Hotpoint HTS18IBSBB Dimensions And Installation Information

HTS18IBS – Hotpoint
®
Front View
A B
Specification Created 10/05
410302
'94 TMNF Refer
®
17.9 Cu. Ft. Top-Freezer Refrigerator
C
D
Top View
H
G
E
F
Note: Before installing, consult installation instructions packed with
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
Width (in.) G
Width with door open 90° with door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
product for current dimensional data.
Total volume and shelf
area are calculated by Listed by
the Association of Home Underwriters
Appliance Manufacturers' Laboratories
R
standards.
66-5/8
66-1/8
27-1/2
30-1/4
32-1/8
58-1/8
29-1/2
32
1/8
1
1
R
