T E E N T E C H

S M A R T WATC H

Operation Manual

HY-CAMW

Table of Contents

Need help?

Do you have a question about the HY-CAMW and is the answer not in the manual?

Questions and answers

Summary of Contents for TeenTech HY-CAMW

Page 1 T E E N T E C H S M A R T WATC H Operation Manual HY-CAMW...
Page 2 Thank you for purchasing the Hype Smart Watch. Please read all instructions carefully before using and retain this manual for future use and reference. PACKAGE CONTENTS • Smart Watch with Built-in Camera • USB Charging Cable • Operation Manual KEY FEATURES •...
Page 3: Smart Watch Features
SMART WATCH FEATURES PRODUCT FEATURES 1. Touch Screen 2. Power / End Call 3. Adjustable Silicone Wrist Strap 4. Speaker 5. Micro USB Charging Port 6. Microphone 7. Return / Home Button...
Page 4 HOME SCREEN Once your smart watch turns on, it will show you the below home screen. 1. Bluetooth Symbol - Indicates watch is paired to a device. 2. Battery - Indicates remaining battery life on the Smart Watch. 3. Time - Shows current time 4.
Page 5 COMPATIBILITY Please note, some features of your smart watch are only available to specific devices. At the top of each section of the manual, compatibility is shown using the two icons below. Only available for Android devices. Available for Android and Apple devices.
Page 6: Bluetooth Pairing
BLUETOOTH PAIRING Make sure your Smart Watch is turned on and fully charged. Make sure Bluetooth is enabled on your smart phone or tablet and your device is discoverable. NOTE: Android users should download and run the “Fundo Companion” App prior to pairing with Bluetooth.
Page 7: Bluetooth Power
In the Bluetooth settings for your smart phone or tablet, search for nearby devices and find your watch. It should appear as “HY-CAMW” HY-CAMW Not Paired Select it to begin pairing. On your smart watch, press “My device,” “Search new devices ”...
Page 8 “194843” is shown on “HY-CAMW”. Cancel Pair Press “Pair” from your Bluetooth Pairing Request “HY-CAMW” would like to pair with your smart phone or tablet. Press “Yes” on iPhone. Con rm that the code “194843” is shown on “HY-CAMW”. your screen on...
Page 9 Pairing is now complete. If you are unsuccessful, press the ”Return” key on the frame of your smart watch to repeat the pairing process. To restart the pairing process, you will first need to turn off “Visibility” and turn off Bluetooth “Power” first. Then turn Bluetooth off on your device and begin from the first step of this section.
Page 10 MESSAGES Bluetooth Phonebook Dialer Messaging Press the Messages Icon on your home screen to view sent and received messages. This App can only be used on smart watches paired with Android devices. BT notice “Please install ””BT Before using, please download the “Fundo Companion” Notice””...
Page 11 MENU LIST Press the Menu Icon on your home screen to see your available smart watch Apps. Your smart watch will begin displaying available Apps. If you are looking for a specific App but do not see it on your screen, swipe left or right on your touch screen to see additional Apps.
Page 12 SETTINGS Settings Anti lost Press the Settings Icon on your Power save Ringtones home screen to adjust settings on your smart watch. SETTINGS QR code “Quick Response Code” will display the Setup QR code. Settings Quick respon.. Time and Date Language Display Please note, this QR code is to be used for quick setup and pairing of...
Page 13: Settings Time/Date
SETTINGS Time/Date “Time and date” will allow you to set the time and date and home city. Settings Time and date Quick respon.. Set home city Time and dat... Date settings Set time Language Set format Display Select “Date settings” to put in the current date. Time and date Set home city Date settings...
Page 14: Settings Language
SETTINGS Language Select “Language” to choose the language shown on your smart watch. The default setting is “English.” Scroll through this list by swiping your finger upwards on your watch touch screen. Find your desired language, and press its name on the touch screen of your watch. In the example below, “English”...
Page 15: Common Settings
SETTINGS Common Settings “Common settings” will allow you to choose your unlock screen clock type, enable the motion sensor features and change the LCD backlight settings. Common settings Settings Unlocking t... Language Motion sen... Display Misc. settin... Common sett... Restore settin... SETTINGS Display Select “Display”...
Page 16 SETTINGS Restore Settings “Restore settings” will allow you to reset all settings on your phone and clear all Bluetooth devices and personal information. It is best to use this feature if you no longer want your smart watch. Settings Language Display Common sett...
Page 17: Power Save
POWER SAVE Settings Anti lost Press the Power Save Icon on Power save Ringtones your home screen to set or turn off Power Save mode. Power Save mode will attempt to put your watch on standby as much as possible to conserve battery life. RINGTONE Settings Anti lost...
Page 18 CALENDAR Alarm Calendar Press the Calendar Icon on your Pedometer Stopwatch home screen to access your calendar. The Calendar will immediately bring you to today’s date, highlighted in light blue. Use the left and right arrows on the top of the calendar to scroll to the previous or the following months.
Page 19 PEDOMETER Alarm Calendar Press the Pedometer Icon on your Pedometer Stopwatch home screen to access your pedometer. Time: Your Pedometer has a built-in 00:00:00 timer and step counter. Step: Press “Start” to start the timer and the step counter. Start Back Swipe right on your screen to check your summary page on the second screen.
Page 20 STOPWATCH Alarm Calendar Press the Stopwatch Icon on your Pedometer Stopwatch home screen to access your stopwatch. 00:00 00:04 Press the left button to start your stopwatch. Press it again to click your stopwatch. The stopwatch will keep going, but the time will freeze for you to read it. Press the right button to reset your stopwatch.
Page 21 CALLS Calls BT Notiﬁer BT music BT camera Press the Calls Icon on your home screen to access your call history. ALARM Alarm Calendar Press the Alarm Icon on your Pedometer Stopwatch home screen to set an alarm. Your smart watch can set up to 5 customizable alarms.
Page 22: Track Name
BT MUSIC Calls BT Notiﬁer Press the BT music Icon on your BT music BT camera home screen to play music from your smart watch. Your smart watch will connect to your smart phone or tablet that is playing music. Once it is connected, you can control media from the screen below.
Page 23 CALCULATOR Sedentary.. Drink Water Calculator Sleep Monitor Press the Calculator Icon on your home screen to access your calculator. A numeric keypad will appear. Enter in your desired calculation and press the “=” button to calculate the result. Press “Clear” to clear your entry. You can press “Back”...
Page 24: Sleep Monitor
SLEEP MONITOR Sedentary.. Drink Water Calculator Sleep Monitor Press the Sleep Monitor Icon on your home screen to monitor your sleep. A timer will appear. Press “Start” when you are ready to sleep. Monitoring time: 00:00:00 Results: None Start Back If you want to reset the sleep timer, press the “Reset”...
Page 25: Phone Book
PHONE BOOK Bluetooth Phonebook Dialer Messaging Press the Phonebook Icon on your home screen to access your contacts list. Please note, you will need to disconnect from “BT music” before your smart watch can access your contacts list. If your smart watch asks you to disconnect, press the Confirm button on the watch frame before proceeding.
Page 26 Your smart phone will indicate it has begun dialing the selected contact. Below is a helpful diagram of available buttons and functions to use during a call. 1. Contact Name Dawn Walker 2. Call Status / Duration Dialing 3. End Call 4.
Page 27 DIALER Bluetooth Phonebook Dialer Messaging Press the Dialer Icon on your home screen to dial numbers from a phone keypad. A numeric dial-pad will appear. Enter the number you wish to dial including 1 + area code. 1234567890 Press the “Delete” button on the bottom right of your watch to delete any mis-entered numbers.
Page 28 BT CAMERA Call logs BT notice BT music BT camera Press the BT camera Icon on your home screen to access the remote shutter button. This App can only be used on smart BT notice watches paired with Android devices. “Please install ””BT Before using, please download the...
Page 29 CAMERA Camera Press the Camera Icon on your home screen to access the built-in 0.08 MP camera. Press “Options” to view and set your photo options.
Page 30 ANTI-LOST Settings Anti lost Power save Ringtones Press the Anti-Lost Icon on your home screen to use the watch and phone tracking feature. Some features of this App can only be used on smart watches paired with Android devices. Please see each sub-section for compatibility before proceeding.
Page 31 Use “Looking phone” if you want your Smart Watch to locate your Android device. It will send a push notification using the “Fundo Companion” App on your Android to have your phone ring. Once your Android is located, you can press the “Return”...
Page 32 ANTI-LOST Anti-lost Anti lost Looking phone Press on “Anti-lost” to set a notification for when your Smart Anti lost Watch is out of range of your Apple or Android smart phone or tablet. Status You have the option to turn this alert On or Off.
Page 33: Sedentary Reminder
SEDENTARY REMINDER Sedentary.. Drink Water Calculator Sleep Monitor Press the Sedentary Reminder Icon on your home screen to set a reminder not to stay seated for too long. DRINK WATER REMINDER Sedentary.. Drink Water Calculator Sleep Monitor Press the Drink Water Reminder Icon on your home screen to set a reminder to drink water consistently throughout the day.
Page 34: Battery Care
BATTERY CARE The lithium-ion battery is built into the device. Do not disassemble the device to remove the battery or attempt to separate it from the device. • When charging the device, please use the enclosed USB charging cable or otherwise ensure that the battery charging conditions are met.
Page 35: Specifications
• Please only use the charger provided by Hype®. • Do not attempt to charge the device if the battery has discharge or emits any substances. In that case, immediately distance yourself from the battery in case of fire or explosion. •...
