Surge Counter & Smart Detector
Menu of Smart Detector User Manual
Model & Ordering Code
Technical Data
Status Description, LCD Display Description
NO/NC RS485_ID Setting Steps
WTH-CS/RS485 Connection Diagram
WTH-CS/RS485/AC-R Connection Diagram
WTH-CS/RS485/AC Connection Diagram
Inductance Coil Connection Diagram
Modbus Mode Application
Modbus Address Description
Smart Monitoring System
Cloud Service
FAQ & Help
Download WatchfulEyE Official App
Remote Monitoring Application
WTH-CS/RS485 Series
MODBUS
Extended Application
MORE
www.watchfuleyesolutions.com - Page A0 - Back to TOP -
A1
A2
A3-A4
A5
A6
A7
A8
A9
B1
B2
C1
C2
D1
D2
E1-E5
Advertisement
Summary of Contents for WatchfulEye WTH-CS/RS485 Series
- Page 1 WTH-CS/RS485/AC Connection Diagram Inductance Coil Connection Diagram MODBUS Modbus Mode Application Modbus Address Description Extended Application Smart Monitoring System Cloud Service MORE FAQ & Help Download WatchfulEyE Official App Remote Monitoring Application E1-E5 www.watchfuleyesolutions.com - Page A0 - Back to TOP -...
- Page 2 Surge Counter & Smart Detector Paperless Datasheet Going green and protecting environment is manufacturers' responsibility. Each WatchfulEyE product has a link of downloading data sheet on its enclosure: http://datasheet.watchfuleyesolutions.com/USR127325.html Model & Ordering Code Model Ordering Code UPC/EAN Code WTH-CS/RS485 USR121084...
-
Page 3: Installation Instruction
Surge Counter & Smart Detector Application Range WTH-CS/RS485/AC series surge counter is used to test and record the discharge frequency of the surge protector ( record the surge current rush frequency beyond certain degree) and SPD remote contacts monitoring, which is convenient for users to do statistics and analysis on the surge situation in specific area. - Page 4 Surge Counter & Smart Detector WTH-CS/RS485 Series Dimensions Detector Status Description Power (green): Power indicator, when the power is turned on, the indicator light is on Data (orange): Data sending indicator, when there is data sending, the indicator flashes Alarm (red): The alarm indicator light, or when the number of surges increases, keeps on, press the Reset button to reset the light off;...
- Page 5 Surge Counter & Smart Detector LCD Display Description LCD display 0-9 numbers and A-F letters, check the following table: Modbus Mode: RS485 ID, Surge Counts I. Turn on the power, the LCD screen first displays the RS485 address (factory value 001), and then displays the number of surges, the screen keeps displaying this value II.
- Page 6 Surge Counter & Smart Detector Setting Steps 1. When ALARM indicator flashes frequently, short press RESET, switch to NO/NC, default: 0 (NO: normal, NC: fault) 2. When Modbus indicator flashes frequently, short press RESET to set RS485 ID address (RS485 ID: 1-247) 3.
- Page 7 Surge Counter & Smart Detector WTH-CS/RS485 Connection Diagram www.watchfuleyesolutions.com - Page A6 - Back to TOP -...
- Page 8 Surge Counter & Smart Detector WTH-CS/RS485/AC-R Connection Diagram Power supply (100-240VAC or USB-5VDC): When the L-N power cord is connected, the LED light is on (you can also choose to connect the USB power adapter) www.watchfuleyesolutions.com - Page A7 - Back to TOP -...
- Page 9 Surge Counter & Smart Detector WTH-CS/RS485/AC Connection Diagram Power supply (100-240VAC or USB-5VDC): When the L-N power cord is connected, the LED light is on (you can also choose to connect the USB power adapter) www.watchfuleyesolutions.com - Page A8 - Back to TOP -...
- Page 10 Surge Counter & Smart Detector Inductance Coil Connection Diagram www.watchfuleyesolutions.com - Page A9 - Back to TOP -...
- Page 11 Surge Counter & Smart Detector Inductance Coil Connection Diagram A: If the grounding wire can penetrate the magnetic ring, and Imax of the surge protector is less than 80kA B: If the grounding wire cannot penetrate the magnetic ring, or Imax of the surge protector is greater than 80kA, use the shunt connection method www.watchfuleyesolutions.com - Page A10 - Back to TOP -...
- Page 12 Surge Counter & Smart Detector Server Modbus Networking System Diagram Test Steps Step 1: Modbus (Page A6) Step 2: USB Power (Page A6 | Page A7) Step 3: NO/NC (Page A5) Step 4: RS485 ID (Page A5) Step 5: RS485 connected to the computer (Page A6 | Page A7) Step 6: Download software Step 7: Test read data www.watchfuleyesolutions.com - Page B1 - Back to TOP -...
- Page 13 Modbus Address Description Communication Protocol: Modbus RTU Baud rate: 19200 (Customized: 4800/9600/19200/38400) Data bits: 8 bit Parity Check: none Stop bit: 1 bit 03 Read Holding Register Address Description Read/Write Data Type Length System reservation Integer Device address high position Integer Device address low position Integer...
- Page 14 Cloud Service www.greenspd.com Remote Monitoring System - A Cloud Based System Introduction of Cloud service management 1. Unattended operation: Through any computer connected to the Internet , Log in on the cloud platform to view the system mode, achieving remote monitoring office work. 2.
- Page 15 Cloud Service www.greenspd.com Cloud Service Log on Demo user name: 2010cafe or bundled E-mail: service@greenspd.com Password: watchfuleye www.watchfuleyesolutions.com - Page C2 - Back to TOP -...
- Page 16 Cloud Service www.greenspd.com The monitoring webpage displayed after log in Roll down to view more node information displays www.watchfuleyesolutions.com - Page C3 - Back to TOP -...
- Page 17 Cloud Service www.greenspd.com Surge protector fault alert page display If "Alarm LED" status displays "abnormal", the text turns red and it contains an email alert sending function If "Bunlded E-mail" or "Share to E-mail" is set, an E-mail alert is sent to the corresponding mailbox Alert sent by Email www.watchfuleyesolutions.com - Page C4 - Back to TOP -...
- Page 18 Surge Counter & Smart Detector FAQ & Help (1/2) 1. What should I do if I can't find the paper manual in the product packaging? Watchful Eye products is committed to going green with paperless data sheets. On the left side of each product enclosure is an engraved link with URL for downloading paperless data sheet and QR code of the website.
- Page 19 Surge Counter & Smart Detector FAQ & Help (2/2) 5. I have question for Surge Counter how the minimum of Input Current for testing? Surge count test of minimum input current: It is tested in the factory with a 1.2/50μs + 8/20μs combination wave generator If it is only to test the digital display of the surge count, a 10μF 400V capacitor can be used, refer to the following steps Note: This method cannot simulate 8/20μs surge waveform.
- Page 20 Surge Counter & Smart Detector Download WatchfulEyE Official App To learn about more products and updates from company, please scan QR code to download the official App: After-sale Services Watchful Eye provides a 5-year quality warranty globally. I have a question...
- Page 21 Smart Surge Protector & Smart Detector Wi-Fi Networking System Diagram www.watchfuleyesolutions.com - Page E1 - Back to TOP -...
- Page 22 Smart Surge Protector & Smart Detector Monitoring Server Network System Diagram Combined Model Model Ordering Code UPC/EAN Code WTH-CS/F-D USR127209 www.watchfuleyesolutions.com - Page E2 - Back to TOP -...
- Page 23 Smart Surge Protector & Smart Detector Monitoring Server Expansion Cloud Service System Diagram Combined Model Model Ordering Code UPC/EAN Code WTH-CS/F-D USR127209 WTH-225/LAN US127301 www.watchfuleyesolutions.com - Page E3 - Back to TOP -...
- Page 24 Smart Surge Protector & Smart Detector Server Modbus Networking System Diagram www.watchfuleyesolutions.com - Page E4 - Back to TOP -...
- Page 25 Smart Surge Protector & Smart Detector Independent Cloud Service Networking System Diagram Combined Model Model Ordering Code UPC/EAN Code WTH-225/LAN US127301 www.watchfuleyesolutions.com - Page E5 - Back to TOP -...
