USER'S MANUAL FOR
F & Q
Submersible Sewage Pumps
100WQ Series
The F&Q pumps are carefully inspected and tested to ensure operating performance and safety.
However, failure to follow the instructions and cautions in this manual can lead to pump damage
or serious injury. Should questions arise, or start up problems occur, contact your pump distributor
or the F&Q factory.
This manual must be read and understood before installation and maintenance. All installation,
operation and maintenance works must be carried out by qualified personnel in strict accordance
with this manual and must comply with all local, state, and national codes. F&Q Pumps, Inc. shall
not be liable for injury, damage or delays caused by a failure to observe the instructions contained
in this manual.
F&Q PUMPS, INC. : 10617 E. Rush Street, S. EI Monte, CA 91733 (626)455-0884 Fax (626)448-9462
Advertisement
Table of Contents
Summary of Contents for F&Q 100WQ Series
- Page 1 USER’S MANUAL FOR F & Q Submersible Sewage Pumps 100WQ Series The F&Q pumps are carefully inspected and tested to ensure operating performance and safety. However, failure to follow the instructions and cautions in this manual can lead to pump damage or serious injury.
-
Page 2: Specifications
This submersible sewage pump is designed for installation in small lift stations, drainage systems or raw water applications and other light through heavy-duty wastewater services that require solids handling capability to 3’’ in diameter. SPECIFICATIONS Power supply required ……………… 208~230/460V, 60Hz, Three Phase Motor duty …………………………... - Page 3 10. When wiring an electrically driven pump, follow all electrical and safety codes that apply. Refer to the following chart to select the wire size of an extension cord if needed: TOTAL EXTENSION CORD(S) LENGTH IN FEET RATING 0-10.0 10.1-13.0 13.1-15.0 15.1-18.0 CAUTION...
-
Page 4: Pump Operation
PIPING All pipes should be supported independently of the pump to avoid putting undue strain on the pumping unit. A union should be installed in the pump discharge line close to the sump cover that the discharge pipe can be broken and the pump removed from the pit with the discharge pipe intact. -
Page 5: Troubleshooting Chart
TROUBLE SHOOTING CHART Check the chart from time to time. It may offer you the solution(s) to the trouble(s) during operation and maintenance thus saving your time and unnecessary expenses. Symptom Possible Causes Possible Remedies 1. Debris caught in impeller, 1. - Page 6 Limited Warranty F&Q PUMPS, INC. hereby warrants your unit. In accordance with and subject to the provisions herein contained, against defects in material and workmanship under normal use and service when properly connected for a period of 12 months or 1000 hours operation (which ever occurs first), from the date of purchase.
