Summary of Contents for Comvision VISIOTECH VC-2
- Page 1 VISIOTECH VC‐2 MANUAL Copyright – Comvision Pty Ltd ...
-
Page 2: Table Of Contents
Software Features ............................ 15 Software installation and operation ...................... 15 Software operations guide .......................... 16 Log on information ............................ 16 Camera information ............................ 16 Time Syncronisation ............................ 16 Other settings: .............................. 17 Enter USB Mode ............................. 18 Trouble Shooting .............................. 19 Unable to Dock ............................... 19 Device restart .............................. 19 Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 2 | P a g e ... -
Page 3: Introduction
This manual is applicable for the Visiotech VC-2 Body Camera. The Visiotech VC-2 is a wearable video recording solution with up to 14 hours of recording time and built-in GPS location recording. With its AES-256 video encryption coupled with Super High-Definition video and incredible low- light capability, lone workers, law enforcement and security agencies can better protect their people and assets. - Page 4 1080p. AUTOMATIC INFRA-RED HIGH OUTPUT NIGHT VISION The Visiotech VC-2 Body Camera is equipped with a low-light HD video sensor that records 2.7k HD colour video and snaps photos at a detailed 32 Megapixels.
-
Page 5: Warning
Lithium Ion battery chargers provide a specific charging voltage and microprocessor current and voltage control. THE BODY CAMERA SHOULD ONLY GET SLIGHTLY WARM DURING CHARGING. If the camera becomes hot, smokes, or gives off an odour during charging, terminate charging immediately and contact Comvision. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 5 | P a g e ... -
Page 6: General Care
If the Body Camera produces smoke, smell, or unusual noise, please turn off the power immediately and unplug the power cord and contact Comvision. If the Body Camera is not working properly, please contact Comvision. Do not disassemble or modify the Body Camera in any way in order to maintain your warranty. -
Page 7: Product Overview
Main features of the Body Camera: 1. Super 2.7K HD Video 2. Wide Angle Lens 3. Built in Wi-Fi 4. AES-256 Encryption 5. Built in GPS 6. Large 4000mAH battery Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 7 | P a g e ... -
Page 8: Product Specification
Wi‐Fi 802.11 a/b/g/n 2.4G Data Port Docking port Interface Protocol RTSP Ruggedised Case The rugged ballistic shell made for law and security agencies is weather resistant and can handle the most extreme conditions. Its rugged clip attaches to any pocket, belt, lapel, collar, placket, and most protective armor. • Light weight 164 Grams (inc battery) • IP66 weather resistant Case • Working temperature ‐20 to +60 Degrees Celsius • 360 degrees Rotatable Clip Dimensions H81mm x W56mm x D27mm Drop‐in Dock Single and 8 Port Docking Stations Available OS Linux with NTK chipset Standard Accessories USB Cable, Drop‐in Dock Charger, Rugged Clip Optional Accessory 8‐Port Docking station (model DS8PVC) Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 8 | P a g e ... -
Page 9: Product Application
PRODUCT APPLICATION The Visiotech VC-2 high-definition Body Camera is a highly integrated device specially developed for the law enforcement industry. The equipment supports photo snap shots, video and audio recording, local storage and infrared night vision. The body camera uses a docking process to charge the body camera batteries and manage the footage on the camera. -
Page 10: Body Camera Buttons
Short In ON state, a photo can be taken by pressing the “Photo key”. press During video recording, a photo can be captured and saved by pressing the “Photo key”. In ON state, long press the “Photo key” to turn on Wi‐Fi. To turn Long WI‐FI off, long press the “Photo key” again. press Note, Wi‐Fi should not be left on to conserve battery life. Function Short In ON state, the Battery life indicator (4 LED’s on the side of the Button Press camera) can be displayed by short pressing the “Function key”. These LED’s automatically turn off after 7 seconds. In ON state, long press the “Function key” to turn on Audio Long recording (without video). Long press again to turn off Audio Press recording. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 10 | P a g e ... -
Page 11: Body Camera Led State Description
0 LED’s ON – 0% charged Pressing the “Function key” brings up the battery life indicator function. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 11 | P a g e ... -
Page 12: Turning The Camera On And Off
Long pressing both the “Photo key” and the “Function key” again will disable GPS function. The orange LED will turn off. Note: Disabling the GPS function will increase the battery life dramatically. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 12 | P a g e ... -
Page 13: Wi-Fi Function
If you are having problems with your device, please try and reset the camera using the reset button on the back of the camera. Note: Use a paper clip to press the reset button. You will hear a "click" after the button is pressed. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 13 | P a g e ... -
Page 14: Product Installation
Order Number Name Number Quantity Visiotech Body Camera Body Camera Clip USB Cable Single Charger Docking base EQUIPMENT UPGRADE Please contact Comvision. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 14 | P a g e ... -
Page 15: Installation And Use Of Management Software For Body Camera
7. Acquisition and modification of other device parameters. SOFTWARE INSTALLATION AND OPERATION Access the software package by downloading from the Comvision web site. Users will need to contact Comvision for a download web link. Files include Cam_manager.exe ... -
Page 16: Software Operations Guide
User/Police ID: Set a 6-digit ID (should be unique for each device for your system). Firmware Version: Will show Firmware version installed TIME SYNCRONISATION Click on “Sync Date and Time” to Sync the time between your PC and the body Camera. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 16 | P a g e ... -
Page 17: Other Settings
Loop Recording: Enable record over older footage once the on-board storage is full Post-Record: Set an amount of time for camera to continue recording after the stop record button is pressed. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 17 | P a g e ... -
Page 18: Enter Usb Mode
ENTER USB MODE Enter the camera USB mode by clicking on the “Unlock Memory Card”. This allows you to access the files on the camera as a normal USB device from your PC. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 18 | P a g e ... -
Page 19: Trouble Shooting
Alternatively, when in the “On state”, restart the body camera by holding the power button down for 3 seconds. After it powers down, press the power button again (for 3 seconds) to start the body camera. Visiotech VC‐2 Manual v1.1 Copyright – Comvision Pty Ltd 19 | P a g e ...
