Climaset is under continuous development. There is no warranty about accuracy and reliability of the contents
of this document. Both the described products and document contents may be changed or withdrawn without
any previous notice. There is no responsibility for any damages or loss, even indirectly, howsoever caused.
®
CLIMASET
Interactive Controllers
Copyright © 2005 Climaset. All rights reserved.
SDT
3 / 3x / 3-ir / 3x-ir
To be used with:
Horizontal room fan coils /
Ducted fan coils
- 3-speed fan control
- Simultaneous indication of
room & desired temperature
- Animated screen
- Bilingual
series
Advertisement
Table of Contents
Related Manuals for CLIMASET SDT Series
Summary of Contents for CLIMASET SDT Series
- Page 1 CLIMASET Interactive Controllers Climaset is under continuous development. There is no warranty about accuracy and reliability of the contents of this document. Both the described products and document contents may be changed or withdrawn without any previous notice. There is no responsibility for any damages or loss, even indirectly, howsoever caused.
- Page 2 User’s Guide...
-
Page 3: Table Of Contents
CLIMASET Contents 1. Your Climaset............................4 2. Wall mounted unit ............................ 4 2.1. Keys and infrared sensor ........................4 2.2. Screen elements ..........................5 2.3. Using the menu ..........................6 2.4. Menu functions ..........................6 2.5. Back light ............................7 3. -
Page 4: Your Climaset
CLIMASET 1. Your Climaset Climaset SDT 3/3-ir/3x/3x-ir are designed to work in conjunction with ceiling type horizontal room fan coils/ducted fan coils to maintain the room/building air condition at the comfort level. Each of the mentioned models consists of the following units:... -
Page 5: Screen Elements
CLIMASET 2.2. Screen elements Room temperature: Indicates the current room temperature. Desired temperature: Your desired room temperature. Power status: Air conditioner apparatus is on. Air conditioner apparatus is off. Season setting: The device is adjusted to work in summer. The device is adjusted to work in winter. -
Page 6: Using The Menu
CLIMASET 2.3. Using the menu 2.3.1. Accessing a menu function Scroll with the "Up" or "Down" keys to access the desired menu function. Use "Right" or "Left" keys to adjust the set points (Refer to section 2.1 for "Up", "Down", "Right" and "Left" keys)(Refer to section 2.4 on adjusting set points and their functions). -
Page 7: Back Light
CLIMASET 2.5. Back light Pressing any keys on the wall mounted unit turns on the back light for several seconds. It enhances reading during the night. 3. Remote controller unit (SDT 3-ir / 3x-ir only) The remote controller utilizes infrared light waves to send the commands to the wall mounted unit. The light waves are effective at the maximum distance of 16 meters. -
Page 8: Keys
CLIMASET Press the "Wake up" key (Refer to section 3.2 for the "Wake up" key). The "Stand by" screen appears and the remote controller is functional (Refer to section 3.3.1 for "Stand by" screen). Notice: Do not place objects on top of the remote control after installation of the batteries. Pressing the keys for an extended period of time reduces the battery life. -
Page 9: List Of Status Bar Messages
CLIMASET 3.3.2. Good bye screen If the remote controller is not used for about 3 minutes, it goes to the "sleep mode". Before it sleeps, "Good bye screen" will appear for some seconds. 3.4. List of status bar messages "Ready": Remote controller is ready for adjustments. -
Page 10: Installation Guide
CLIMASET 4. Installation guide 4.1. Mounting the wall mounted unit Position the mounting plate on the wall. Level the mounting plate. Use a pencil to mark the mounting holes. Remove the plate from the wall and drill 3/16" holes in wall. Tap anchors into drilled holes. Reposition the plate and loosely insert two mounting screws into the holes. -
Page 11: Wall Mounted Unit Connectors
CLIMASET 4.4. Wall mounted unit connectors Connector Input / Electrical Description Unit Output Characteristics Phase Input AC220V/50Hz Null Input Null Fan high speed Output AC220V/50Hz terminal Fan medium speed Output AC220V/50Hz terminal Fan low speed Output AC220V/50Hz terminal 4.5. Wiring diagram... -
Page 12: Care And Maintenance
3. Climaset is designed to be used for residential comfort. Do not store it in hot or cold areas. Also it should not be stored in dirty or dusty environment. 4. Do not attempt to open any part of the Climaset. There is no part inside which you can service it. Ask your local dealer for services, if necessary.
