Pressac Sensing 60.CO2 SLR TMP HUM.868 Quick Start Manual

Product Installation

It is recommended the Pressac Sensing CO Sensor is installed in an environment where:
2
1. The local CO level is representative of the complete area being measured i.e. do not place the unit close to
2
a frequently opened window or A/C unit.
2. A source of either natural or artifi cial light is available during the hours when the building is occupied (due
to the unit being solar powered).
Installation of backplate
The Pressac Sensing CO Sensor is designed to be wall mounted. For ease of
2
installation it is supplied with a backplate that can be mounted on the wall
prior to installation of the CO Sensor itself.
2
The backplate can be wall mounted either using the screws and rawlplugs
provided, or alternatively it can be mounted over an existing 'pattress' box
using the appropriate machine screws. (not provided).
Installation of unit on backplate.
BEFORE FINALLY FIXING THE SENSOR ON THE BACKPLATE, ENSURE THE UNIT HAS BEEN SET UP AND
COMMISSIONED AS PER THE PRODUCT OPERATION SECTION.
The CO Sensor will latch onto the previously mounted backplate via the latches on the top of the unit.
2
Once latched, the securing screw at the bottom of the backplate can be tightened.
Learn More
For the complete product User Guide, data sheet, video tutorials and product support
scan the QR code or visit:
www.pressac.com/pressac-sensing
CONTACT DETAILS
Fax: +44 (0) 115 936 5252
E-mail: sales@pressac.com
TECHNICAL SUPPORT
Tel: +44 (0) 115 936 5202
E-mail: tech_support@pressac.com
CO , Temperature and Humidity Sensor
2
EEP: A5-09-04 GUIDE VERSION 1.1
Q U I C K S T A R T G U I D E
