00727-01 Moto GP Bike Right Side Vacform 603-00728-01 Moto GP Bike Left Side Vacform 603-00742-01...
Page 45 Moto GP handle bar mech (w Hard Grey Sno-X Grips) 50-0166-00 807-00010-01 3.5 inch speaker grille 600-01649-01 Moto GP Speedo Blackout Plate 606-01105-01 Moto GP Speedo Blackout Decal Moto GP Keypad Assy Keypad Assembly Page 45 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 46 Parts Tailpipe Assembly Item Part No. Description 608-00198-01 Moto GP Tailpipe 608-00198-02 Tailpipe LED bracket 500-00026-01 Red LED superpuck pcb #8-32 panhd_phillips Phillips Black Screw 91870A148 #6-32x3_8-Flat Tamper Black Taillight Assembly Item Part No. Description 600-01651-01 Moto GP Rear taillight plate 500-00184-13 Taillight –...
Page 47 42” LCD Monitor MT42W-267A 608-00156-02 42” Monitor Frame Assembly Weldment 606-01113-01 Moto GP Monitor Frame Camera Decal Camera-House-Assy Moto GP Camera Assembly LCD Foam Tape 1/16”Tx3/4”Wx120” Total Length Black Foam Tape Page 47 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 48 Parts Moto GP 42” Marquee Assembly Item Part No. Description 600-01561-01-ASSY Moto GP Marquee Screen Weldment 603-00741-01 Moto GP Marquee Vacform Left 603-00739-01 Moto GP Marquee Vacform Center 603-00740-01 Moto GP Marquee Vacform Right 500-00162-20 20cm LED Strip White (with foam tape) 606-01017-01 Moto GP 42”...
Page 49 Moto GP 42” Rio Board Assembly Item Part No. Description 600-01670-01 Moto GP Rio Mounting Plate 500-00040-01 Rio board 500-00194-01 5V, 5A switching Regulator PCB (12v input) 500-00075-01 Blower Motor PCB Page 49 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
Page 50: Electrical Wiring
Electrical Wiring Moto GP 42” Dash Assembly Item Part No. Description 600-01562-01-ASSY Moto GP Dash Screen Weldment 603-00723-01 Moto GP Dash Center Vacform 603-00724-01 Moto GP Dash Right Vacform 603-00725-01 Moto GP Dash Left Vacform #10-32 TORX-Lock-Flat #10-32 Torx #10 Lock Washer #10 Flat Washer Torx 1-1_4-20 Torx 1-1/4 inch, lock and flat washer Copyright ©...
Page 53 303 Paterson Plank Rd. 800 Roosevelt Road, Suite D-103 Carlstadt, NJ 07072 Glen Ellyn, IL 60137 (800) 524-2343 or (201) 438-1300 (866) 646-1975 fax (630) 942-1073 fax (201) 438-4837 Page 53 MotoGP™ Game Software copyright 2015 PlayMechanix™ Inc. All rights reserved.
