Summary of Contents for Megaelektronik SIMNANO+
- Page 1 EXPANDER GSM / GPRS INTEGRAL + ® 2G with the function of the central panel and the communication of GSM / GPRS ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 1...
- Page 2 The current declaration of CE can be found at www.megaelektronik.pl Megaelektronik.pl continually improves its products and reserves the right to make changes in the operation of the product during its manufacture and use, without prior notice.
- Page 3 The module has six richly configurable inputs, four relay outputs and four OC outputs. Digital input for connecting temperature sensors, audio modules, is suitable for housing for DIN rail 35 mm. PCB Description ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 3...
- Page 4 One flash every 6 seconds. Module logged correctly L-2 Rapid blinking - the system starts One blink - receiving a message L-3-one flash to send the message L-2 and L-3 flashing alternately update or unloaded correctly flash module ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 4...
- Page 5 -20C to +55 C Working conditions GSM/GPRS 850/900/1800/1900 MHz Operating frequency, transmit power (2 W @ 850/900 MHz) (1 W @ 1800/1900MHz) Dimensions Height 62.8 mm Width 88.8 mm Length 138.8 mm ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 5...
- Page 6 We can remotely manage the SIM card located in the module, such as prepaid or post codes to activate the service to add new packages, etc., be sure also to include the "Echo" by which we receive feedback messages from GSM networks such as account balance, etc. ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 6...
- Page 7 Extensive diagnostics of the module is able to signal the loss of signal of GSM, SIM card lock, or other cause not correct the erroneous operation of the device by using a dedicated OC outputs ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 7...
-
Page 8: Installation
When connecting the battery pack should be applied to the parameters given in the table. Connected battery Voltage voltage (V min.) Devices (V min.) 14, 5V 26, 5V ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 8... - Page 9 An example of the power connection ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 9...
- Page 10 • Insert the SIM card, the card must be included in the PIN code request. • Connect the power supply. • Wait for your SIM card to log on • Send a text message to the SIM card in the device of the content. ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 10...
- Page 11 • Confirm the download of data from the device. • Enter your settings. • Click Program. • The unit is ready to work. • To disconnect the Internet connection, close the program. (Closing the Internet connection takes about 2 minutes) ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 11...
- Page 12 Module connected to the PC using a program IPE-1 USB. INTERNET OK. The PC waits for a connection with the module. Expander GPRS OK. Module connected to the PC software via the Internet ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 12...
- Page 13 Where xxx is a number from 1 to 999 Disabling the maximum number of sent SMS-no limit ####counter off Output Disable AWR ####error GSM on signaling failures ####error GSM off Output Enable AWR signaling failures ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 13...
- Page 14 The number that we send an SMS with the configuration change must have selected a remote configuration. Examples for additional options 5678 48507473767 send SMS "hello world" The telephone number +48507473767 to receive from the module SMS "hello world" Call 5678 * 121 # ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 14...
- Page 15 Help system and the location of errors in programming The PC before programming checks whether all the required fields are completed, if it is otherwise dictates where in entries must be corrected. ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 15...
- Page 16 Remote configuration The telephone number at which this option is selected may change the parameters of the device via SMS. echo Incoming sms messages to the module I passed on the selected numbers. ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 16...
- Page 17 It is recommended to manually enter the number, only if the module is working in the border areas. Module Name The name will be sent at the beginning of each SMS text message or e-mail. External Power ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 17...
- Page 18 The device has a built-in trigger alarm, you can connect a standard motion sensors (PIR) sensors P. FIRE PROTECTION, contusions, vibration and any others that provide on its output NO or NC states of matter, or plus ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 18...
- Page 19 To use this feature, you must select the starting number and choose a way of controlling the line of tabs in the Time input Entered value provides a delay of the input line after arming Emergency mode – disarming ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 19...
- Page 20 • alarm outputs: relay (RELAY - potential-free contacts) • Trip time from 0.3 s to 9999sek. • In addition, IN-3 line can be an analog line on the reaction of 0.6V to 27V ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 20...
- Page 21 For each method of response functions can be assigned to the IO logic. (Each input can control any output) Analogowe NAZWA (+) , (-) (+) ,(-) (2k2) IN-1….IN-2 √ √ √ IN-3 √ √ √ (only IN-3) √ -support X – not support ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 21...
- Page 22 (Range of all possible 0.1s to 9999s). Stand 24 Selecting this option causes the temperature measurement function is active, regardless of status. Otherwise, the function will be enabled only module is armed. ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 22...
- Page 23 Xxxx GARAGE ON 120 turns on the output OUT-1 to 120sek OFF GARAGE xxxx 120 disables the output OUT-1 to 120sek For each entry, enter the various names without Polish characters Xxxx-access code ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 23...
- Page 24 • Communicating with CLIP ringtones, SMS, E-MAILS about the excess states. • Assign any name a connected sensor. • Emergency-temp2 temperature and informing users via SMS. • The findings of the measured temperature differential. ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 24...
- Page 25 • depending on the temperature in a monostable or bistable control and repeat at intervals (range of all possible 0, 001 to 9999999s). Report ON OFF Hysteresis Setting the hysteresis of the sensors. ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 25...
- Page 26 • Password and user,-if required Accessories (in preparation) The device is prepared for connection of accessories that will appear in the manufacturer's offer in the near future. For more information visit www.megaelektronik.pl • SIMTOUCH-LCD touch panel, preview and management module ® 2G EXPANDER GSM „SIMNANO+”...
- Page 27 Innovative solutions allow for individual choice to the users' needs. On this tab, select what information we print to receive. You can also specify a cyclical sending time information selected and users who will receive them. ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 27...
- Page 28 Innovative solutions allow for individual choice to the users' needs. On this tab, select what information we print to receive. You can also specify a cyclical sending time information selected and users who will receive them. ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 28...
- Page 29 Send Report SMS - sends a report on the number of devices registered on the Line tab, ON Send e-mail report sends an e-mail report to the email address entered on the tab line ON ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 29...
- Page 30 With this function you can upload new software yourself without having to return the unit to service. To update the device the new software, click the "update software module", and upload the file extension * LHX. New software versions can be found on the website www.megaelektronik.com.pl (updated products). The update is only possible through IP-1 USB.
- Page 31 ® 2G EXPANDER GSM „SIMNANO+” www.megaelektronik.com.pl Strona 31...
