The CountEasy advanced configuration options affect the function and operation of the machine. They are options that
are not normally required to get CountEasy working but do allow for more detailed configuration to be carried out as
well as providing future proofing features.
It is not advisable to change any of the settings of the CountEasy advanced configuration unless you fully
understand the instructions and the implications of changing each option.
This document refers to software version CE2.6 and above. (Shown momentarily upon switch on)
ENTERING ADVANCED SETUP LEVEL 2
Press and hold down the
The screen will momentarily display 'SETUP' and will then read 'GRAMS?'
Now press and hold down the
seconds. The screen will momentarily display 'SETUP 2' and will then read 'GRAMS?'
FINDING YOUR WAY AROUND SETUP
To move between the options use the
To select an option use the
To move back an option or to leave Setup use the
It is important that you understand the function of the above keys whilst in Setup.
The options available in Setup Level 1 are explained in detail in the Configuration Manual provided with your
CountEasy .
Setup Level 1 options are as follows:
GRAMS?
-
OPTIONS?
-
CALIBRATE PACKS?
-
CALIBRATE CUP?
-
A copy of the configuration Manual can be found on the Volumatic website
COUNTEASY ADVANCED SETUP LEVEL 2 OPTIONS
In addition to the Setup Level 1 options as detailed above, the Setup level 2 options are as follows:
NOTE ENABLE?
-
NOTE WEIGHT?
-
COIN ENABLE?
-
COIN WEIGHT?
-
PACK SIZE?
-
PACK TOLERANCE?
-
SET ONLINE?
-
-
CALIBRATE 500g?
RESET OPTIONS?
-
LOAD CURRENCY?
-
www.Volumatic.com
CountEasy
Advanced Configuration Manual
(down) button and the
(down) button and the
button.
button.
ESC
button at the same time for about 4-5 seconds.
button at the same time again for about 4-5
button.
www.volumatic.com
25-201679 CE Advanced Configuration Manual Issue 4.0 Feb 2011
Page 1 of 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Volumatic CountEasy
- Page 1 The CountEasy advanced configuration options affect the function and operation of the machine. They are options that are not normally required to get CountEasy working but do allow for more detailed configuration to be carried out as well as providing future proofing features.
- Page 2 As and when there may be a requirement to use the above configuration option due to the above scenarios further instructions will be added to the Volumatic website. To enter NOTE ENABLE press the...
- Page 3 As and when there may be a requirement to use the above configuration option due to the above scenarios further instructions will be added to the CountEasy website. To enter COIN ENABLE press the...
- Page 4 20p’s that also weigh 500g. You should only ever recalibrate your CountEasy with a 500g weight as a last resort after all other possible reasons for the machine miscounting have been exhausted – refer to the ‘Frequently Asked Questions / Troubleshooting Guide on the CountEasy website on the ‘CountEasy Downloads’...
- Page 5 Now recalibrate the FlexiCup or alternative weighing vessel and all other packs used – refer to the CountEasy Configuration Manual supplied with the machine and then test the machine again. If CountEasy is still inaccurate then contact the Helpdesk, the number for which can be found on the label on the underneath of the machine.
- Page 6 This menu option allows you to re-load the factory data for the currency being used or to load the data for a different currency i.e. changing from using the CountEasy to count Sterling to count Euros. It is important that you are aware that loading a currency will destroy any ‘learning’ that has taken place, any pack calibration that has been done and any changes that have been carried out to center weights and note and coin enables.
