Juggernaut Defense Juggernaut.Case Quick Start Manual

1
remove Quick Disconnect Cable Assembly
prior to inserting **critical step**
micro USB can only be
inserted in one direction
5
inspect cable to ensure that the seal is
clean and still attached
2
open door latch to release door
do not press on glass without
only insert device in a clean
device installed dust-free environment
6
connect micro USB with cable facing
toward the left side of the device/case
3
insert device micro USB first to align
home button with case button
do not over tighten screws or
use tools to tighten
7
do not connect with the cable facing to
the right
4
securely close and latch door
refrain from opening door in
dusty or wet conditions
8
hold down middle of cable while
tightening screws
is a
Juggernaut.Case TM
registered trademark of
Juggernaut Defense, LLC
www.JuggernautCase.com
©2016, Rev. B, US Patents
Pending
