USER MANUAL and TREATMENT GUIDE
Congratulations on your decision to purchase Sonic Relief™ Portable Pain Therapy! You are on the
road to effective, portable pain relief and an improved quality of life.
Read this manual in its entirety before using your Sonic Relief™. We recommend that you consult
your physician or physical therapy practitioner before using this device.
Remember to use the handy registration and re-order form contained in this booklet.
To order additional Sonic Relief™ Portable Pain Therapy Devices or Sonic Relief™ Ultrasound Gel, visit
our website www.sonicrelief.com
Important - Please note:
• Do not use your Sonic Relief™ without ultrasound gel. Always apply generous amount of Sonic
Relief™ ultrasound gel on the sound head and/or skin before your treatment to ensure it does
not run out before the end of your treatment.
• If the gel does begin to dry out before the end of treatment and you begin to feel
uncomfortable heat, turn off your Sonic Relief™ and use more gel on your next treatment.
• Do not turn on your Sonic Relief™ without contact to skin – keep the face of the ultrasound unit
flat against the skin at all times. Do not tilt the sound head or lift it during treatment. Ensure you
keep your Sonic Relief™ in constant motion during treatment.
• Allow Sonic Relief™ to cool off 15 minutes between treatments on different areas of the body.
• Always unplug your Sonic Relief™ when not in use.
If you have any questions, email scooper@sonicrelief.com . Should you wish to return your
Sonic Relief™ for refund or exchange it in case of damage, visit our returns page for instructions.
http://www.sonicrelief.com/return-form.html
Sonic Relief™
scooper@sonicrelief.com www.sonicrelief.com
Advertisement
Summary of Contents for SONIC RELIEF Portable Ultrasound Device
- Page 1 USER MANUAL and TREATMENT GUIDE Congratulations on your decision to purchase Sonic Relief™ Portable Pain Therapy! You are on the road to effective, portable pain relief and an improved quality of life. Read this manual in its entirety before using your Sonic Relief™. We recommend that you consult your physician or physical therapy practitioner before using this device. Remember to use the handy registration and re-order form contained in this booklet. To order additional Sonic Relief™ Portable Pain Therapy Devices or Sonic Relief™ Ultrasound Gel, visit our website www.sonicrelief.com Important - Please note: • Do not use your Sonic Relief™ without ultrasound gel. Always apply generous amount of Sonic Relief™ ultrasound gel on the sound head and/or skin before your treatment to ensure it does not run out before the end of your treatment. • If the gel does begin to dry out before the end of treatment and you begin to feel uncomfortable heat, turn off your Sonic Relief™ and use more gel on your next treatment. • Do not turn on your Sonic Relief™ without contact to skin – keep the face of the ultrasound unit flat against the skin at all times. Do not tilt the sound head or lift it during treatment. Ensure you keep your Sonic Relief™ in constant motion during treatment. • Allow Sonic Relief™ to cool off 15 minutes between treatments on different areas of the body. • Always unplug your Sonic Relief™ when not in use. If you have any questions, email scooper@sonicrelief.com . Should you wish to return your Sonic Relief™ for refund or exchange it in case of damage, visit our returns page for instructions. http://www.sonicrelief.com/return-form.html Sonic Relief™ scooper@sonicrelief.com www.sonicrelief.com...
-
Page 2: Table Of Contents
What To Expect: Before you use your Sonic Relief ™ Portable Ultrasound Device, you should note that Sonic Relief™ does not produce significant noticeable sound or motion. Some users mistakenly believe that the unit is not working or will not produce the desired effects because it does not vibrate or act like a ‘massager’. Sonic Relief ™ is a Medical Device that provides low-dose therapeutic ultrasound – it is not a massager. If the light on the unit turns on, the device should be working. You can run a ‘water-drop’ test to confirm the output of the device. To do this, follow these steps: 1. Choose the high setting so that the light is on. 2. Turn the unit over so the ‘head’ is facing upwards. 3. Place a small drop (size of a ten-cent coin) of water on the head. 4. Ensure that the water does not run off the head onto the body of the device. 5. Turn the device on for 10 seconds – the water should be visibly agitated and bubble or ‘jump’. 6. Turn the device off and wipe any water. If you do not experience immediate pain relief, we suggest that you still continue to treat yourself for the duration of the recommended treatment regimen as outlined in your manual. While many users experience pain relief soon after first using Sonic Relief, some people with more persistent pain may not experience relief until after a week or more of regular use. If you have any questions please email us at scooper@sonicrelief.com Table of Contents Ultrasound Therapy Explained What is Sonic Relief™? What Does It Treat? Unit Output Specifications How to use the Sonic Relief™ Ultrasound Device Warnings and Contraindications Treatment Methods 5-6 How to Treat Specific Ailments Sonic Relief™ Ultrasound Gel Frequently Asked Questions Warranty Sonic Relief™ is a registered trademark of Sonic Relief™. This book and its contents are Copyright Protected. -
Page 3: Ultrasound Therapy Explained
Ultrasound Therapy Explained What is Ultrasound? Ultrasound is a therapeutic treatment method utilizing sound waves to treat pain, inflammation and muscle spasm. Ultrasound therapy has been used by physical therapists since the 1940s. How does it work? Ultrasound waves are applied to tissues using a round-headed wand or transducer. Ultrasound gel is used on the skin in order to reduce friction and act as a conductor of the ultrasonic waves. Therapeutic ultrasound is in the frequency range of about 0.8-1.0 MHz (millions of vibrations/second). A typical ultrasound treatment will take from 5-10 minutes. During the treatment the head of the ultrasound probe is kept in constant motion. If the probe is held in one place for more than just a few seconds, a build up of the sound energy can result which can become uncomfortable. What do ultrasound waves do? Adds Heat: Sound waves penetrate the skin’s surface causing soft tissues to vibrate creating gentle heat. Increases Blood Flow: Ultrasound waves cause increases in tissue relaxation and local blood flow to the treatment area. The effect of the increase in local blood flow can be used to help reduce local swelling and chronic inflammation. Increased blood flow delivers needed oxygen and nutrients, and removes cell wastes. Enhances Absorption of Analgesics and Anti-inflammatory Agents: Ultrasound can also be used to evoke phonophoresis. This is a non-invasive way of enhancing the absorption of analgesics and anti-inflammatory agents to tissues below the skin using ultrasound waves. Decreases Trigger Point Pain: Ultrasound works by decreasing the pain/sensitivity associated with muscular trigger points. Studies have demonstrated trigger points to be important causes of headache, back ache and all types of muscular/soft tissue "overuse" syndromes. You will not feel any sensation – the sound waves are acting deep in the tissues– although you may feel a slight tingling, soothing sensation. Benefits of Ultrasound Therapy: relieves pain ✓ reduces inflammation ✓ r educes muscle spasms ✓ accelerates healing ü increases range of motion ✓ d ecreases the pain/sensitivity associated with muscular trigger points ü... -
Page 4: What Is Sonic Relief
What is Sonic Relief™? Portable Pain Therapy Sonic Relief™ is your personal therapeutic ultrasound device. The same ultrasound technology used at your physical therapist’s office is what Sonic Relief™ delivers. It is lightweight, safe and portable. Its contoured handle allows for comfortable, easy application to all areas of the body. Use it at home, while traveling or at the office! Effective Therapy and Pain Relief When used as directed with Sonic Relief™ Ultrasound Gel, your Sonic Relief™ device has been scientifically demonstrated to be an effective therapeutic device for the treatment of multiple medical ailments. Sonic Relief™ emits ultrasound waves at a frequency of 1-million vibrations per second (1 MHz). Its automatic shut-off makes Sonic Relief™ safe to use. Sonic Relief™ has been scientifically and medically tested to relieve pain and promote healing. Sonic Relief™ is Chiropractor and Doctor recommended for patients who require ultrasound treatment for ailments. Sonic Relief™ comes with specially formulated Sonic Relief™ Ultrasound Gel which gives immediate topical relief while conducting the ultrasound waves deep into the affected tissues. Cost Effective and Convenient Sonic Relief™ delivers the same kind of pain relief and healing benefits as professional ultrasound treatment at the physical therapy office. When used in conjunction with other physical therapy regimens, users can reduce recurring physical therapy costs and decrease time traveling to inconvenient appointments. Your Sonic Relief™ device may be covered by private insurance plans. What does Sonic Relief™ Treat? Sonic Relief™ treats essentially all conditions you would treat using regular therapeutic ultrasound including: Tendonitis Chronic pain Muscle spasm Muscle aches/pains Strains/sprains Bursitis Back ache Headache (tension) Ligament strains Nerve root pain Neuralgia Neck strains Low back strain Heel spurs Tennis elbow Golfer's elbow Hip or shoulder capsulitis Post-exercise recovery Carpal tunnel syndrome... -
Page 5: How To Use The Sonic Relief™ Ultrasound Device
Output Specifications • Power Source: 100-250V 50/60 Hz • Output Power: 5V 1A wireless • Lithium Battery Capacity: 1100mAH • Transducer Head Size: 40mm • Switch: On/Off Plus Hi/Med/Low Intensity • Frequency: 1 MHz ± 5% • Max Power: 5 watts • Intensity: High 5W, Medium 3W, Low 2W (±0.5) • Timer Setting: 10 minute auto off ± 5% • Weight: 178 gm How to Use the Sonic Relief™ Ultrasound Device Directions: 1. Remove Sonic Relief™ Device from packaging. 2. Plug cord into charging stand. Plug into regular wall socket or the USB end into a computer. 3. Charge for minimum 1 hour before using the first time. It is recommended to replace Sonic Relief™ in the charging stand after use and charging so it’s ready when you need it. 4. Position yourself comfortably, with the treatment area fully exposed. 5. Apply a generous layer of Sonic Relief™ Ultrasound Gel to the skin over the treatment area. 6. Press the power switch – the panel will be lit when the machine is on. 7. Choose the Intensity by pressing the up/down button to select the desired intensity based on the treatment manual. High, Medium, Low – choose high especially for long term or chronic conditions or those areas requiring deep penetration of sound waves (ie hips, knees, buttocks, back) and lower settings for areas that are closer to the surface of the skin. -
Page 6: Warnings And Contraindications
Note: You will not feel any sensation – the sound waves are acting deep in the tissues to heal and reduce inflammation – although you may feel a slight tingling soothing If you feel heat or discomfort at any time during the treatment, reduce the intensity by pushing the intensity button. Or increase the treatment area and speed of application and ensure that you are using adequate amount of gel. DO NOT EXCEED THE RECOMMENDED EXPOSURE TIMES INDICATED IN THIS MANUAL UNLESS DIRECTED TO DO SO BY A PHYSICIAN. Use Sonic Relief™ daily for the first 2 weeks at the daily frequency specified for your condition. After 2 weeks, reduce frequency of treatment to 3 days per week (at the daily frequency specified for your condition) as required. Week four should be a week off. If there is no improvement, consult a physician or therapist for re-evaluation. Treatments with Sonic Relief™ should be pain free and comfortable. If you feel any discomfort or pain during or after using Sonic Relief™, discontinue use immediately. Warnings for use: A. Never use the Sonic Relief™ ultrasound device for treatment without using the Sonic Relief™ conductive gel. B. Never clean the device with water or submerge it under water. C. Never use Sonic Relief™ on children under the age of 18 without the recommendation/supervision of a physician or therapist. Warnings and Contraindications: The use of Sonic Relief™ is not recommended: o ver organs (stomach, liver, lungs, spleen, bowels, heart, kidneys) × o ver the pelvis, abdomen and lumbar (lower back) region in pregnant or potentially pregnant females. × o ver highly ultrasound-sensitive organs (eyes, ears, ovaries, testicles, brain, spinal cord) × o ver mucous membranes (mouth, nose, rectum/anus, vagina) × o n patients with pace-makers or electronic implants ×... -
Page 7: Treatment Methods
Treatment Methods Indications Duration Intensity Regimen Placement Acute muscle sprains/strains Foot 5 minutes Medium or 3 times daily high Toes 5 minutes Medium or 3 times daily high Knee 10 minutes Medium 3 times daily Hip 10 minutes High 3 times daily Hand 5 minutes Medium or 3 times daily high Shoulder 10 minutes Medium or 3 times daily High Ankle 10 minutes High, 3 times daily medium... - Page 8 Indications Duration Intensity Regimen Placement Wrist 5 minutes High, 3 times daily medium Elbow 10 minutes High, 3 times daily medium Calf 10 minutes Medium- 3 times daily High Upper Back 10 minutes Medium- 3 times daily High Thigh 10 minutes High 3 times daily Neck 5-10 minutes Medium 3 times daily...
- Page 9 Indications Duration Intensity Regimen Placement Low Back Strain 10 minutes High 3 times per day Bursitis: Shoulder 10 minutes Medium, 3 times per day Hip 10 minutes 3 times per day High Tendonitis Medium, 3 times per day 5-10 minutes Directly over affected area high depending (acute) on location Carpal tunnel 5 minutes Medium 2 times per day syndrome Headaches 5 minutes Medium As many as needed – up to 3 (tension) times per day 5 minutes Plantar Fascitis, Medium...
-
Page 10: Sonic Relief™ Ultrasound Gel
Sonic Relief™ Ultrasound Gel Sonic Relief™ comes with a specially formulated conductive gel that enhances the therapeutic effects of ultrasound. Blended with natural compounds, this gel reduces inflammation and soothes pain through its deep-heating effect when exposed to ultrasound. Directions for Use: Apply a generous layer approximately 2 cm (1 in.) in diameter of specially formulated Sonic Relief™ Ultrasound Gel to the skin over the treatment area. Proceed with Sonic Relief™ ultrasound treatment according to Sonic Relief™ instruction manual. When treatment is complete, remove Sonic Relief™ Gel from the skin and the Sonic Relief™ ultrasound device with a towel or tissue. For external use only; do not use on broken skin. Discontinue use if rash or irritation occurs. If gel is swallowed, do not induce vomiting, seek medical attention immediately. Ingredients: Medicinal: Menthol 0.5%, Eucalyptus 0.5%, Peppermint 0.5%, Lavender 0.1% Others: Water, Carbopol,TEA 85%, Germall Plus, Methyl Paraben, FD&C Blue1 Warnings and Contraindications: The use of Sonic Relief™ Ultrasound Gel is not recommended: Over mucous membranes (mouth, nose, rectum/anus, vagina) and sensitive organs (eyes, ears, nose, × genitalia) O n tissue and/or bone with active infection × O ver areas suspected to be cancerous or pre-cancerous × O ver de-sensitized (numb, hypoaesthesia) areas of the skin (eg. diabetic neuropathy) × O ver open sores or lesions × F or use as a general lubricant × F or use with other medical or therapeutic devices × Frequently Asked Questions: Q – I am using the Sonic Relief™ as directed but I don’t feel anything during my treatment. Is it really working? A - Yes, if the light is on, the Sonic Relief™ is working. You should feel no sensation from the ultrasound waves. You may... -
Page 11: Warranty
Q - Can I use water or oil or lotion instead of gel with my Sonic Relief™? A - Sonic Relief™ Gel is specially made to work with your Sonic Relief™ Device. Use of any other product with your Sonic Relief™ is not recommended and may affect the performance of your device or can even damage the sound head. Sonic Relief™ gel is hyper-ionic so it conducts the ultrasound waves better than any other medium. Using any other medium will void your Sonic Relief™ warranty. Q – Can my 12 year old son use Sonic Relief™? A – Use of ultrasound is not recommended on children under the age of 18 unless on the advice of a physician. Q – Can I use Sonic Relief™ anywhere on my body? A – Sonic Relief™ cannot be used everywhere. Review the Sonic Relief™ contraindications before using. Warranty The Sonic Relief™ Portable Pain Therapy program comes with a 60 Day Money Back Guarantee from date of purchase for products purchased DIRECTLY from Sonic Relief™. If you are not satisfied with your purchase within 60 days, you must call email scooper@sonicrelief.com to arrange for your refund. Sonic Relief™ will exchange any product with manufacturer defects for new product within one year (less shipping/handling) after date of purchase. Damage caused by user mishandling, dropping etc. will not be exchanged. Email Sonic Relief™ to arrange for your exchange. Sonic Relief™ does not cover products purchased through eBay. We stand behind, and are proud, of all the medical devices we have created and the countless number of people they have helped and improved their quality of life. We hope you enjoy the use and benefits of your Sonic Relief™ Portable Pain Management System as much as we did creating it. Sonic Relief™ scooper@sonicrelief.com www.sonicrelief.com Visit www.sonicrelief.com to fill out your warranty card. version –RC 1.0...
