Securing the iPad to the MultiGrip™
Install selected Mounting Option before securing the iPad
A
Place iPad above the
MultiGrip™ (1). Gently
press the iPad in place.
If power cable is needed
insert it before placing
iPad in place!
B
Place the SafeGuard
Frame
(2),
from
top.
Align the holes for the
tamper proof screws (5).
C
Using the tool (6),
secure
the
SafeGuard
Frame with tamper proof
screws (5), in four points.
D
The iPad is now secured
and ready to be used.
4
iPad SafeGuard Frames
Installation Instructions
®
Advertisement
Table of Contents
Summary of Contents for Space Pole Atdec SafeGuard
- Page 1 Securing the iPad to the MultiGrip™ Install selected Mounting Option before securing the iPad Place iPad above the MultiGrip™ (1). Gently iPad SafeGuard Frames press the iPad in place. If power cable is needed insert it before placing iPad in place! Installation Instructions Place the SafeGuard Frame...
- Page 2 ® DuraTilt mounting MultiGrip™ plate for iPad, multiple mounting options Uses two screws (3) to attach the MultiGrip™ (1) to a DuraTilt™ connection. Tool (6) is included for use. SafeGuard Frame VESA mounting Uses four screws (4) to M4/5 counter-sink screws with hex recess (x 2) attach the MultiGrip™...
