Summary of Contents for Fym BlueTexGPS
- Page 1 INTEGRATION GUIDE BLUETEXGPS-Mobitex VERSION 2.6 BlueTexGPS Mobitex Integration guide v.2.6...
-
Page 2: Revision History
Added control panel userguide. 2004-12-09 Tobias Nilsson Added example of one pospac18. 2004-12-10 Added certification papers Added vehicle installation advice Added information about pospac collection byte 2005-07-01 Tobias Nilsson Layout update, information about new functions 2006-12-20 and settings. BlueTexGPS Mobitex Integration guide v.2.6... - Page 3 Protocols POSPAC18 MOBITEX communication GPS NMEA v0183 Specification of NMEA v0183 sentences Control panel data protocol Bluetooth link DSUB9 connector Using the control panel Installation advice External sensors Accessories Appendix: Software revision history Antenna performance BlueTexGPS Mobitex Integration guide v.2.6...
-
Page 4: Configuration Options
PRODUCT PRINCIPLE The main aim of the BlueTexGPS is to provide personal navigation and a back office positioning solution combined in one unit. This is achieved by integrating a GPS receiver, a Bluetooth chip and a Mobitex radio modem in the BlueTexGPS. - Page 5 This has the benefit of minimizing the radio traffic and saving precious battery power. The 3 byte payload can be set to any user defined value. In the BlueTexGPS, the payload is used for indicating the status of the unit for the back office system. This status could say “normal operation”, “parked car”or “other obstacle”...
- Page 6 0001 0110 1111 0001 05873 speed: 0000 0000 0 km/h Dir: 0000 0000 temp: 1000 0000 0 celsius rssi: 0010 0000 payload: 0000 0000 0000 0000 0000 0000 GPS-q: valid position extra: 00 000 Not used: MOBITEX COMMUNICATION BlueTexGPS Mobitex Integration guide v.2.6...
- Page 7 Control panel data protocol part of this document. There is no ack message from the server, the network ack is enough to ensure that the messages get through to the server. BlueTexGPS Mobitex Integration guide v.2.6...
- Page 8 5,6: Speed over the ground (SOG) in kilometer per hour. 7: Mode Indicator: A=Autonomous Mode, D=Differential Mode, E=Estimated (dead reckoning) Mode, M=Manual Input Mode, S=Simulated Mode, N-Data Not Valid hh: Checksum GSA - GPS DOP and Active Satellites BlueTexGPS Mobitex Integration guide v.2.6...
- Page 9 Checksum CONTROL PANEL DATA PROTOCOL There is two main commands that the BlueTexGPS respond to. One set command and one get command. The set command contains all settings for the unit. The settings can be set over the bluetooth link, serial interface in DSUB9 or over the air.
- Page 10 BlueTexGPS sends its settings on this format. NAME LENGTH TYPICAL VALUE COMMENTS Start 3 byte 0x46594D(FYM) Battery 2 byte NOT USED Rec man1 3 byte 0x30D5BC Rec man2 3 byte 0x30D5BC Received for future usage Update time 2 byte Payload 1...
- Page 11 End byte SET SETTINGS OVER THE AIR BlueTexGPS can be configured over the air. The message is a data package with fix length, of 110, sent over the mobitex network. Remote configuration has low priority. If BlueTexGPS has other things to do it will not send data back.
-
Page 12: Bluetooth Link
BLUETOOTH LINK The BlueTexGPS is connectable over Bluetooth via the serial port profile. The raw NMEA v0183 data is directly forwarded from the GPS-receiver to the Bluetooth serial port. The GPS data is sent once every second at 9600 bits/second, 8 bit, no parity and one stop bit. -
Page 13: Using The Control Panel
Below is a screendump of the BlueTexGPS control panel. Connect To connect to a BlueTexGPS unit select the serial port that the Bluetooth device give you. Press the Open button and wait. When connected the units manid and the software information will be showed. If you connect to the unit to soon after power on you may get a invalid manid (negative) from the unit. - Page 14 There are tree power on methods, on/off button is default and the unit power on and off by pressing the on/off button at the front of BlueTexGPS. When the unit is configured as motion it starts when motion is detected and power off when there is no motion for some minutes.
-
Page 15: Installation Advice
INSTALLATION ADVICE The BlueTexGPS has a built-in GPS antenna. For optimal GPS performance, the unit should be placed viewing as much clear sky as possible. For example on the dashboard looking out the windscreen, see picture. The green/shadowed area show the optimal reception angle of the GPS antenna. - Page 16 ACCESSORIES ARTICLE NR NAME 888200095 Button sensor 888200095_2 Led sensor 942004 Car charger 245102 Car hold simple 245106 Car hold with external connections 888200095_3 Inductive sensor BlueTexGPS Mobitex Integration guide v.2.6...
-
Page 17: Antenna Performance
Meas2:Mkr1 406.000 MHz 2.595 Start 400.000 MHz Stop 440.000 MHz 1:Mkr (MHz) Ohm 2:Mkr (MHz) 1: 406.000 25.72 25.40 1> 406.0000 2.595 2> 430.000 38.23 -46.52 2: 430.0000 2.806 Fig: Smith chart and VSWR, BlueTexGPS EU. BlueTexGPS Mobitex Integration guide v.2.6...
