Summary of Contents for Lucas TVS TVVD001HD

Page 1 DASHCAM DASHCAM User Manual User Manual TVVD001HD TVVD001HD...
Page 3: Table Of Contents
CONTENTS PREFAC E ....................... . SAFE TY IN S TR U C T I ON S .
Page 4: Preface
Please refer to this manual before use of the product. The contents of this manual at the time of production are accurate though are subject to change at any given time. Lucas TVS have taken all necessary precautions to ensure that information is correct.
Page 5: Package Contents
Before using this product please check that all following items are present in your package. If there are any omissions, please contact us immediately on: 0333 555 0003. DESCRIPTION QUANTITY Lucas TVS Dashcam TVVD001HD Main Wiring Loom 2.5mm Jack to Female RCA (Video In Cable) Emergency Record Button...
Page 6: Technical Specifications
TECHNICAL SPECIFICATIONS & PARAMETERS TECHNICAL INDICATORS PARAMETER DESCRIPTIONS Size / Weight / Colour L170mm*Ø65mm / 120g / Black 4M physical pixel CMOS image sensor Camera Sensor Seven groups all-glass lens Front: 170° Lens Angle Rear: Depending on the input camera Support CVBS (Composite Video Baseband Signal) Second Camera camera input...
Page 7 TECHNICAL INDICATORS PARAMETER DESCRIPTIONS Power button/ Camera button/ Emergency Recording button/ Reset button/ Upgrade button (Press the key to enter upgrade mode when the power is turned off Button (s) or the card is not present) Note: The upgrade button is located above the SD Card Slot.
Page 8: Overview
TECHNICAL INDICATORS PARAMETER DESCRIPTIONS Less than 1mA Standby Current Note: The vehicle is off and after full charge (within 10 minutes) Optimal Performance Temperature -25° C to 65° C Operating Temperature -40° C + 85° C Storage Temperature -40° C + 90° C OVERVIEW YE LLOW RE D...
Page 9: Camera Features
CAMERA FEATURES FIXING PAD LOCK COVER VENTILATION POWER CORD CAMERA FRONT VIEW REAR CAMERA VIDEO IN DOUBLE SIDED TAPE POWER BUTTON POWER CORD LOCK OUTLET HDMI LEFT VIEW RIGHT VIEW CAMERA POSITION RESET ADJUSTMENT BUTTON RED INDICATOR LIGHT BLUE INDICATOR LIGHT SPEAKER REAR VIEW...
Page 10: B Utto N & I Nd Ic Ator L I G H T S
BUTTONS & INDICATOR LIGHTS POWER BUTTON: Press and hold the power button to start the device. Quick press the power button to take a photograph. Press and hold the power button to lock/unlock the most recent video file when the device boots up. RESET BUTTON: Press Reset to restart the machine.
Page 11: R Ec O R D T Ime Tab L E
Many newer vehicles operate a ‘battery saving mode’ which include ‘timed fuses’ which stay live for several minutes once the ignition has been terminated. Lucas TVS AE recommend that installation is only carried out by a professional auto electrician to ensure accuracy of the installation resulting in prime recording for the end user.
Page 12: O N / Of F O Pe R At I On
Recording schedule if a rear/secondary camera is installed N = Normal E = Event MEMORY CARD CAPACITY AND RECORDING TIME CAMERA AND VIDEO PROPERTIES 128G Camera Res. Front 1080p Camera 25 or 720p Camera Front 720p Camera 25 or 720p Camera NOTE The above figures are only references, numbers are subject to change dependent on memory card...
Page 13: Sm A R Tp Ho N E Ap P S E T T I N G S
SMARTPHONE APP. Lucas TVS Dashcam TVVD001HD links seamlessly to the below App. To download and install the app use the below links: CONNECT THE RECORDER After downloading and installing the App. Turn on the recorder and connect it within the Wi-Fi signal coverage.
Page 14 LIVE PREVIEW Once a Wi-Fi connection has been established click the home page and select ‘Real-time preview’ this will allow you to view live footage. Switch between front and rear camera Click this icon to switch between the front and rear camera (if applicable) If this icon is grey, it is likely that no rear camera has been detected.
Page 15 APP SETTINGS Recording Resolution: • 1080p @ 30 fps (Sharpest Image) • 720 @ 30 fps (Note: 3rd part cameras are set at this resolution) Clip Time: • 1 minute • 2 minutes • 3 minutes...
Page 16 G-Sensor Sensitivity: Gravity accelerations are likely to vary when faced with factors such as; sudden acceleration, uneven road surfaces or emergency breaking. The video file is protected when the system senses a large acceleration/deceleration. G-Sensor sensitivity is used to set the threshold for sensing such fluctuations.
Page 17 Parking guard: Parking Guard detects vibrations whilst the device Is powered down, when a shock is detected the device starts to record (default 25 seconds) The video protection will be cancelled, if the vehicle is started or the power button is activated manually during the parking guard video recording.
Page 18 In the configuration you can modify the devices Wi-Fi name and password. After changing the Wi-Fi name and/or password, the app and the device will be disconnected. You will now need to re-enter the new Wi-Fi and password to connect the device to your smart phone.
Page 19: Tv-Out Interface
LOCAL FILES Video footage downloaded to the local device can be viewed through the devices system file directory. You can also delete or save footage to a designated album. TV-OUT INTERFACE The device supports two TV OUT Outputs showing the below info on screen in addition to live view footage, or playback functions.
Page 20: I N Fo R Mati O N & G U I Da Nce
After the mobile terminal is connected to the recorded Wi-Fi, open the TVVD001HD Dashcam App, and the cellular time will synchronise to the device automatically. Otherwise when the device received a GPS satellite signal, it will begin to synchronise the time.
Page 21 NOTE: Therefore it is important that you back up videos and photo filed to avoid them being removed. • If the device is in the process of shutting down and the ignition is switched OFF, ensure the device is completely powered down before switching the ignition back on. •...
Page 22: T Roub Le S Ho Oti N G
SIMPLE TROUBLESHOOTING ERROR SOLUTION Reset the machine Format the SD Card Doesn’t record normally Change to a genuine SD Card (Class 10) Ensure the SD Card is installed correctly Delete any damaged files from the SD Card Change the resolution Video not clear Ensure the camera lens and window screen are clean Press the reset button to restart...
Page 24 TVS Auto Electrics Ltd Ashroyd Business Park, Ashroyds Way Barnsley S74 9SB sales@lucastvs.co.uk 0333 555 0003 www.lucastvs.co.uk...
