Sonida S61 Instruction

Thanks for purchasing our eye-caring smart table lamp. Please read the instruction carefully before
use. Product specification is the latest information at the time when this user manual is made. No
further notice will be made for any variation.
Structural Function Diagram
Axis of rotation
Support rod
DC power input interface
USB_DC output interface
Installation Step Schematic
At first, the table lamp support is connected with the base and then a M4 bolt shall be screwed up
from the bottom of the base and then tightened with a phillips screwdriver. The installation is
completed if it is shown as the Fig. II.
Functional Description (fig. I)
Key quantity: switch/color temperature switching, 6 keys are for brightness control by sliding
itching.
② Power supply：AC100-240V-50/60HZ power adapter, DC-9V_2.5A output.
③ Wireless charging indicator has the red light on during the charging process. Neither red nor
Instruction for Eye-Caring Smart Table Lamp
(Fig. I)
(Fig.II)
1
Support of table lamp
Luminous zone of lamp panel
Wireless charging area(optional)
Minimal brightness
Timing button
On/Off key
Maximum brightness
6-level brightness adjustment key
Mode button of color temperature
WIFI indicator light(optional)
Wireless charging indicator
