* Shown with optional outdoor cover
Self-Contained
Remote
Length
Height W/condensing unit
Height W/O condensing unit
Depth
Sections
(Dimensions are +/-1/4")
• Specification subject to change without notice
100-1S+35
R-100-1S+35
R-140-1S+35
48"
88"
75"
60"
2
Step-In-Refrigerators
• PRODUCT SPECIFICATIONS SHEETS
140-1S+35
150-1S+35
R-150-1S+35
66-1/2"
88"
75"
60"
2
48"
88"
75"
90"
3
Advertisement
Related Manuals for Howard McCray R-100-1S-35
Summary of Contents for Howard McCray R-100-1S-35
- Page 1 * Shown with optional outdoor cover Self-Contained Remote Length Height W/condensing unit Height W/O condensing unit Depth Sections (Dimensions are +/-1/4”) • Specification subject to change without notice Step-In-Refrigerators • PRODUCT SPECIFICATIONS SHEETS 100-1S+35 140-1S+35 R-100-1S+35 R-140-1S+35 48" 66-1/2" 88" 88"...
- Page 2 Standard Specifications and Optional Features CONSTRUCTION UL Classified to ANSI/NSF 7 Embossed aluminum Two or three section connection for easy installation CFC free foamed in place insulation Heavy duty hardware Cam lock technology INTERIOR Embossed aluminum Heavy gauge re-enforced floor Evaporator installed inside unit EXTERIOR Embossed aluminum...
-
Page 3: Technical Data
Model # Sizes Length Height Depth Section Cubic Feet Gross Weight Length Height Depth Section Cubic Feet Gross Weight Length Height Depth Section Cubic Feet Gross Weight Length Height with unit Depth Sections Gross Weight Operating temperature Refrigerant Compressor size- HP System type Air defrost BTU’s at +20°... - Page 4 Technical Data • Side View • Plan View 48.000 1.125 DRAIN LINE CAP 43.500 90.000 24.500 150 STEP IN 24.063 A Division of HMC Enterprises LLC • (215) 464-6800 • 1-800-344-8222 • Fax (215) 969-4890 • E-Mail: sales@howardmccray.com • www.howardmccray.com 30.000 60.000 85.500...
- Page 5 * Shown with optional outdoor cover Self-Contained Remote Length Height W/condensing unit Height W/O condensing unit Depth Sections (Dimensions are +/-1/4") • Specification subject to change without notice • PRODUCT SPECIFICATIONS SHEETS 100-1S-5 140-1S-5 R-100-1S-5 R-140-1S-5 48" 66-1/2" 93" 93" 75"...
- Page 6 Standard Specifications and Optional Features CONSTRUCTION UL Classified to ANSI/NSF 7 Embossed aluminum Two or three section connection for easy installation CFC free foamed in place insulation Heavy duty hardware Cam lock technology INTERIOR Embossed aluminum Heavy gauge re-enforced floor Evaporator installed inside unit EXTERIOR Embossed aluminum...
- Page 7 Model # Sizes Length Height Depth Section Cubic Feet Gross Weight Length Height Depth Section Cubic Feet Gross Weight Length Height Depth Section Cubic Feet Gross Weight Length Height with unit Depth Sections Gross Weight Operating temperature Refrigerant Compressor size- HP System type Defrost per day (24 hours) BTU’s at -25°F Evap.
- Page 8 Technical Data • Side View • Plan View 48.000 1.125 DRAIN LINE CAP 43.500 90.000 24.500 150 STEP IN 24.063 A Division of HMC Enterprises LLC • (215) 464-6800 • 1-800-344-8222 • Fax (215) 969-4890 • E-Mail: sales@howardmccray.com • www.howardmccray.com 30.000 60.000 85.500...
