The Ultimate Chicken Coop
1: Locate the different components and get the right
BOX #1
Side Board (x6)
Floor Bottom Brace (x1)
Roost Post
Floor Top Brace (x1)
Gable Support Stick (x1)
Floor Ramp (x1)
Long Floor Brace (x2)
Short Floor Brace (x2)
Under Coop Back Panel (x1)
Under Coop Side Panel (x2)
BOX #2
Left Leg (x1)
Nesting Box Panel (x1)
Smart Carts Enterprises LLC –
Right Leg (x1)
Back Panel (x1)
Front Panel (x1)
www.infinitecedar.com
BY Infinite Cedar:
tools.
Roof Panel (x1)
Hardware Kit (x1)
Floor Panel (x1)
Yard Side Panel (x2)
Window (x2)
Yard Roof Panel (x1)
Laying Box Side Wall / Roof (x2)
Roof Gables (x2)
Yard Door Panel (x1)
Yard Roof Panel (x1)
www.smartcarts.com - (207) 591-4250
INSTRUCTIONS
Hardware Kit
2.5" Bolt (x8)
2" Screw (x10)
1.5" Screw (x36)
1" Screw (x9)
Rope Latch (x1) +
screws (x2)
Washer (x16)
Nut (x8)
Roof Panel Latch
(x1) + screws (x6)
Latch Support (x2)
+ 0.75" screws (x4)
Tools Not
Included
Philips Screwdriver
Wrench 7/16"
Powered tool (Not a
must)
Help is available. Please
call
207.591.4250
Advertisement
Table of Contents
Summary of Contents for Infinite Cedar Ultimate Chicken Coop
- Page 1 The Ultimate Chicken Coop INSTRUCTIONS BY Infinite Cedar: 1: Locate the different components and get the right tools. BOX #1 Hardware Kit Side Board (x6) 2.5” Bolt (x8) Floor Bottom Brace (x1) Roof Panel (x1) Roost Post 2” Screw (x10) Floor Top Brace (x1) 1.5”...
- Page 2 The Ultimate Chicken Coop INSTRUCTIONS BY Infinite Cedar: 2:Attach the Floor Braces to the Legs: There are 2 types of legs and it is important that you choose the right ones. Make sure to have one “A” marked leg and one “B”...
- Page 3 The Ultimate Chicken Coop INSTRUCTIONS BY Infinite Cedar: 6: Install the Floor Panel and Nesting Box: Position the plastic Floor Panel making sure that the pre-installed wooded cleat is facing inside the house and under the long cleat of the Front Panel (6.1). The pre-installed wooden cleat should be directly facing the Nesting Box Panel door.
- Page 4 The Ultimate Chicken Coop INSTRUCTIONS BY Infinite Cedar: 10: Create The Roof Support Structure: Position the first Roof Gable over the Front Wall between the 2 legs (10.1). Secure using the 1.5” screws and predrilled holes (10.2). Repeat for the 2 Roof Gable but this time over the Back Wall.
