DRONE RAINGER - USER MANUAL

Congratulations on buying the Drone Rainger! This is an innovative, digital delay–based tool to inspire

music that's truly hypnotic and powerful.

CONTROLS

Digital delay section (four knobs across the middle)

Level; This decides the amount of delay heard with the signal..

Rate; This decides the speed of the repeats (maximum time is about 1 sec).

Repeat; This decides the amount of feedback.

Volume; This decides the overall volume of the pedal.

Guitar In; set your guitar level here.

Drone In; set your drone level here.

'Overload' LED; This shows when the guitar input signal is high enough to start the pedal overloading

(best set to come on just occasionally). BTW nothing is harmed if it's on all the time.

Drone section (upper half of main panel)

Pitch 1; set this knob to the drone note you need. If turning Pitch 1 gives no change in the note, try

panning Mix to the right or pressing the Mix/Pitch 2 footswitch.

Fine Tune; Adjust this knob to tune the pedal to the music you're playing along to. 12 o'clock is the

closest to concert pitch.

Pitch 2; Set this knob to a second note that you need – maybe the note of a different section of the

track you're playing, or a harmony or octave of Pitch 1, or very slightly out-of-tune with Pitch 1 to hear

the 'beats' between them....

Mix; this changes the balance between the two drone notes.

Interfere 1-2; For the drones, this momentary footswitch decides between an overall tone down drop-

and-rise, or a Pitch 2 only rise-and-fall.

Table of Contents

Do you have a question about the DRONE RAINGER and is the answer not in the manual?

Page 1 DRONE RAINGER - USER MANUAL Congratulations on buying the Drone Rainger! This is an innovative, digital delay–based tool to inspire music that’s truly hypnotic and powerful. CONTROLS Digital delay section (four knobs across the middle) Level; This decides the amount of delay heard with the signal..
Page 2 Dry guitar; This button turns off the delay on the guitar. Footswitches ON/OFF; This footswitch puts the Drone Rainger into the circuit, or bypasses it (with hard-wired true bypass). Mix/Pitch 2; this footswitch toggles between however the Mix knob is set, and Pitch 2 on its own. This facility is probably most useful when Mix is panned hard right;...
