- Page 1 CLOUDBOX Quick Start Guide...
- Page 2 Online setup must be complete in order to finish installation and test your system. If you are the account owner, please complete online setup prior to your installation date. Go to Fuelcloud.com and follow the on-screen prompts. Need Help? Videos and more information available at help.fuelcloud.com...
- Page 3 — all other details can be edited at anytime. 4. Add Hardware and Configure Relay Important: To test the app, your CloudBox must be activated and the relay must be configured to your tank.
- Page 4 FuelCloud uses a wireless signal to communicate with the hardware, and your mobile device needs a line of site to the CloudBox to connect and unlock the pump. Select an installation site that is in visual range, and do not install the CloudBox inside or...
-
Page 5: Turn Power Off
Turn power off Turn off all power to the pump at the breaker. Mount Attach the 4 included Mounting Brackets and screws to the CloudBox. Use any available fasteners to mount the CloudBox. Included with CloudBox (4x) - Page 6 Wiring FuelCloud piggybacks AC power off of the input. Your wiring configuration will depend on whether the pump runs on AC or DC power. AC power has a 100-240VAC power range. For power input, attach the appropriate wires (L, N, G) to the designated terminals on the top bank of terminals on the left-hand side of the CloudBox circuit board.
- Page 7 CLASS 2 WIRING TERMINAL INPUT OUTPUT INPUT OUTPUT...
- Page 8 Pulsers Warning: Do not attach AC power to the terminal marked “12V+”. This terminal is for DC active pulsers only. Attaching AC power to this terminal will destroy your FuelCloud board. The wiring configuration for pulsers depends on whether you are using a 2-wire (passive) or a 3-wire (active) pulser.
- Page 9 2 Wire (Passive) Pulser: FU ELCLO UD PU LS E R Pulse Pulse 12v+ Pulse Level 3 Wire (Active) Pulser: FU ELCLO UD PU LS E R Signal Pulse 12v+ 12v+ Level...
- Page 10 Status LED should move from flashing red to yellow. • If no LEDs illuminate: – Verify that the terminals are correctly wired for your power supply. – Verify that there is power coming to the CloudBox. STATUS POWER...
- Page 11 Toggle the bypass switch and verify that the pump can run in bypass mode. • Check that the Pulse LED flashes when running in bypass mode. • Check that the latest version of the FuelCloud app is installed.
