Summary of Contents for HTechMT CO600 Series
- Page 1 Operation Manual HTech Messtechnik GmbH, Germany www.htech-mt.de; info@htech-mt.de...
-
Page 2: Table Of Contents
CO600 Coating Thickness Gauge HTechMT CO600 Coating Thickness Gauge Content Overview .......................... 1 Construction Plan ......................1 Packing List ........................2 Before First Use ......................2 On Screen ........................3 Measurement Procedure ....................4 Calibration ........................4 Upper/Lower Limit Setting ..................... 5 Statistics ........................... -
Page 3: Overview
CO600 Coating Thickness Gauge Overview CO600 series coating thickness gauge is designed to determine the thickness of a magnetically non-conductive coating on ferrous substrates, or the thickness of an electrically non-conductive coating on non-magnetic metal substrates. Standards: ISO 2178/2360/2808, ISO 19840, ASTM B244/B499/D1186/D1400,... -
Page 4: Packing List
CO600 Coating Thickness Gauge Packing List 1. CO600 gauge (probe NOT included for separate type) 2. Silicon case 3. Standard film set (NOT for separate type) 4. Zero plate 5. AA battery, 2 pieces 6. Operation manual 7. Certificate Before First Use 1. -
Page 5: On Screen
CO600 Coating Thickness Gauge On Screen Statistics N: Number of measurements; Max: Maximum; Min: Minimum; AVG: Average; σ: Standard deviation; USB: appears when connected with a computer. Battery level, turns red when lower than 20%. Fe: Ferrous substrate; NFe: Non-ferrous substrate Calibration method 2 point calibration, smooth Zero calibration... -
Page 6: Measurement Procedure
CO600 Coating Thickness Gauge Measurement Procedure 1. Long press the On/Off button to turn the gauge on. 2. Check the specimen and select a suitable calibration method. Calibrate accordingly and the latest calibration will be stored and applied as a rule. 3. -
Page 7: Upper/Lower Limit Setting
CO600 Coating Thickness Gauge 2. Procedure of calibration 1) Click “Calibration”, select types needed, for example, “2-point calibration, smooth”. 2) Put selected standard film on zero plate (other substrate may be used according to calibration method) and measure the thickness. 3) If the result differs from that of the standard film, correct it using upward or downward arrow, and then click “Next”. -
Page 8: Statistics
CO600 Coating Thickness Gauge Statistics Statistics is always running, and the analysis is based on the data since the last selection of “Clear and start new statistics”. The results of statistics won’t loss after turning off the gauge. However, only the last five measurement results can be displayed. -
Page 9: Technical Data
CO600 Coating Thickness Gauge 3. Contaminations on the tip of the probe such as paint and dust etc. can be removed by carefully applying a cutter blade. 4. The cable of the probe should be stored properly, and sharp bending should be avoided. -
Page 10: Typical Problems
CO600 Coating Thickness Gauge Economic Basic Standard On-screen statistics ◆ ◆ ◆ Measurement number ◆ ◆ ◆ Maximum value ◆ ◆ ◆ Minimum value ◆ ◆ ◆ Average ◆ ◆ ◆ Standard deviation ◆ ◆ ◆ New batch ◆ ◆ Open batch ◆... -
Page 11: Accessories
CO600 Coating Thickness Gauge 15. Accessories 1. Standard films and zero plates Part number Description CO600-S12.5 12.5 µm standard film CO600-S25 25 µm standard film CO600-S50 50 µm standard film CO600-S125 125 µm standard film CO600-S250 250 µm standard film CO600-S500 500 µm standard film CO600-S750... -
Page 12: Menu Diagram
CO600 Coating Thickness Gauge CO600-FH5 0-5000 µm high temperature ferrous probe CO600-F14 0-14000 µm ferrous probe CO600-NF0.5 0-500 µm non-ferrous probe CO600-NF1.6 0-1600 µm non-ferrous probe CO600-NFR1.6 0-1600 µm rectangular non-ferrous probe CO600-NFH1.6 0-1600 µm high temperature non-ferrous probe CO600-NF5 0-5000 µm non-ferrous probe CO600-NFR5 0-5000 µm rectangular non-ferrous probe... - Page 13 HTech Messtechnik GmbH Von-Waldthausen-Str. 28 45739 Oer-Erkenschwick Germany Tel: +49 (2368) 9040942 www.htech-mt.de Email: info@htech-mt.de...
