1.Safety Precautions and Warnings
To Prevent personal injury or damage to vehicles or the Car Tool, read this instruction
manual first and observe the following safety precautions.
1.When an engine is running, it produces carbon monoxide, a toxic and poisonous gas. To prevent
serious injury or death from carbon monoxide poisoning ,operate the vehicle ONLY in a
well-ventilated area.
2.To protect your eyes from propelled objects as well as hot or caustic liquids, always wear approved
safety eye protection.
3.
Keep cigarettes, sparks, open flame and other sources of ignition away from vehicle. Keep a dry
chemical (Class B) fire extinguisher rated for gasoline, chemical and electrical fires in work area.
4.Connecting or disconnecting test equipment when the ignition is ON can damage test equipment
and the ignition OFF before connecting the Code Reader to or disconnecting the Code Reader from
the vehicle's Data Link Connector(DLC).
5.To prevent damage to the on-board computer when taking vehicle electrical measurements.
always use a digital multi meter with at least 10megOhms of impedance.
6.Keep the car Tool clean, dry and free from oil, water and grease. Use a mild detergent on a clean
cloth to clean the outside of the Scan Tool, when necessary.
2. General OBD-II Information
2.1 What is OBD-II?
OBD-II stands for On-Board Diagnostics, II generation. It is a set of documents issued by SAE and
ISO, which describe the interchange of digital information between on-board emission-related
Electronic Control Units (ECUs) of road vehicles and an OBD-II scan tool. OBD-II also commonly
refers to the physical on-board diagnostic system of a vehicle, which consists of an ECU (or
multiple ECUs), Malfunction Indicator Light(MIL), Diagnostic Link Connector (DLC), and the wiring
that connect the different elements.
2.2 How do I know whether my car is OBD-II compliant?
There are several ways.
1996 or newer model year vehicle sold in the United States
United States legislation requires all cars and light trucks model year (MY) 1996 and newer to be
OBD-II compliant. More information is available on the
2001 or newer model year gasoline vehicle sold in the European Union
Commission Directive 70/220/EEC, Annex I:
Vehicles with positive-ignition engines
With effect from 1 January 2000 for new types and from 1 January 2001 for all types, vehicles of
category M1, except vehicles the maximum mass of which exceeds 2500 kg, and vehicles of
category N1 class I, must be fitted with an on-board diagnostic (OBD) system for emission control
in accordance with Annex XI. [...]
Note that here "European Union" means countries which were members of the EU in 2000.
2004 or newer model year diesel vehicle sold in the European Union
Commission Directive 70/220/EEC, Annex I:
Vehicles with compression-ignition engines
Vehicles of category M1, except
- vehicles designed to carry more than six occupants including the driver,
- vehicles whose maximum mass exceeds 2500 kg,
from 1 January 2003 for new types and from 1 January 2004 for all types, must be fitted with an
- 1 -
1
- 2 -
EPA's website.
