- Page 1 Operation and Service Manual Laser Wheel Alignment System TLT-12 Truck, Trailer, and RV Alignment System 8231 Blaine Rd. Blaine, WA 98230 360-371-0552 Phone 800-496-3777 Toll Free www.Tru-Line.net...
-
Page 2: Table Of Contents
Table of Contents Introduction ......................... 3 How it Works ........................4 Reading the Targets: ....................... 4 Unpacking and Assembling the System................5 Calibration Procedures ......................7 Calibrating the camber of the TLT-30................7 Calibrating the TLT-56 Digital Level… ................. 8 Calibrating the toe settings for TLT-36 right Laser Gun and TLT-37 left Laser Gun. -
Page 3: Introduction
Tru-Line is pleased to have you and your company as a client. We are available to you to answer any questions that you may have. Please feel free to contact us if there is anything further we can do to make Tru-Line a better product for you and your company. -
Page 4: How It Works
How it Works The TLT-12 wheel alignment system measures Caster, Camber, SAI/KPI, Toe, Tracking/Tandem, and Offset. These alignments can reference the mechanical or actual centerline of the vehicle. Two-wheel centerline, tracking, and four-wheel total alignments can be made. Depending on the model of vehicle being aligned, the technician chooses which type of alignment to do. -
Page 5: Unpacking And Assembling The System
Unpacking and Assembling the System The system is shipped for the most part complete and ready to use. However, you will need to assemble a couple of items in order to use the system to its fullest capability. 1. To assemble the TLT-41 Calibration Bar (Fig. 1). Locate the bar which looks like a black bar with three disks on one end. - Page 6 3. Next you will find a pair of targets. These targets mount either on the King Pin Target kit, (Fig. 3) or the Wheel Chock Target Stands (Fig. 4). The targets have plastic thumbscrews for easy mounting and dismounting. Please note that when assembling these Targets, they must be mounted exactly mirror image from each other in order to obtain the highest accuracy.
-
Page 7: Calibration Procedures
Calibration Procedures Using the TLT-41 Calibration Bar, you are able to calibrate the TLT-12 wheel alignment system, which consist of the TLT-30 EZ Check Gauge, TLT-36 right Laser Gun, and TLT-37 left Laser Gun. For maximum accuracy, it is important to check and, if necessary, recalibrate the alignment system regularly. -
Page 8: Calibrating The Tlt-56 Digital Level
Calibrating the TLT-56 Digital Level Note: There is a separate set of detailed instructions included with the TLT-56 Digital Level (AccuLevell ™ 1) Place the TLT-56 Digital Level on a flat surface. 2) Wait ten (10) seconds. 3) Push and hold the CALIBRATE button for 2seconds. (-1-) will appear briefly on the display. -
Page 9: Calibrating The Toe Settings For Tlt-36 Right Laser Gun And Tlt-37 Left Laser Gun
Calibrating the toe settings for TLT-36 right Laser Gun and TLT-37 left Laser Gun. 1) Place the TLT-41 Calibration Bar on a firm surface orientated so that the end of the bar that has the mounting discs on it is opposite of a clear distance of at least twenty (20’) feet. -
Page 10: Calibration Of The Tlt-44
1/16th Hex Screws Ring Scale Dial Ring Zero Mark Figure 7 Calibration of the TLT-44 To calibrate TLT-44 it must be assembled. Figure 20 shows the bar placed under the front wheels of the vehicle to be measured. Since the bar rests near the front wheels, it is tilted the same amount as the vehicle. - Page 11 TLT-44 Level Compensator Bar Calibration Procedure 1. Place the bar on a firm surface. One side of the bar has a red dot (called the red side). Place the bar with the red side on the left.(Fig. 8) Locking Nut Red Side Locking Knob Height Adjustment Screw...
- Page 12 Caster Bubble 1/2 way to Zero Locking Nut Black Side Locking Knob Height Adjustment Screw Figure 11 If the bar is properly calibrated, the caster reading will be the same with the bar returned to the original position (red side on the left). Once the bar is calibrated, it should not require recalibration.
-
Page 13: General Alignment Procedure
General Alignment Procedure The following section is an overall guide for performing an alignment with the TLT-12. The steps listed below are meant to give a basic understanding of what procedures are used and how they are performed to accomplish wheel alignment. The steps given should generally be followed in the same order as they have been placed. - Page 14 5) Lower the vehicle to settle the suspension. Be sure that the front turning plates are released and move freely. 6) Hang the TLT-30 on the left front wheel clamp to measure camber, caster and SAI/KPI. a. For camber readings: with the tire in a straight-ahead position, take the reading of the camber bubble on the TLT-30.
-
Page 15: Mounting The Tlt-28 Wheel Clamps
Mounting the TLT–28 Wheel Clamps The wheel clamps, (Fig 12) can be attached to either the inside or the outside of the rim (whichever is easiest). They can be mounted on a wheel rim 17 inches to 25 inches in diameter, and the aluminum feet are less likely to damage polished aluminum rims. -
Page 16: Run-Out Procedure
Run-Out Procedure Once the wheel clamps have been mounted, a simple run-out procedure should be performed. The following should be completed before run out adjustments are made: • Front wheel clamps must be installed • The vehicle must be raised, so the wheels can rotate freely. Run Out Procedure: 1) Place the TLT-30 on the disk extending from the wheel clamp. - Page 17 Caster Zero Adjustment Figure 14 5) Level the TLT-30 and read the number on the caster scale. 6) Adjust the bubble to the point halfway between zero and the current reading using the RED knob on the TLT-28. (When making this adjustment, it is important not to move the bubble with the caster adjustment knob.) 7) Rotate the wheel ¼...
- Page 18 9) Rotate the wheel ½ turn, until the clamping knob is at a 3:00 o’clock position (Fig 16). Red Adjustment Knob Figure 16 10) Level the TLT-30, and read the number on the caster scale. 11) Adjust the caster bubble to the point halfway between zero and the current reading, using the two BLACK knobs on the wheel clamp.
-
Page 19: Accommodating Oversize Truck Tires
Accommodating Oversize Truck Tires Although the Tru-Line TLT series alignment system is designed to align vehicles with rim diameters up to 25”, alignment of vehicles with larger rim and tire diameters is possible. By offsetting the center assembly of the TLT-28 Wheel Clamp is to accommodate the laser to reach around the oversize tire as seen in the diagram below. -
Page 20: Measuring Camber
Measuring Caster, Camber, SAI/KPI with the TL-30 Easy Check Angle Gauge Measuring Caster, Camber, SAI/KPI is very simple and fast. Before performing these measurements: • The equipment must be calibrated. • The wheel clamps must be mounted and adjusted for run out. •... -
Page 21: Measuring Sai/Kpi
Measuring SAI/KPI: When measuring SAI/KPI, the Brake Pedal Depressor (TLT-31) must be installed, so the wheel does not rotate. Note: If the car has power brakes, run the engine while performing this procedure. 1) Hang the TLT-30 the left front wheel clamp to measure SAI/KPI (Fig 19). 2) Install brake pedal depressor and lock brakes so they do not rotate. -
Page 22: Measuring Caster With The Tlt-56 Digital Level
Measuring Caster with the TLT-56 Digital Level (AccuLevel™) There is another way to read Caster on Heavy Duty Truck with a solid front (steer) axle. This method provides an accurate caster reading and gives the user the ability to make caster measurements and adjustments with out having to purchase turn tables which can be heavy and costly. -
Page 23: Measuring Caster, Camber And Sai/Kpi On A Non-Level Surface
Measuring Caster, Camber and SAI/KPI on a Non-Level Surface When the vehicle is not on a level surface, the procedure is somewhat different. The TLT-30 Easy Check Angle Gauge is used in conjunction with the TLT-44 Level Compensator Bar to correct the readings. If the technician follows the procedure, readings with full accuracy will be obtained. -
Page 24: To Measure Front To Rear Tilt For Caster
3. Hang the gauge on the black side and read the camber. 4. Adjust the bubble half way back using the camber zero adjust knob. The camber gauge now reads the tilt on the ground. 1. Place the gauge on the red side and read the tilt of the ground. Whatever the SAI/KPI readings are, add the ground tilt reading on the right side, and subtract the reading on the left side. -
Page 25: Live Caster Adjustment
Live Caster Adjustment Caster readings are taken on the front wheels, using the TLT-30. 1) Hang the TLT-30 on the left front wheel clamp to measure caster. 2) Install brake pedal depressor and lock brakes so they do not rotate. With power brakes start the engine to install brake pedal depressor. -
Page 26: Two-Wheel Centerline Alignment
Two-Wheel Centerline Alignment The purpose of a Two-wheel Centerline alignment is to align the front wheels to the theoretical centerline of the vehicle. This is accomplished by adjusting the front wheels to match up with the centerline of the vehicle. The following should be completed before making any measurements or adjustments: 1) Equipment should be checked for calibration. - Page 27 b. Check to make sure that the cross-toe laser from the left laser box is hitting the cross-toe mirror in the laser box. If not, adjust the cross toe vertical pivot knob, which is on the left laser box, until the laser reaches the mirror.
- Page 28 Two Wheel Centerline Alignment Figure 22...
-
Page 29: Tracking & Offset
Tracking & Offset The purpose of a Tracking is to adjust the rear axles until they are aligned with the vehicle chassis. These procedures can be used on a trailer as well by using our King Pin Target kit. The following should be completed before making any measurements or adjustments: 1) Equipment should be checked for calibration. -
Page 30: Offset Procedure
Offset Procedure: Offset is when a vehicle’s rear axles are mounted to the vehicle chassis out of center to each other and the vehicle chassis. You must follow tracking on one axle before you move to offset. 1) Place both TLT-28 Wheel Clamps on one side of the vehicle to be measured for offset. - Page 31 Tracking...
-
Page 32: Maintenance, Warranty & Service
Tru-Line Wheel Alignment Systems are guaranteed to the original owner for a period of two years from the date of purchase. Tru-Line will repair or replace, at its options, for the full two years, those parts returned to the desired and proves to be defective after inspection by Tru-Line. -
Page 33: Service Instructions
Routine desired maintenance and service is not necessary. However, if the system is not functioning properly, the user should not attempt to repair any equipment. A Tru-Line service representative should perform all servicing and repairs at the desired.
