Summary of Contents for ELIMOS RiTa EasyGo
- Page 1 21 Jun 2013 Version File RiTa EasyGo - Quick Installation Guide V 1.0 - ENG ELIMOS S.r.l. Sede legale: via Galvani, 5c - 34133 Trieste - Italy Sede operativa: AREA Science Park - Padriciano 99 - 34149 Trieste - Italy Tel/Fax: +39-040 375 5356 - E-mail: info@elimos.it - Http: www.elimos.it...
- Page 2 QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System PRODUCTS IMPORTANT INFORMATION CE Compliances The manufacturer hereby declares that the RiTa System HW components are compliant with CE Directive specifies in EMC 89/336/EEC. The products are compliant with following regulations: Emission: EN55022, EN55024...
-
Page 3: Table Of Contents
QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System Summary Hardware Overview – EasyGo Control Unit ..................4 LPR Camera – EpCAM ............................6 1.1.1 Install the EpCAM camera .......................... 7 1.1.2 Power Specifications ............................ 7 1.1.3 Environmental conditions..........................7 1.1.4 EpCAM connection cables ........................... 8 1.1.5... -
Page 4: Hardware Overview - Easygo Control Unit
QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System 1 Hardware Overview – EasyGo Control Unit Front View 1. Ventilator: The ventilator on the enclosure is used for air convection and to prevent the equipment from overheating. Do not cover the ventilator. - Page 5 QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System RJ45 LAN Jack Color LED State Condition LAN link is not established Right Yellow On (steady state) LAN link is established On (brighter & pulsing) The computer is communicating with another computer on the LAN...
-
Page 6: Lpr Camera - Epcam
QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System 1.1 LPR Camera – EpCAM Sunshield Wall bracket Camera with bracket Infrared LEDs Camera optics Infrared LEDs Green status LED Light sensor Red status LED Bracket Camera front Technical Documentation – All Rights Reserved... -
Page 7: Install The Epcam Camera
QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System 1.1.1 Install the EpCAM camera The bracket can be adjusted in two different points. Firstly, the bracket allows rotating the ball joint in a 35 degree spatial angle in any direction. Secondly, by rotating the foot of the bracket, this angle can be extended with additional 20°... -
Page 8: Epcam Connection Cables
QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System 1.1.4 EpCAM connection cables The camera is equipped with two cables. The first cable is responsible for the power, trigger and serial connections while the second cable is for communication via TCP/IP. Attention: For cabling, use quality, outdoor-certified cables. -
Page 9: Camera Positioning
Following picture shows the suggested layout for the installation of RiTa EasyGo system: From the point of ANPR/LPR the most important is the size of the characters on the image. -
Page 10: Cabling Easygo 1 Lane System
QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System 3 Cabling EasyGo 1 lane system EasyGo ONE Lane RiTa System To motorized barrier EpCAM or FreeCAM Optional Overview Surveillance Camera To motorized barrier Ethernet network Optional I/O module EasyGo 1 Lane Control Unit... -
Page 11: Default Ip Addressing
QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System 4 Default IP Addressing The installation default IP addressing is configured as follows: Device IP Address Notes Control Unit 192.168.125.100 LAN Port 1 LPR Camera 1 192.168.125.101 Surveillance Camera 1 192.168.125.111 Optional I/O module (EpCore) 192.168.125.120... - Page 12 QUICK INSTALLATION GUIDE RiTa EasyGo– LPR System Notes: ELIMOS S.r.l. AREA Science Park – Padriciano 99 34149 Trieste Tel/Fax: +39 040 3755356 Sales Office Tel/ Fax: +39 0523 498236 E-mail: info@elimos.it vendite@elimos.it http://www.elimos.it Technical Documentation – All Rights Reserved...
