Summary of Contents for Mausound WALLSOUND
- Page 1 Users and Maintenance Manual UNDERWATER SPEAKER Mod. AKUASOUND PORTABLE AND FIXED MAUSOUND di Roberto Berselli Via E. Salgari, 29 41123 Modena Official language ITALIAN - document dated 04-2016 rev 00.
- Page 2 Edition: September 2011 Revision: 01 All rights reserved by Mausound; the manual may not be reproduced, even in part. The descriptions and illustrations refer to the specific product/system in question. Mausound reserves the right to make any modifications it deems appropriate to the series production at any time.
-
Page 3: Table Of Contents
LIST OF CONTENTS 1 Introduction 2 Presentation 3 Hazards and protection equipment 4 Lifting, transport and storage 5 Installation 6 Starting and stopping the system 7 Maintenance 8 Scrapping and disposal... -
Page 4: Introduction
You may receive occasional revisions and updates for consideration and integration into the manual. Mausound reserves the right to update its products and manuals without the need to notify users of previously supplied products. Notification of proposed updates to the manual or product are in the nature of a courtesy. - Page 5 1.2 G eneral information about the use of the product This manual is designed to provide the user with a general familiarity with the product and the maintenance instructions deemed necessary to ensure its proper operation. Before proceeding to install, service or repair the product, read the manual in full.
-
Page 6: Presentation
PRESENTATION 2.1 i ntended use The product is intended to emit musical sound to be heard underwater. point 2.5 “TECHNICAL DATA”. Example installation of the fixed version: 2.2 n ameplate Citing the model, serial number and year of manufacture of the product assists us in identifying it and providing a quick, precise response to your requests. - Page 7 2.3 p rinciple of operation The product makes it possible to listen to music and sounds underwater (in a swimming pool or at sea) by means of an amplifier connected to an Akuasound portable underwater speaker. Once the amplifier has been hooked up and powered on, and the microphone/ radio/CD/mp3/USB audio is on or playing, the speaker outputs sound which can be heard underwater.
- Page 8 2.2 kg models removable/portable Akuasound model with 8 m/16 m cable fixed Wallsound model with 20 cm cable suction cup model (for smooth walls and surfaces only) N.B. The cable is flexible and waterproof, even at its connection to the speaker (pull it by hand only and with care, only to move the weight of the speaker itself).
-
Page 9: Hazards And Protection Equipment
WALLSOUND Product specifications Outer diameter: 178 mm Thickness: 52 mm Weight: 2.3 kg Maximum applicable power: 100 W rms Impedance: 8 Ohm Output frequency range: 150 Hz to 16 kHz at -10 dB Very low voltage components with 2X1 cable. The product may be hooked up to any audio amplifier. -
Page 10: Lifting, Transport And Storage
ANY WAIVER OF THE ABOVE CONDITIONS MUST BE AUTHORISED IN WRITING BY MAUSOUND CAUTION THE MANUFACTURER IS NOT LIABLE IN ANY WAY FOR UNAUTHORISED MODIFICATIONS WHICH ALTER THE SPECIFIED FUNCTION OF THE DEVICE, AND MODIFY OR INCREASE THE RISKS ATTENDANT ON ITS USE. -
Page 11: Installation
INSTALLATION 5.1 p reparinG the area to be done by the user The user must prepare: • The installation area as required by local occupational health and safety regulations. • The electrical power supply as required by local regulations applicable to the installation area. - Page 12 No masonry work is required for the installation of the removable version with cable. For the fixed WALLSOUND version, the design of the swimming pool must provide recesses for the speakers like those for the in-pool lights. .
- Page 13 5.2.1 E lEctrical hookup CONNECTION: CANNON JACK SPEAKON 1. ground 1. TIP: positive 1+ positive 2. positive 2. SLEEVE: ground 1- ground A proper installation would include not just one underwater speaker: for applications like synchronised swimming, we recommend installing more than one AKUASOUND speaker in the pool.
-
Page 14: Starting And Stopping The System
DO NOT START THE EQUIPMENT UP IF ITS CABLE OR ANY OTHER COMPONENTS ARE DAMAGED The initial adjustments are normally done by Mausound staff or persons authorised by them. Clients wishing to do the work themselves must read this manual with care before proceeding, to ensure they are familiar with the purpose and effect of the commands. -
Page 15: Maintenance
6.3 p ower outaGes Power outages (even transient ones) immediately shut the product off. The product starts up again when power is restored. MAINTENANCE The product has no scheduled maintenance requirements. It should be inspected by the manufacturer during its second year of use, and must be scrapped in a regulatory fashion. - Page 16 Notes: MAUSOUNDdi Roberto Berselli Via E. Salgari, 29 - 41123 Modena cell. 338.2668608 www.mausound.it - e-mail: info@mausound.it...
