Fastenal FAST Bin 9705080 User Manual page 15

Repeater
Model Number
Regulatory Identifications Numbers
Dimensions
Weight
Power
Operating Temperature
Operating Humidity
External Ports & Connections
Supported Protocols & Regulatory Identification
Numbers
Supported Antennas
Reader
Model Number
Regulatory Identifications Numbers
Dimensions of RFID enclosure (in which Reader is
housed)
Weight of RFID enclosure (in which Reader is housed)
Power
Operating Temperature
Operating Humidity
External Ports & Connections
Supported Protocols & Regulatory Identification
Numbers
Fastenal Company
9705080
FCC ID: 2APK7-9705080V1-0
IC ID: 23979-9705080V10
3.839" W x 3.352" L x 1.5" H
(9.75 cm W x 8.51 cm L x 3.81 cm H)
0.33 lbs (.149 kg)
5.0 VDC, 3.0 A input
60.8° to 89.6° F (16° to 32° C)
20% to 80%
Power
LoRa: 903-914.2 MHz (12500 bps max)
BLE:
LoRa: Flat Patch RF Antenna (Yageo
ANTX100P001BWPEN3)
BLE: Integrated trace antenna in BLE
module
FAST Bin℠ User Manual
Revision 4.0
FAST Bin℠ User Manual
FCC ID: T9JRN2903
IC ID: 6514A-RN2903
FCC ID: WAP2011
IC ID: 7922A-2011
9705082
FCC ID: 2APK7-9705082V1-0
IC ID: 23979-9705082V10
48" W x 18" H x 24" H
(121.92 cm W x 45.72 cm L x 60.96
cm H)
72 lbs (32.66 kg)
5.0 VDC, 3.0 A input
60.8° to 89.6° F (16° to 32° C)
20% to 80%
Power
LoRa: 903-914.2 MHz (12500 bps
max)
FCC ID: T9JRN2903
IC ID: 6514A-RN2903
Page | 14
