Light Instruments EDGE C Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1
EDGE C
Quickstart Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDGE C and is the answer not in the manual?

Questions and answers

Summary of Contents for Light Instruments EDGE C

  • Page 1 EDGE C Quickstart Guide...
  • Page 3 The EDGE C was developed by li - Light Instruments GmbH. We continue to work on our visions of modern lighting technology tools. We hope you enjoy a pleasant work flow...

  • Page 4: Table Of Contents

    TABLE OF CONTENT Scope of Delivery & Accessories EDGE C Server EDGE C App Gesture Control Set Up EDGE C Server Set Up EDGE C App Play Media Content Customize Media Content Mask Media Content Create Playlists Adjust the Volume...

  • Page 5: Scope Of Delivery & Accessories

    Quickstart Guide Packaging REQUIRED ACCESSORIES Video connection cable (HDMI oder Display Port) iPad (at least iOS 10) with installed EDGE C app at www.app.light-instruments.de Projector, screen or similar output device OPTIONAL ACCESSORIES EDGE projector mount USB stick (formatting FAT 32)

  • Page 6: Edge Cserver

    Ethernet interface (for a router Internet connection), and two HDMI ports for the output with up to two projectors and/or screens. A web camera can be connected via USB to the EDGE C to retrieve snapshots of the scene in the app.
  • Page 7 On/Off HDMI Ethernet Power HDMI...

  • Page 8: Edge Capp

    EDGE C With the EDGE C app you control your EDGE C server. In the app, you can create surfaces, adjust perspectives and mask media content. In the media management, you can select videos and images and manage them in playlists.
  • Page 9 SCENE MODE Media output Command bar MEDIA MANAGEMENT Media of the iPad and Media on USB stick, effects the EDGE C...

  • Page 10: Gesture Control

    GESTURE CONTROL SIMPLE TAPPING Select objects and confirm entries ZOOM PINCH Shrinks or enlarges a selected object. If no object is selected, the workspace can be zoomed. SINGLE FINGER DRAG Move selected objects DOUBLE FINGER DRAG Move view...

  • Page 11: Set Up Edge C Server

    SET UP EDGE C To use the EDGE C server, it must be connected to the power supply and connected to an output device (such as a projector). To control the EDGE C use the EDGE C App (see page 12).

  • Page 12: Set Up Edge C App

    SET UP EDGE C APP To control the EDGE C server, you must connect it to an iPad. Install the EDGE C app from the Apple App Store. Get the app here: www.app.light-instruments.de Go to the WLAN settings of your iPad and connect it to the WLAN of the EDGE C server.
  • Page 13 C server is not connected to the Internet; yet the EDGE C server and the iPad are connected to each other. If the EDGE C server is connected to the Internet, a check is displayed instead of the rotating circle.
  • Page 14 PLAY MEDIA CONTENT Create a surface and assign the favored media content to realize your projection. The iPad must be connected to the EDGE C server (see page 12). Add a new surface with Add Object. Since no content has been assigned yet, this surface displays a test pattern.
  • Page 15 NOTE Media files from the iPad, a USB stick and effects can be found on the left side of the media management. Already added media files are copied to the internal data store, the EDGE Storage on the right side. Depending on the size and type of the media files, it may take a moment for the media file to be dis- played on the iPad.

  • Page 16: Customize Media Content

    CUSTOMIZE MEDIA CONTENT Bring surfaces with media content into the favored shape: Single tap the surface you want to adjust Move the surface to the favored po- sition by tap dragging the surface Select one of the blue corner marks and move it to adjust the area NOTE Bring your surface to the needed shape...
  • Page 17 MASK MEDIA CONTENT Use the masking mode to display only parts of the media content or to cut out precise shapes Select the favored surface Add a new mask by tapping Edit Mask. You have now entered the yellow mask mode. Move the yellow corner marks to ad- just the mask Use the + Icon on the outer edge of...

  • Page 18: Create Playlists

    Tap Set Content Select the files you want to play in this playlist. You can select files from your iPad, a USB stick or from the EDGE C storage on the right side. The number in the circle represents the playing order of the files...

  • Page 19: Adjust The Volume

    0 to 100 NOTE The volume of a surface is set to zero by default. The sound can be played out via the jack output on the front of the EDGE C or via HDMI.
  • Page 20 Insert a USB stick (see page 5) with the favored files into a USB port of the EDGE C server Open the EDGE C app and add a surface (see page 14) Tap Set Content and select USB 1, USB 2, or USB 3 on the left side of...

  • Page 21: Live Signals Via Usb

    Connect webcam HDMI grabber with an USB port of the EDGE C Select the surface to which the live signal should be assigned Press Set Content and select the correct source in the left column „Media“. The lists name is specific to...

  • Page 22: Set New Password

    SET NEW PASSWORD Since the EDGE C is shipped with a standard password, we recommend as- signing a different password to protect your EDGE. Open Settings in the scene mode of EDGE C App Open System Enter the default password...

  • Page 23: Set New System Name

    SET NEW SYSTEM NAME You can choose your favored name for your EDGE C. Open Settings in scene mode of EDGE C App Open System Enter your password Enter your new system name in the name line and press apply changes.

  • Page 24: Update Process

    UPDATE PROCESS UPDATE EDGE C APP Update your EDGE C App to keep your app up to date. You will be notified about any available update when you start the app. UPDATE EDGE C SERVER Once an update is available for your EDGE C Server, your EDGE C App will alert you.
  • Page 25 Now connect your iPad to your EDGE C server via Settings > WLAN > Your EDGE C. A check mark before the connection indicates, that the EDGE C server is connected to the Internet. (If you do not see a check mark, verify your Internet connection).

  • Page 26: Safety & Warnings

    SAFETY & WARNINGS AC POWER ADAPTER If a different power adapter than the one supplied with the product is used, there is a risk of electric shock or fire or burn hazard. Use only in buildings and dry environments. The unit may only be repaired by an authorized technician.
  • Page 27 TEMPERATURE This device is intended for use at ambient tem- peratures between 0 ° C and 35 ° C. Avoid usage and storage near sources of heat, direct sunlight or in environments with temperatures outside the specified values. MEDICAL This device may cause interference in the ope- ration of certain pacemakers, hearing aids, or other medical devices.

  • Page 28: Contact

    Please state your EDGE system num- ber to make sure we process your request to the best possible extent. In case of returning a defect or old de- vice, please send it to: li - Light Instruments GmbH - Retour- Haßstraße 3 24103 Kiel Germany...
  • Page 30 - Light Instruments GmbH Haßstraße 3 D - 24103 Kiel +49 431 8870 3106 www.light-instruments.de...
