Summary of Contents for United Care OpeMed Tilly
- Page 1 USER GUIDE Tilly Floor Hoist OpeMed (United Care) Ltd www.united-care.com +4 4 (0)1252 758 858 infouk@united-care.com...
-
Page 2: Table Of Contents
Bi-Annual Maintenance 4.1.4 Yearly Maintenance Inspection Finding and Correcting Malfunctions ..................Parts List for the Tilly ....................... Table of Standard Slings ......................5 Appendix Warranty Provisions ......................... Removal of Parts About United Care Contact EG- Declaration of Conformity ....................REF0518-2... -
Page 3: This Manual
• From and to the floor. The difference between this hoist and with the United Care Wendy Hoist is that the Tilly is more compact. The Wendy has a larger range and has more options such as integrated weighing scales for example. -
Page 4: Points Of Attention
• Service and maintenance to the hoist is only permitted by • It is advisable to use a sling supplied by United Care. demonstrably authorized persons. Always contact United Care if you intend to use a different type of sling. -
Page 5: Description
Description Tilly Overview Technical Data The components from figure 1 are further described in their own section. Specification of the Tilly basic Total Weight 45kg Chassis pg.6 - 2.7 Capacity 160kg Lifting Arm Sound Pressure Lift 48dB Lifting Motor pg.6 - 2.6 Belast poten spreiden 52dB Battery... -
Page 6: Hand Control
2 Description 2.4.1 Emergency Stop Hand Control By pressing the red emergency stop button (figure 2), the hoist immediately stops moving. The Tilly basic can be operated with the hand control and on the You can release the emergency stop by turning the knob. control box. -
Page 7: Charging The Battery
2 Description Lift Motor The engine is a strong and robust engine with a very low noise 2.5.1 Charging the Battery level. It is equipped with an emergency lower button on the top. By turning the knob you can lower the lifting arm down when the hoist Batteries are charged with the internal battery charger in the stops working. -
Page 8: Cradle
2 Description 2.10 Slings Cradle When lifting, the user seeks place in a sling and is attached to the yoke with clips or loops. There are different types and sizes of The Tilly has a cradle. The cradle is a construction to which the sling slings, each with their own application (§4.4 p.18). -
Page 9: Shapes And Sizes
(with which the Every United Care sling has a label on which clip is attached to the sling) is not twisted. the washing instructions are displayed. Such Grasp the strap under the clip of the sling and pull it a label is shown in the picture on the right. -
Page 10: Use
3 Use • Then apply the other leg slip in the same way. • If necessary, pull the main side of the sling up to the correct height. The sling is now around user. Introduction 3.2.2 Applying the Sling from a Laying Position Check the Tilly before use on the following points: •... -
Page 11: Applying A Toileting Sling
3 Gebruik Hoisting with the Tilly Applying a toileting sling 3.2.3 Before hoisting, place the cradle Fit the toilet sling in the same way as the standard sling, but with in the position in which the user the following points of attention: is to be lifted. -
Page 12: Driving
3 Use Driving Do not lift the user higher than necessary when moving the hoist. When you want to start driving, put the hoist in a half lifted position. The cradle should also be in a half-sitting and half-laying position. 3.4.1 Driving the Hoist •... -
Page 13: Maintenance
According to NEN7506, a hoist must be serviced once a year. 4.1.2 Weekly Maintenance This must be done by United Care or another competent authority. United Care offers you the possibility to have your The following operations can be performed by users on a hoist thoroughly inspected once a year, through the Periodic weekly basis. - Page 14 Motor faulty Replace the motor Battery drains quickly Battery needs replacing. Replace the battery. If the error table below does not resolve the complaint or if in doubt, do not use the Hoist / sling and contact United Care. REF0518-2...
-
Page 15: Parts List For The Tilly
4 Maintenance Parts List Parts List for the Tilly with Electric Leg Adjustment No Description Art.nr. Description Art.nr. Lift Motor La40, 250mm 11101851 Plug Sleeve red, Ø4 17103250 Leg Adjustment Motor La23, 30mm 11101440 Six Sided Bolt M10x60 11100300 Control box 11101500 Six Sided Bolt M10x65 11100970... - Page 16 4 Maintenance Parts List Parts List for the Manual Cradle No Description Art.nr. Description Art.nr. 40 Turn Head, White 32300720 Cap 12, white 11100680 41 Turn Axis 32202160 Fill Ring 15x1,5 (26) 11101410 42 Cardan Bracket 11202040 Adjust Bolt M8x10x40 11100760 43 Bus 15 L=38,5 32202320...
- Page 17 Maintenance Parts List Parts List Two Point Spreader Bar No Description Art.nr. Description Art.nr. 60 Two Point Spreader Bar 11101410 Cover Cap M10, white 32103200 61 Cardan bracket 11202040 Adjust Boly M8x10x40 11100760 62 Bus 15 L=10,5 (rvs) 11200671 Locknut M8 12100710 63 Six-Sided Bolt M10x60 11100300...
- Page 18 Maintenance Parts List Parts List for the Electric Powered Cradle Pos Naam Art.nr. Pos Naam Art.nr. 70 Powered cradle motor, stroke 200, gray 32109000 Axle circlip Ø20 10101840 71 Jack plug male 32107140 Fit bolt set 34mm 11400430 72 Jack panel plug female 32109030 Fit bolt set 26mm 11400390...
-
Page 19: Table Of Standard Slings
Maintenance Colour Code Size Crown to bottom Sling Size Table Purple 45-60 cm Brown 60-80 cm The last number and letter of the article number represent the 80-87 cm dimensions (X) of a sling and the type of attachment (Y). The dimensions range from 0 to 6 (see 2.10.4 page 14). -
Page 20: Appendix
United Care is a company that focuses on services and products for people who are involved in carrying out transfers on a daily basis. The starting point is the mobility of the user: working together with carers and users on solutions that preserve and even improve the mobility of the users. - Page 21 NEN-EN-ISO 14971 ISO 10535 NEN-EN-60601-1 NEN-EN-60601-1-2 (EMC) NEN-EN-ISO 15223: 2012 NEN-EN 12182: 2012 On behalf of: United Care Products BV, Place and Date : Groningen, 19 april 2018 Name and Position: Jan Stevenson, directeur Signature: REF0518-2...
- Page 22 OpeMed (United Care) Ltd www.united-care.com +4 4 (0)1252 758 858 infouk@united-care.com Clockhouse, Dogflud Way, Farnham, Surrey, GU9 7UD United Kingdom United Care manufactures and installs high-quality ceiling hoists and patient handling equipment for the hospital, nursing home and domestic environment REF0717-2...
