Summary of Contents for TMEIC TMdrive-XL Series
- Page 1 TMdrive TMdrive -XL Series Family -XL Series Family ® ® Product Application Guide Product Application Guide solar power metals cranes mining testing oil & gas cement inverters generation...
- Page 2 TMdrive-XL Series 30 MVA 8 MVA 20 MVA 15 MVA Three different inverter modules for The TMdrive XL series family of variable frequency drives (VFD) provides this architecture, three per VFD: the high power levels and speed required to drive large motors that power rotating machinery used in the Oil &...
- Page 3 XL Drive Family Power Expansion Higher Power Levels. The XL VFDs can be run in parallel to produce higher power levels than single XL Drive Power Levels, Single Bank Multiple Banks, Max banks. Two, three, or four banks can be combined TMdrive-XL85 30 MVA (39,000 hp) 120 MVA (156,000 hp) to obtain the desired power.
-
Page 4: Motor Control
TMdrive-XL Series TMdrive-XL55 – 8 MVA Frame Power Rating: 8 MVA, expandable to 16 MVA Output Voltage: 6.6 kV Output Frequency: Rated 50-60 Hz, 50 to 250 Hertz option Dimensions: Width 6.5 m Height: 2.5 m Motor type: Synchronous or Induction Insulated Gate Bipolar Transistor (IGBT). -
Page 5: Power Circuits
TMdrive-XL75 – 20 MVA Frame Injection Enhanced Insulated Gate Transistor (IEGT). Rated 4,500 Volts, 2,100 Amps Dimensions: Width 9.4 m Power Rating: 20 MVA, expandable to 80 MVA Height: 2.7 m Output Voltage: 6 kV Motor type: Synchronous or Induction Output Frequency: Rated 50-60 Hz, 50 to 250 Hertz Power Input/Output Power Circuits... - Page 6 TMdrive-XL Series TMdrive-XL85 – 30 MVA Frame drive-XL85 – 30 MVA Frame Gate Commutated Thyristor (GCT) with driver board. Rated 6,000 Volts, 6,000 Amps - the world’s largest switching device Dimensions: Width 8.1 m Power Rating: 30 MVA, expandable to 120 MVA Height: 2.6 m...
- Page 7 TMdrive-XL80 – 15 MVA Frame Gate Commutated Thyristor (GCT) with driver board. Rated 6,000 Volts, 6,000 Amps - the world’s largest switching device. Power Rating: 15 MVA, expandable to 30 MVA Output Voltage: 3.8 kV Output Frequency: Rated 50-60 Hz, 50 to 200 Hertz option with derate above 100 Hz Dimensions: Width 4.8 m;...
- Page 8 Web: www.tmeic.co.jp TMEIC. TOSHIBA MITSUBISHI-ELECTRIC INDUSTRIAL TMEIC Corporation does not accept, nor imply, the acceptance of any liability SYSTEMS with regard to the use of the information provided. TMEIC Corporation provides (Beijing) CORPORATION...
