PRO SERIES TELESCOPE
Get ready for hours of discovery and fun
with your new Dr. Cool Telescope!

Parts List

Your Dr. Cool Telescope should include
all of the pieces shown below. See the
other side of this sheet for assembly
instructions!
If anything is missing or damaged contact
us at: custserv@discoverwithdrcool.com.
6
12
7. Lens Cap
8. Barrel mount
9. Tripod legs (3X)
10. Tripod head
11. Barrel mount disc
12. Tripod stabilizer
14
15
13
16
17
13. Barrel mount lock
14. Vertical micro adj.
15. Horizontal micro adj.
16. Hex nuts (6X)
17. Threaded bolts (3X)
18. Washers (6X)
7
18
